Lexus GS450h2016 Service Manual

Table of Contents

Quick Links

Download this manual

Pictorial index

For safety

and security

Instrument cluster

Operation of

each component

Driving

Interior features

Maintenance

and care

When trouble

arises

Vehicle

specifications

For owners

Index

GS450h_OM_OM30E99U_(U)

Search by illustration

Make sure to read through them

How to read the gauges and meters, the variety of

warning lights and indicators, etc.

Opening and closing the doors and windows,

adjustment before driving, etc.

Operations and advice which are necessary for driving

Usage of the interior features, etc.

Caring for your vehicle and maintenance procedures

What to do in case of malfunction or emergency

Vehicle specifications, customizable features, etc.

Reporting safety defects for U.S. owners, and seat belt,

SRS airbag and headlight aim instructions for Canadian

owners

Search by symptom

Search alphabetically

Table of Contents

Summary of Contents for Lexus GS450h2016

Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security How to read the gauges and meters, the variety of Instrument cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each component adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information........8 Instrument cluster Reading this manual........12 How to search ..........13 Instrument cluster Pictorial index..........14 Warning lights and indicators......80 For safety and security Gauges and meters..... 86 Multi-information display ..93 1-1. For safe use Head-up display......101 Before driving.........
Page 3 Opening the fuel tank cap ..210 4-5. Using the driving support 4-1. Before driving systems Driving the vehicle ......166 Lexus Safety System+ ....214 Cargo and luggage......174 Vehicle load limits......177 (Pre-Collision System) ..220 Trailer towing .........178 LKA (Lane-Keeping Assist) ..........
Page 4 • Coat hooks......318 air conditioning system..285 • Assist grips ......318 • Garage door opener ...319 Rear air conditioning system.......... 296 LEXUS Enform Safety Connect........326 Heated steering wheel/ seat heaters/seat Maintenance and care ventilators........299 5-3. Using the interior lights 6-1.
Page 5 6-3. Do-it-yourself maintenance 7-2. Steps to take in an emergency Do-it-yourself service If your vehicle needs precautions........ 345 to be towed........ 394 Hood..........347 If you think something is wrong....399 Positioning a floor jack.....348 If a warning light turns on or Engine compartment ....
Page 6 Canadian owners (in French) (vehicles with single-beam headlights).....517 For information regarding the equipment listed below, refer to the “NAVIGA- TION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”. • Audio system • Navigation system • Intuitive parking assist • Lexus parking assist monitor GS450h_OM_OM30E99U_(U)
Page 7 GS450h_OM_OM30E99U_(U)
Page 8: For Your Information
Lexus vehicle. This vehicle should not be modified with non-genuine Lexus products. Modification with non-genuine Lexus products could affect its performance, safety or durability, and may even violate governmental regulations.
Page 9 Usage of data collected through Safety Connect / Lexus Enform (U.S. mainland only) If your Lexus has Safety Connect or Lexus Enform and if you have subscribed to those services, please refer to the Safety Connect / Lexus Enform Telematics Subscription Service Agreement for information on data collected and its usage.
Page 10 EDR. ● Disclosure of the EDR data Lexus will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’ s owner (or the lessee for a leased vehicle) is obtained •...
Page 11 Scrapping of your Lexus The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Lexus dealer before you scrap your vehicle.
Page 12: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a mal- function in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps in numerical order.
Page 13: How To Search
How to search Searching by name ■ • Alphabetical index....P. 524 Searching by installation position ■ • Pictorial index ......P. 14 Searching by symptom or sound ■ • What to do if... (Troubleshooting)....P. 520 Searching by title ■ • Table of contents......P. 2 GS450h_OM_OM30E99U_(U)
Page 14: Pictorial Index
Pictorial index Pictorial index ■ Exterior Doors ..............P. 120 Locking/unlocking .
Page 15 Pictorial index Windshield wipers ...........P. 204 Precautions against winter season .
Page 16: Warning Lights
Pictorial index ■ Instrument panel Power switch............P. 180 Starting the hybrid system/changing the modes.
Page 17 Pictorial index Multi-information display ..........P. 93 Display .
Page 18 Pictorial index ■ Switches VSC OFF switch........... . . P. 268 Heated steering wheel switch.
Page 19 Pictorial index Driving position memory switches ........P. 143 Outside rear view mirror switches .
Page 20 Pictorial index Audio remote control switches Paddle shift switches..........P. 189 Talk switch Meter control switches.
Page 21 Pictorial index Seat heater switches ..........P. 300 Seat ventilator switches .
Page 22 Pictorial index ■ Interior SRS airbags ............P. 35 Floor mats.
Page 23 Pictorial index Inside rear view mirror ..........P. 152 Sun visors .
Page 24 Pictorial index GS450h_OM_OM30E99U_(U)
Page 25: For Safety And Security
For safety and security 1-1. For safe use Before driving......... 26 For safety drive.......28 Seat belts ..........30 SRS airbags ........35 Front passenger occupant classification system....46 Safety information for children........52 Child restraint systems ....53 Installing child restraints..... 57 Exhaust gas precautions....65 1-2.
Page 26: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets.
Page 27 ■ Do not use floor mats designed for other models or different model year vehicles, ● even if they are Lexus Genuine floor mats. Only use floor mats designed for the driver’ s seat. ● Always install the floor mat securely using the retaining hooks (clips) provided.
Page 28: For Safety Drive
1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seatback so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 29 1-1. For safe use WARNING Observe the following precautions. Failure to do so may result in death or serious injury. Do not adjust the position of the driver’ s seat while driving. ● Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback.
Page 30: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts Extend the shoulder belt so that it ● comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 31 1-1. For safe use Seat belt comfort guide (outboard rear seats) For children or smaller-than-average people, slide the seat belt comfort guide forward so that the shoulder belt does not sit close to the person’ s neck. Seat belt pretensioners (front and outboard rear seats) The pretensioner helps the seat belt to quickly restrain the occupant by retracting the seat belt when the vehi-...
Page 32 Each seat belt should be used by one person only. Do not use a seat belt for more ● than one person at once, including children. Lexus recommends that children be seated in the rear seat and always use a seat belt ● and/or an appropriate child restraint system.
Page 33 If the pretensioner has activated, the SRS warning light will come on. In that case, the ● seat belt cannot be used again and must be replaced at your Lexus dealer. Adjustable shoulder anchor ■...
Page 34 Ensure that the belt and plate are locked and the belt is not twisted. ● If the seat belt does not function correctly, immediately contact your Lexus dealer. Replace the seat assembly, including the belts, if your vehicle has been involved in a ●...
Page 35: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 36 1-1. For safe use ◆ SRS side and curtain shield airbags SRS front side airbags Can help protect the torso of the front seat occupants SRS rear side airbags Can help protect the torso of occupants in the rear outer seats SRS curtain shield airbags Can help protect primarily the head of occupants in the outer seats ●...
Page 37 1-1. For safe use SRS airbag system components Front passenger occupant classifi- Front side airbags cation system (ECU and sensors) SRS warning light Side impact sensors (front doors) Driver airbag Knee airbags Rear side airbags Front passenger airbag Side impact sensors (rear) Curtain shield airbags Driver’...
Page 38 1-1. For safe use WARNING SRS airbag precautions ■ Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts properly. ●...
Page 39 An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Lexus strongly recom- mends that all infants and children be placed in the rear seats of the vehicle and prop- erly restrained.
Page 40 1-1. For safe use WARNING SRS airbag precautions ■ Do not lean against the door, the roof side rail ● or the front, side and rear pillars. Do not allow anyone to kneel on the passen- ● ger seat toward the door or put their head or hands outside the vehicle.
Page 41 ■ Do not dispose of your vehicle or perform any of the following modifications without consulting your Lexus dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury. Installation, removal, disassembly and repair of the SRS airbags ●...
Page 42 The airbag itself may also be hot. The windshield may crack. ● For Lexus Enform Safety Connect subscribers, if the SRS airbags deploy or in the event ● of a severe rear-end collision, the system is designed to send an emergency call to the response center, notifying them of the vehicle’...
Page 43 1-1. For safe use Conditions under which the SRS airbags may deploy (inflate), other than a collision ■ The SRS front airbags, SRS side and curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustra- tion.
Page 44 1-1. For safe use Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield air- ■ bags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 45 1-1. For safe use When to contact your Lexus dealer ■ In the following cases, the vehicle will require inspection and/or repair. Contact your Lexus dealer as soon as possible. Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or ●...
Page 46: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classification sys- tem. This system detects the conditions of the front passenger seat and acti- vates or deactivates the devices for the front passenger. Seat belt reminder light SRS warning light “AIR BAG OFF”...
Page 47 1-1. For safe use Condition and operation in the front passenger occupant classification system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Side airbag on the front passenger seat Curtain shield airbag...
Page 48 1-1. For safe use Child restraint system with infant ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag Devices...
Page 49 1-1. For safe use There is a malfunction in the system ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag...
Page 50 Do not kick the front passenger seat or subject it to severe impact. Otherwise, the ● SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Lexus dealer immediately. GS450h_OM_OM30E99U_(U)
Page 51 1-1. For safe use WARNING Front passenger occupant classification system precautions ■ Child restraint systems installed on the rear seat should not contact the front seat- ● backs. Do not use a seat accessory, such as a cushion and seat cover, that covers the seat ●...
Page 52: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehicle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. It is recommended that children sit in the rear seats to avoid accidental con- ●...
Page 53: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/ shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 54 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing  Infant seat/convert- Forward facing  Convertible   ible seat seat Booster seat ...
Page 55 In an accident, the child can be crushed against the windshield, or between you and the vehicle’ s interior. Lexus strongly urges the use of a proper child restraint system that conforms to the ● size of the child, installed on the rear seat. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 56 1-1. For safe use WARNING When children are in the vehicle ■ Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’ s neck, it may lead to choking or other serious injuries that could result in death. If this occurs and the buckle cannot be unfastened, scissors should be used to cut the belt.
Page 57: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compati- ble with the LATCH (Lower Anchors and Tethers for Children) system.
Page 58 1-1. For safe use Installation with LATCH system Remove the head restraint. Widen the gap between the seat cushion and seatback slightly. Type A  Latch the hooks of the lower straps onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor.
Page 59 1-1. For safe use Type B  Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: The symbol on a child restraint sys- tem indicates the presence of a lower connector system.
Page 60 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt can- not be extended. While pushing the child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 61 1-1. For safe use Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and allow it to retract to put it in lock mode.
Page 62 1-1. For safe use Sit the child in the child restraint system. Fit the seat belt to the child restraint system according to the manufacturer’ s instructions and insert the plate into the buckle. Make sure that the belt is not twisted.
Page 63 1-1. For safe use Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched. Laws and regulations pertaining to anchorages ■ The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifications can be used.
Page 64 1-1. For safe use WARNING When installing a child restraint system ■ When a booster seat is installed, always ensure that the shoulder belt is positioned ● across the center of the child’ s shoulder. The belt should be kept away from the child’ s neck, but not so that it could fall off the child’...
Page 65: Exhaust Gas Precautions
● If you smell exhaust gases in the vehicle even when the trunk lid is closed, open the ● windows and have the vehicle inspected at your Lexus dealer as soon as possible. When parking ■ If the vehicle is in a poorly ventilated area or a closed area, such as a garage, stop the ●...
Page 66: Hybrid System Features
1-2. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conven- tional vehicles. Be sure you are closely familiar with the characteristics of your vehicle, and operate if with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel effi- ciency and reducing exhaust emissions.
Page 67 1-2. Hybrid system ◆ During normal driving The gasoline engine is predominantly used. The electric motor (traction motor) charges the hybrid battery (traction battery) as necessary. ◆ When accelerating sharply When the accelerator pedal is depressed heavily, the power of the hybrid bat- tery (traction battery) is added to that of the gasoline engine via the electric motor (traction motor).
Page 68 The gasoline engine may not stop even if the vehicle is being driven by the hybrid battery (traction battery). If this continues for a few days, contact your Lexus dealer. Sounds and vibrations specific to a hybrid vehicle ■...
Page 69 Maintenance, repair, recycling, and disposal ■ Contact your Lexus dealer regarding maintenance, repair, recycling and disposal. Do not dispose of the vehicle yourself. Customization ■...
Page 70: Hybrid System Precautions
1-2. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it is a high voltage system (about 650 V at maximum) as well as contains parts that become extremely hot when the hybrid system is operating. Obey the warning labels attached to the vehicle.
Page 71 ■ connected The hybrid system may not start. In this case, try to start the system again. If the “READY” indicator does not come on, contact your Lexus dealer. Running out of fuel ■ When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the vehicle with at least enough gasoline to make the low fuel level warning light (P.
Page 72 1-2. Hybrid system WARNING High voltage precautions ■ This vehicle has high voltage DC and AC systems as well as a 12-volt system. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury.
Page 73 In the event that your vehicle must be disposed of, the hybrid battery must be disposed of by your Lexus dealer or a qualified service shop. If the hybrid bat- tery is not disposed of properly, it may cause electric shock that can result in death or serious injury.
Page 74: 1-3. Theft Deterrent System
1-3. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid sys- tem from starting if a key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. This system is designed to help prevent vehicle theft but does not guarantee absolute security against all vehicle thefts.
Page 75 1-3. Theft deterrent system Certifications for the immobilizer system ■ For vehicles sold in the U.S. mainland, Hawaii, Guam and Puerto Rico  For vehicles sold in Canada  GS450h_OM_OM30E99U_(U)
Page 76 1-3. Theft deterrent system WARNING Certifications for the immobilizer system ■ Changes or modifications not expressly approved by the party responsible for compli- ance could void the user’ s authority to operate the equipment. NOTICE To ensure the system operates correctly ■...
Page 77: Alarm
1-3. Theft deterrent system Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: A locked door or trunk is unlocked or opened in any way other than using the ●...
Page 78 1-3. Theft deterrent system System maintenance ■ The vehicle has a maintenance-free type alarm system. Items to check before locking the vehicle ■ To prevent unexpected triggering of the alarm and vehicle theft, make sure of the follow- ing: Nobody is in the vehicle. ●...
Page 79: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......80 Gauges and meters .....86 Multi-information display ..93 Head-up display ......101 Energy monitor/ consumption screen ....107 GS450h_OM_OM30E99U_(U)
Page 80: Warning Lights And Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster, center panel and outside rear view mirrors inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustrations display all warning lights and indicators illuminated.
Page 81 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehicle systems. Brake system warning light Slip indicator (P. 401) (P. 400) (U.S.A.) 2, 3 Brake system warning light “AFS OFF” indicator (P. 400) (P. 401) (Canada) (If equipped) 2, 4...
Page 82 They will turn off after the hybrid system is on, or after a few seconds. There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Lexus dealer. : The light flashes to indicate a malfunction.
Page 83 2. Instrument cluster Cruise control “SET” Brake hold standby indicator (P. 241, 253) indicator (P. 195) LKA (Lane-Keeping Assist) Brake hold operated indicator (P. 236) indicator (P. 195) (If equipped) Security indicator Parking brake indicator (P. 74, 77) (P. 193) (U.S.A.) Low outside temperature Parking brake indicator...
Page 84 There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Lexus dealer. : These lights turn on when the power switch is turned to ON mode to indicate that a system check is being performed.
Page 85 Have the vehicle inspected by your Lexus dealer immediately if this occurs. GS450h_OM_OM30E99U_(U)
Page 86: Gauges And Meters
2. Instrument cluster Gauges and meters Except F SPORT models  F SPORT models  The units used on the speedometer may differ depending on the target region. GS450h_OM_OM30E99U_(U)
Page 87 2. Instrument cluster Engine coolant temperature gauge Displays the engine coolant temperature Tachometer/Hybrid System Indicator Tachometer: Displays the engine speed in revolutions per minute. Hybrid System Indicator: Displays hybrid system output or regeneration level (P. 90) Outside temperature Displays the outside temperature within the range of -40F (-40C) to 122F (50C).
Page 88 2. Instrument cluster Rev indicator (F SPORT models) ■ When the engine reaches a set speed while the tachometer is dis- played, a ring-shaped indicator is displayed on the tachometer. Rev peak (F SPORT models) ■ When the engine speed reaches or exceeds 5000 rpm while the tachometer is displayed, an afterim- age of the tachometer needle is dis-...
Page 89 2. Instrument cluster Changing the display Switches between odometer, trip meter and maintenance required information displays. When the trip meter is dis- played, pressing and holding the button will reset the trip meter. Instrument panel light control The brightness of the instrument panel lights can be adjusted. Darker Brighter The meters and display illuminate when...
Page 90 2. Instrument cluster Hybrid System Indicator ■ Charge area Except F SPORT models  Shows regenerative charging. Hybrid Eco area Shows that gasoline engine power is not being used very often. The gasoline engine will automatically stop and restart under various conditions. Eco area Shows that the vehicle is being driven in an Eco-friendly manner.
Page 91 • When the vehicle is parked in direct sunlight When “--” or “E” is displayed, the system may be malfunctioning. ● Take your vehicle to your Lexus dealer. Pop-up display ■ In some situations, a pop-up display will be temporarily displayed on the multi-informa- tion display or the odometer/trip meter/maintenance required information screen.
Page 92 2. Instrument cluster WARNING The information display at low temperatures ■ Allow the interior of the vehicle to warm up before using the liquid crystal information display. At extremely low temperatures, the information display monitor may respond slowly, and display changes may be delayed. For example, there is a lag between the driver’...
Page 93: Multi-Information Display
2. Instrument cluster Multi-information display Display contents The multi-information display presents the driver with a variety of vehicle data. Menu icons ● Except F SPORT models F SPORT models   Displays the following information when an icon is selected. (P. 95) Some of the information may be displayed automatically depending on the situa- tion.
Page 94 2. Instrument cluster Settings display Select to change the meter display settings. (P. 492) Operating the meter control switches The multi-information display is oper- ated using the meter control switches. : Switch menu : Change displayed con- tent, scroll up/down the screen and move the cur- sor up/down Press: Enter/Set...
Page 95 2. Instrument cluster Drive information Items displayed can be switched by pressing of the meter control switches to select and pressing Current fuel consumption ■ Displays the current rate of fuel consumption Average fuel economy (after reset /after start/after refuel) ■...
Page 96 2. Instrument cluster Energy monitor ■ P. 107 G-forces ■ Displays lateral G-forces on the vehicle Also displays, around the periphery of the G-force display, the left and right steering amount, accelerator pedal input, and brake fluid pressure Acceleration G-force on the vehicle Current G-force value (analyzed value of front/rear and left/right...
Page 97 2. Instrument cluster Display off ■ A blank screen is displayed : Displayed when the item is set in “Drive Info 1”, “Drive Info 2” or “Drive Info 3”. (P. 492) : The function can be reset by pressing the of the meter control switches for longer than 1 second when the item to reset is displayed.
Page 98 2. Instrument cluster EV indicator ● Select to activate/deactivate the EV indicator. switch ● Displays a procedure to register a desired screen to You can register 1 screen as a shortcut, which can be displayed by pressing Drive information 1/2/3 ●...
Page 99 2. Instrument cluster G-force display ■ The G-force values may not be zero even when the vehicle is parked, such as when it is ● parked on an incline. Depending on the vehicle usage conditions, the brake fluid pressure display may not ●...
Page 100 2. Instrument cluster WARNING Caution for use while driving ■ When operating the multi-information display while driving, pay extra attention to the ● safety of the area around the vehicle. Do not look continuously at the multi-information display while driving as you may fail ●...
Page 101: Head-Up Display
2. Instrument cluster  Head-up display Summary of functions The head-up display can be used to project vehicle speed and other information onto the windshield. Head-up display Display brightness will change automat- ically according to the brightness of the surrounding area. “HUD”...
Page 102 When approaching an intersection while the navigation system is giving route guid- ance, an arrow will automatically be displayed to indicate the direction of travel. Lexus Enform (if equipped) ● Displays “LEXUS Enform” for approximately 3 seconds when LEXUS App Suite is operated Lane departure warning display (LKA [Lane-Keeping Assist]) ●...
Page 103 2. Instrument cluster Switching the head-up display “HUD” button ■ Pressing the switch turns the head- up display on/off and changes the vehicle speed display units as fol- lows: U.S.A.  OFF  ON (MPH)  ON (km/h)  OFF Canada ...
Page 104 2. Instrument cluster Making the display easier to see Adjusting the display position ■ Higher Lower Setting the brightness ■ The brightness of the display is automatically adjusted in accordance with the brightness of the surrounding environment. However, the brightness can also be manually adjusted in 9 stages.
Page 105 2. Instrument cluster Route guidance display When the vehicle approaches an inter- section, the direction the vehicle should go is guided by the arrow. When the vehicle approaches an inter- section, the route guidance will start and the distance* to the intersection will also be displayed.
Page 106 2. Instrument cluster Press the “DISP” button to switch between on and off. On and off will be switched between each time the button is pressed. If the button is left alone without being operated for a short time, setting will be fin- ished automatically.
Page 107: Energy Monitor/Consumption Screen
2. Instrument cluster Energy monitor/consumption screen You can view the status of your hybrid system on the multi-information display and the Remote Touch screen. Vehicles with 12.3-inch display: The energy monitor or consumption screen can be displayed on the side display. Multi-information display Remote Touch screen Meter control switches...
Page 108 2. Instrument cluster Energy monitor Remote Touch screen ■ Press the “MENU” button on the Remote Touch, then select on the “Menu” screen, and then select “Fuel Consumption”. If the “Trip Information” or “Past Record” screen is displayed, select “Energy”. Multi-information display ■...
Page 109 2. Instrument cluster Remote Touch screen Multi-information display When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Hybrid battery (traction battery) status Full Full These images are examples only, and may vary slightly from actual conditions. GS450h_OM_OM30E99U_(U)
Page 110 2. Instrument cluster Consumption Press the “MENU” button on the Remote Touch, then select on the “Menu” screen, and then select “Fuel Consumption”. Trip information ■ If the “Energy Monitor” or “Past Record” screen is displayed, select “Trip Infor- mation”. Resetting the consumption data Fuel consumption in the past 15 minutes...
Page 111 2. Instrument cluster Past record ■ If the “Energy Monitor” or “Trip Information” screen is displayed, select “Past Record”. Resetting the past record data Best recorded fuel consumption Average fuel consumption Previous fuel consumption record Updating the average fuel con- sumption data The average fuel consumption his- tory is divided by color into past...
Page 112 2. Instrument cluster Using the side display Vehicle information can be displayed on the side display (P. 284), then select to select the desired screen. Fuel consumption  Displays the average fuel consumption and regenerated energy for the past 10 minutes in 1 minute intervals, as well as the cruising range.
Page 113 2. Instrument cluster Energy monitor  Displays the hybrid system operation and energy recovery states. The image is an example only, and may vary slightly from actual conditions. GS450h_OM_OM30E99U_(U)
Page 114 2. Instrument cluster GS450h_OM_OM30E99U_(U)
Page 115: Operation Of Each Component
Operation of each component 3-1. Key information Keys ............116 3-2. Opening, closing and locking the doors and trunk Doors ..........120 Trunk..........126 Smart access system with push-button start .... 133 3-3. Adjusting the seats Front seats........141 Driving position memory..143 Head restraints ......
Page 116: 3-1. Key Information
Wireless remote control Locks all the doors (P. 120) Unlocks all the doors Opens the windows and moon roof (P. 120) Opens the trunk (P. 127) Sounds the alarm (P. 117) : This setting must be customized at your Lexus dealer. GS450h_OM_OM30E99U_(U)
Page 117 If you lose your mechanical keys ■ New genuine mechanical keys can be made by your Lexus dealer using the other mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 118 ■ P. 377 Confirmation of the registered key number ■ The number of keys already registered to the vehicle can be confirmed. Ask your Lexus dealer for details. If a wrong key is used ■ The key cylinder rotates freely to isolate inside mechanism.
Page 119 In case of a smart access system with push-button start malfunction or other key- ■ related problems Take your vehicle with all the electronic keys provided with your vehicle to your Lexus dealer. When an electronic key is lost ■...
Page 120: 3-2. Opening, Closing And Locking The Doors And Trunk
Pressing the button unlocks the driver’ s door. Pressing the button again within 5 seconds unlocks the other doors. Press and hold to open the windows and moon roof. : This setting must be customized at your Lexus dealer. GS450h_OM_OM30E99U_(U)
Page 121 3-2. Opening, closing and locking the doors and trunk Operation signals ■ A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: once; Unlocked: twice) Security feature ■ If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again.
Page 122 3-2. Opening, closing and locking the doors and trunk Unlocking and locking the doors from the inside ◆ Door lock switches Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
Page 123 3-2. Opening, closing and locking the doors and trunk Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent chil- dren from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Page 124 3-2. Opening, closing and locking the doors and trunk Switching the door unlock function ■ It is possible to set which doors the entry function unlocks using the wireless remote con- trol. Turn the power switch off. When the indicator light on the key surface is not on, press and hold for approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
Page 125 3-2. Opening, closing and locking the doors and trunk WARNING To prevent an accident ■ Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant throwing out of the vehi- cle, resulting in death or serious injury.
Page 126: Trunk
3-2. Opening, closing and locking the doors and trunk Trunk The trunk can be opened using the trunk opener, entry function or wireless remote control. If the vehicle is equipped with a power trunk opener and closer, the trunk can be closed using the trunk closer.
Page 127 3-2. Opening, closing and locking the doors and trunk ◆ Wireless remote control Press and hold the switch. If the vehicle is equipped with a power trunk lid, the trunk lid auto- matically opens fully. Trunk closer switch (vehicles with power trunk opener and closer) Pressing the switch closes the trunk lid automatically.
Page 128 3-2. Opening, closing and locking the doors and trunk Luggage security system The trunk opener switch can be temporarily disabled to protect luggage stored in the trunk against theft. Turn the main switch in the glove box off to disable the trunk opener. The trunk lid cannot be opened even with the wireless remote control or the trunk release button.
Page 129 3-2. Opening, closing and locking the doors and trunk Internal trunk release lever ■ The trunk lid can be opened by pulling the glow- in-the-dark lever located on the inside of the trunk lid to the side. The lever will continue to glow for some time after the trunk lid is closed.
Page 130 Do not attach any accessories other than genuine Lexus parts to the trunk lid. Such ● additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Page 131 • When the 12-volt battery voltage suddenly drops, such as when the power switch is turned to ON mode or the hybrid system is started during automatic operation Do not attach any accessories other than genuine Lexus parts to the trunk lid. The ●...
Page 132 3-2. Opening, closing and locking the doors and trunk NOTICE To prevent trunk easy closer malfunctions ■ Do not apply force to the trunk lid while the trunk easy closer is operating. To prevent damage to the power trunk opener and closer (vehicles with power trunk ■...
Page 133: Smart Access System With Push-Button Start
3-2. Opening, closing and locking the doors and trunk Smart access system with push-button start The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. Locks and unlocks the doors (P.
Page 134 3-2. Opening, closing and locking the doors and trunk Alarms and warning indicators ■ An alarm sounds and warning message displays shown on the multi-information display are used to protect against unexpected accidents or theft of the vehicle resulting from erroneous operation.
Page 135 3-2. Opening, closing and locking the doors and trunk Electronic Key Battery-Saving Function ■ When battery-saving mode is set, battery depletion is minimized by stopping the elec- tronic key from receiving radio waves. Press twice while pressing and holding . Confirm that the electronic key indica- tor flashes 4 times.
Page 136 3-2. Opening, closing and locking the doors and trunk Note for the entry function ■ Even when the electronic key is within the effective range (detection areas), the system ● may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 137 3-2. Opening, closing and locking the doors and trunk When the vehicle is not driven for extended periods ■ To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the ● vehicle. The smart access system with push-button start can be deactivated in advance.
Page 138 3-2. Opening, closing and locking the doors and trunk Certification for the smart access system with push-button start ■ For vehicles sold in the U.S. mainland, Hawaii, Guam and Puerto Rico  GS450h_OM_OM30E99U_(U)
Page 139 3-2. Opening, closing and locking the doors and trunk For vehicles sold in Canada  GS450h_OM_OM30E99U_(U)
Page 140 The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Lexus dealer for details, such as the frequency of radio waves and timing of the emitted radio waves. Then, consult your doctor to see if you should disable the entry function.
Page 141: Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Seat position adjustment switch Lumbar support adjustment switch Seatback angle adjustment switch Pelvic support adjustment switch (if equipped) Seat cushion (front) angle adjust- ment switch Seat cushion length adjustment switch (if equipped) Vertical height adjustment switch Seatback side support adjustment Seatback upper angle adjustment...
Page 142 3-3. Adjusting the seats When adjusting the seat ■ Take care when adjusting the seat so that the head restraint does not touch the ceiling. Power easy access system ■ The driver’ s seat and steering wheel move in accordance with power switch mode and the driver’...
Page 143: Driving Position Memory
3-3. Adjusting the seats Driving position memory This feature automatically adjusts the front seats, steering wheel and outside rear view mirrors to make entering and exiting the vehicle easier or to suit your preferences. Power easy access system The seat and steering wheel are automatically adjusted to allow the driver or front passenger to enter and exit the vehicle easily.
Page 144 3-3. Adjusting the seats Driving position memory Your preferred driving position (the position of the driver’ s seat, steering wheel, outside rear view mirrors and HUD [head-up display] [if equipped]) can be recorded and recalled by pressing a button. Three different driving positions can be recorded into memory. Recording procedure ■...
Page 145 3-3. Adjusting the seats To stop the position recall operation part-way through ■ Perform any of the following: Press the “SET” button. ● Press button “1”, “2” or “3”. ● Operate any of the seat adjustment switches (only cancels seat position recall). ●...
Page 146 3-3. Adjusting the seats While pressing the recalled but- ton, press and hold the door lock switch (either lock or unlock) until the buzzer sounds. If the button could not be registered, the buzzer sounds continuously for approximately 3 seconds. Recall procedure ■...
Page 147 3-3. Adjusting the seats WARNING Seat adjustment caution ■ Take care during seat adjustment so that the seat does not strike the rear passenger or squeeze your body against the steering wheel. GS450h_OM_OM30E99U_(U)
Page 148: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment  Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Horizontal adjustment (if equipped) Side support adjustment ...
Page 149 3-3. Adjusting the seats Rear seats Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Removing the head restraints ■ Pull the head restraint up while pressing the lock release button.
Page 150 3-3. Adjusting the seats Adjusting the height of the head restraints ■ Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. Adjusting the rear seat head restraints ■...
Page 151: Adjusting The Steering Wheel And Mirrors
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Operating the switch moves the steering wheel in the following directions: Down Toward the driver Away from the driver Horn To sound the horn, press on or close to mark.
Page 152: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable sufficient confirma- tion of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture. Adjust the height of the rear view mir- ror by moving it up and down.
Page 153 3-4. Adjusting the steering wheel and mirrors To prevent sensor error ■ To ensure that the sensors operate properly, do not touch or cover them. WARNING Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.
Page 154: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right Pressing the same switch again will put the switch in neutral. To adjust the mirror, press the switch. Right Down Left...
Page 155 3-4. Adjusting the steering wheel and mirrors Automatically folding and extending the mirrors (if equipped) Using the switch ■ Press the switch to fold the mirrors. Press it again to extend them to the original position. Setting automatic mode ■ Automatic mode allows the folding or extending of the mirrors to be linked to locking/unlocking of the...
Page 156 3-4. Adjusting the steering wheel and mirrors Linked mirror function when reversing When either “L” or “R” of the mirror select switch is selected, the outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground. To disable this function, select neither “L”...
Page 157 3-4. Adjusting the steering wheel and mirrors WARNING Important points while driving ■ Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, result- ing in death or serious injury. Do not adjust the mirrors while driving.
Page 158: 3-5. Opening, Closing The Windows And Moon Roof
3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, operate the switch in the opposite direction.
Page 159 The power windows can be opened using the wireless remote control. (P. 120) ● : These settings must be customized at your Lexus dealer. When the 12-volt battery is disconnected ■ The window lock switch is disabled. If necessary, press the window lock switch after reconnecting the 12-volt battery.
Page 160 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may result in death or serious injury. Closing the windows ■ The driver is responsible for all the power window operations, including the operation ●...
Page 161: Moon Roof
3-5. Opening, closing the windows and moon roof Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 162 ● The moon roof can be opened using the wireless remote control. (P. 120) ● : These settings must be customized at your Lexus dealer. When the moon roof does not close normally ■ Perform the following procedure: If the moon roof closes but then re-opens slightly ●...
Page 163 3-5. Opening, closing the windows and moon roof Moon roof open warning buzzer ■ The buzzer sounds and a message is shown on the multi-information display in the instru- ment cluster when the power switch is turned off and the driver’ s door is opened with the moon roof open.
Page 164 3-5. Opening, closing the windows and moon roof GS450h_OM_OM30E99U_(U)
Page 165: Driving
Driving the vehicle...... 166 Opening the fuel tank cap ..210 Cargo and luggage.....174 4-5. Using the driving support systems Vehicle load limits ......177 Lexus Safety System+ ....214 Trailer towing......... 178 Dinghy towing....... 179 (Pre-Collision System)..220 4-2. Driving procedures LKA (Lane-Keeping Power (ignition) switch....180...
Page 166: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the hybrid system P. 180 Driving With the brake pedal depressed, shift the shift lever to D. (P. 187) If the parking brake is in manual mode, release the parking brake. (P. 193) Gradually release the brake pedal and gently depress the accelerator pedal to accelerate the vehicle.
Page 167 In such case, deactivate TRAC (P. 268) to cancel Drive- Start Control so that the vehicle may become able to escape from the mud or fresh snow. Breaking in your new Lexus ■ To extend the life of the vehicle, observing the following precautions is recommended: For the first 186 miles (300 km): ●...
Page 168 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Lexus dealer perform the bedding down operation.
Page 169 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. When starting the vehicle ■ Always keep your foot on the brake pedal while stopped with the “READY” indicator is illuminated. This prevents the vehicle from creeping. When driving the vehicle ■...
Page 170 If you hear a squealing or scraping noise (brake pad wear limit indicators) ■ Have the brake pads checked and replaced by your Lexus dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 171 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. When the vehicle is stopped ■ Do not depress the accelerator pedal unnecessarily. ● If the shift lever is any position other than P or N, the vehicle may accelerate suddenly and unexpectedly, causing an accident.
Page 172 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. When taking a nap in the vehicle ■ Always turn the hybrid system off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to hybrid system overheating.
Page 173 Engine damage caused by water immersion ● In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Lexus dealer check the following: Brake function ● Changes in quantity and quality of oil and fluid used for the engine, hybrid transmis- ●...
Page 174: Cargo And Luggage
Consult this manual to determine how this reduces the avail- able cargo and luggage load capacity of your vehicle. (P. 177) Lexus does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing.
Page 175 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 466) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb. (kg), the avail- able amount of cargo and luggage load capacity will be C lb.
Page 176 4-1. Before driving WARNING Things that must not be carried in the trunk ■ The following things may cause a fire if loaded in the trunk: Receptacles containing gasoline ● Aerosol cans ● Storage precautions ■ Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’...
Page 177: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. ◆ Towing capacity Lexus does not recommend towing a trailer with your vehicle. ◆ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 178: Trailer Towing
4-1. Before driving Trailer towing Lexus does not recommend towing a trailer with your vehicle. Lexus also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicycle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 179: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle ■ Do not tow your vehicle with the four wheels on the ground. GS450h_OM_OM30E99U_(U)
Page 180: 4-2. Driving Procedures
4-2. Driving procedures Power (ignition) switch Performing the following operations when carrying the electronic key on your person starts the hybrid system or changes power switch modes. Starting the hybrid system Press the parking brake switch to check that the parking brake is set. (P. 193) Parking brake indicator will come on.
Page 181 4-2. Driving procedures Stopping the hybrid system Stop the vehicle completely. Shift the shift lever to P. Set the parking brake. (P. 193) Press the power switch. Release the brake pedal and check that “POWER ON” on the multi-informa- tion display is off. Changing power switch modes Modes can be changed by pressing the power switch with brake pedal released.
Page 182 ■ The immobilizer system may not have been deactivated. (P. 74) ● Contact your Lexus dealer. Check that the shift lever is securely set in P. The hybrid system may not start if the shift ● lever is displaced out of P. “Shift to P position to Start” will be displayed on the multi- information display.
Page 183 When “Check Access System with Elec. Key” will be displayed on the multi-informa- ■ tion display The system may be malfunctioning. Have the vehicle inspected by your Lexus dealer immediately. If the “READY” indicator does not come on ■...
Page 184 ACCESSORY mode. If the vehicle is left in ACCESSORY mode, 12-volt battery discharge may occur. When starting the hybrid system ■ If the hybrid system becomes difficult to start, have your vehicle checked by your Lexus dealer immediately. Symptoms indicating a malfunction with the power switch ■...
Page 185: Ev Drive Mode
4-2. Driving procedures EV drive mode In EV drive mode, electric power is supplied by the hybrid battery (traction battery), and only the electric motor (traction motor) is used to drive the vehi- cle. This mode allows you to drive in residential areas early in the morning and late at night, or in indoor parking lots etc.
Page 186 4-2. Driving procedures Switching to EV drive mode when the gasoline engine is cold ■ If the hybrid system is started while the gasoline engine is cold, the gasoline engine will start automatically in order to warm up. In this case, you will become unable to switch to EV drive mode.
Page 187: Hybrid Transmission
4-2. Driving procedures Hybrid transmission Shifting the shift lever While the power switch is in ON mode, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is com- pletely stopped.
Page 188 4-2. Driving procedures Selecting the driving mode Sport mode/Eco drive mode ■ P. 256 Snow mode ■ Snow mode can be selected to suit the conditions when driving on slippery road surfaces, such as on snow. Press the switch. Press the switch again to return to normal mode.
Page 189 4-2. Driving procedures Selecting shift ranges in the D position To drive using temporary shift range selection, operate the “-” or “+” paddle shift switch. When the “-” paddle shift switch is operated, the shift range will be downshifted to a range that enables engine braking force that is suitable to driving conditions. When the “+”...
Page 190 4-2. Driving procedures Selecting shift ranges in the S position To enter S mode, shift the shift lever to S. Shift ranges can be selected by operat- ing the shift lever or paddle shift switches, allowing you to drive in the shift range of your choosing.
Page 191 4-2. Driving procedures Automatic deactivation of shift range selection in the D position ■ Shift range selection in the D position will be deactivated in the following situations: When the vehicle comes to a stop ● If the accelerator pedal is depressed for more than a certain period of time ●...
Page 192: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions The lever will return to its original position immediately after operation. Right turn Lane change to the right (move the lever partway and release it) The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release it) The left hand signals will flash 3 times.
Page 193: Parking Brake
4-2. Driving procedures Parking brake A selections can be made as desired from the following modes. Manual mode Sets the parking brake The parking brake indicator light will come on. (P. 194) Press and hold the parking brake switch if an emergency occurs and it is neces- sary to operate the parking brake while driving.
Page 194 4-2. Driving procedures Parking brake operation ■ When the power switch is not in ON mode, the parking brake cannot be released using ● the parking brake switch. When the power switch is not in ON mode, automatic mode (automatic brake setting ●...
Page 195: Brake Hold
4-2. Driving procedures Brake Hold The brake hold system keeps the brake applied when the shift lever is in D, S or N with the system on and the brake pedal has been depressed to stop the vehi- cle. The system releases the brake when the accelerator pedal is depressed with the shift lever in D or S to allow smooth start off.
Page 196 4-2. Driving procedures When the parking brake is set automatically while the system is holding the brakes ■ The parking brake will not be released automatically. Perform one of the following proce- dures to release the parking brake and confirm that the parking brake indicator light turns off.
Page 197: Operating The Lights And Wipers
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: The side marker, parking, tail, license plate and instrument panel lights turn on. U.S.A.
Page 198 4-3. Operating the lights and wipers AFS (Adaptive Front-lighting System) (if equipped) AFS (Adaptive Front-lighting System) secures excellent visibility at intersections and on curves by automatically adjusting the direction of the light axis of the headlights according to vehicle speed and the degree of the tire’ s angle as con- trolled by steering input.
Page 199 If the “AFS OFF” indicator flashes ■ It may indicate a malfunction in the system. Contact your Lexus dealer. Customization ■ Settings (e.g. light sensor sensitivity) can be changed.
Page 200: Automatic High Beam
4-3. Operating the lights and wipers  Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of vehicles ahead, etc., and automatically turns the high beam on or off as necessary. WARNING Limitations of the Automatic High Beam ■...
Page 201 4-3. Operating the lights and wipers Turning the high beam on/off manually Switching to low beam ■ Pull the lever to the original position. The Automatic High Beam indicator will turn off. Push the lever away from you to acti- vate the Automatic High Beam sys- tem again.
Page 202 4-3. Operating the lights and wipers High beam automatic turning on or off conditions ■ When all of the following conditions are fulfilled, the high beam will be automatically ● turned on: • Vehicle speed is above approximately 21 mph (34 km/h). •...
Page 203 4-3. Operating the lights and wipers In the situations shown below, the system may not be able to accurately detect sur- ● rounding brightness levels. This may cause the low beams to remain on or the high beams to cause problems for pedestrians, vehicles ahead or other parties. In these cases, manually switch between the high and low beams.
Page 204: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever Operate the lever as follows to operate the wipers. The lever will return to its original position immediately after operation. (U.S.A.) (Canada) Move the lever up 2 levels Move the lever up 1 level (U.S.A.) (Canada)
Page 205: Gs450H_Om_Om30E99U_(U
4-3. Operating the lights and wipers When AUTO mode is selected, the sensor sensitivity can be adjusted by turning the switch ring. Increases the sensitivity Decreases the sensitivity Washer/wiper dual operation Wipers will automatically operate a cou- ple of times after the washer squirts. Vehicles with headlight cleaners: When the headlights are on and the lever is pulled and held, the headlight...
Page 206: Gs450H_Om_Om30E99U_(U
4-3. Operating the lights and wipers Operating the intermittent windshield wipers ■ (U.S.A.) (Canada) Move the lever up 2 levels Move the lever up 1 level (U.S.A.) (Canada) Move the lever down 1 level (U.S.A.) (Canada) Move the lever down 2 lev- Operation Status before...
Page 207: Gs450H_Om_Om30E99U_(U
4-3. Operating the lights and wipers Wiper intervals can be adjusted when intermittent operation is selected. Increases the intermittent windshield wiper frequency Decreases the intermittent wind- shield wiper frequency Washer/wiper dual operation Wipers will automatically operate a cou- ple of times after the washer squirts. Vehicles with headlight cleaners: When the headlights are on and the lever is pulled and held, the headlight...
Page 208: Gs450H_Om_Om30E99U_(U
4-3. Operating the lights and wipers Raindrop sensor ■ The raindrop sensor judges the amount of ● raindrops. An optical sensor is adopted. It may not oper- ate properly when sunlight from the rising or setting of the sun intermittently strikes the windshield, or if bugs etc.
Page 209 Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. When a nozzle becomes blocked ■ In this case, contact your Lexus dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. When standing the windshield wipers up ■...
Page 210: 4-4. Refueling
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle Turn the power switch off and ensure that all the doors and windows are ● closed. Confirm the type of fuel. ●...
Page 211 4-4. Refueling NOTICE Refueling ■ Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally or damaging fuel system components or the vehicle’ s painted sur- face. Opening the fuel tank cap With the doors unlocked, press the center of the rear edge of the fuel filler door.
Page 212 4-4. Refueling When the fuel filler door cannot be opened by pressing the rearward of the fuel filler ■ door Remove the cover inside the trunk and pull the lever. Closing the fuel tank cap After refueling, turn the fuel tank cap until you hear a click.
Page 213 When replacing the fuel tank cap ■ Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury. GS450h_OM_OM30E99U_(U)
Page 214: 4-5. Using The Driving Support Systems
Lexus Safety System+ ■ The Lexus Safety System+ is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 215 Data usage ● Lexus may use the data recorded in this computer to diagnose malfunctions, conduct research and development, and improve quality. Lexus will not disclose the recorded data to a third party except: •...
Page 216 Do not subject the radar sensor or surrounding area to a strong impact. ● If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Lexus dealer. Do not disassemble the radar sensor. ●...
Page 217 ● of the camera sensor by the windshield wipers, replace the wiper insert or wiper blade. If the wiper inserts or wiper blades need to be replaced, contact your Lexus dealer. Do not attach window tinting to the windshield. ●...
Page 218 Do not attach any accessories that may obstruct the camera sensor to the hood, front ● grille or front bumper. Contact your Lexus dealer for details. If a surfboard or other long object is to be mounted on the roof, make sure that it will ●...
Page 219 4-5. Using the driving support systems For vehicles sold in Canada  GS450h_OM_OM30E99U_(U)
Page 220: (Pre-Collision System)
(P. 223) : Depending on the region in which the vehicle was sold, the pedestrian detection function may not be available. Contact your Lexus dealer for details. : Depending on the region in which the vehicle was sold, the pre-collision braking function (automatic braking function) may not be available.
Page 221 4-5. Using the driving support systems ◆ Pre-collision braking When the system determines that the possibility of a frontal collision is high, the system warns the driver. If the system determines that the possibility of a collision is extremely high, the brakes are automatically applied to help avoid the collision or reduce the collision speed.
Page 222 4-5. Using the driving support systems WARNING Pre-collision braking ■ The pre-collision braking function may not operate if certain operations are per- ● formed by the driver. If the accelerator pedal is being depressed strongly or the steer- ing wheel is being turned, the system may determine that the driver is taking evasive action and possibly prevent the pre-collision braking function from operating.
Page 223 4-5. Using the driving support systems Changing settings of the pre-collision system Enabling/disabling the pre-collision system ■ The pre-collision system can be enabled/disabled on (P. 93) of the multi-information display. The system is automatically enabled each time the power switch is turned to ON mode.
Page 224 4-5. Using the driving support systems Operational conditions ■ Availability of the pedestrian detection function and pre-collision braking function depend on the region in which the vehicle was sold. Regions Function availability The pedestrian detection function and pre-collision braking Region A function are available The pedestrian detection function is not available and the pre- Region B...
Page 225 4-5. Using the driving support systems Region B  (The pedestrian detection function is not available and the pre-collision braking func- tion is available) The pre-collision system is enabled and the system determines that the possibility of a frontal collision with a vehicle is high. Each function is operational at the following speeds: Pre-collision warning: ●...
Page 226 4-5. Using the driving support systems Pedestrian detection function ■ The pre-collision system detects pedestrians based on the size, profile, and motion of a detected object. However, a pedestrian may not be detected depending on the surrounding brightness and the motion, posture, and angle of the detected object, preventing the system from operating properly.
Page 227 4-5. Using the driving support systems • When driving on a road where relative location to vehicle ahead in an adjacent lane may change, such as on a winding road • When a preceding vehicle suddenly decelerates • If the front of the vehicle is raised or lowered, such as when the road surface is uneven or undulating •...
Page 228 4-5. Using the driving support systems • When passing under an object (billboard, etc.) at the top of an uphill road • When rapidly closing on an electric toll gate barrier, parking area barrier, or other barrier that opens and closes •...
Page 229 4-5. Using the driving support systems Situations in which the system may not operate properly ■ In some situations such as the following, a vehicle may not be detected by the radar ● sensor and camera sensor, preventing the system from operating properly: •...
Page 230 4-5. Using the driving support systems • After the hybrid system has started the vehicle has not been driven for a certain amount of time • While making a left/right turn and for a few seconds after making a left/right turn •...
Page 231 If the PCS warning light continues to flash or the warning message does not disappear, ● the system may be malfunctioning. Have the vehicle inspected by your Lexus dealer immediately. If VSC is disabled ■...
Page 232: Lka (Lane-Keeping Assist)
4-5. Using the driving support systems  LKA (Lane-Keeping Assist) Summary of functions When driving on highways and freeways with white or yellow lines, this function alerts the driver when the vehicle might depart from its lane and provides assis- tance by operating the steering wheel to keep the vehicle in its lane.
Page 233 4-5. Using the driving support systems ◆ Lane departure control function When the system determines that the vehicle might depart from its lane, the system provides assistance as necessary by operating the steer- ing wheel in small amounts for a short period of time to keep the vehicle in its lane.
Page 234 4-5. Using the driving support systems ◆ Lane centering function This function is linked with radar cruise control and provides the required assistance by operating the steering wheel to keep the vehicle in its current lane. When radar cruise control is not operating, the lane centering func- tion does not operate.
Page 235 ● tact your Lexus dealer. Do not install or place anything on the hood or grille. Also, do not install a grille guard ● (bull bars, kangaroo bar, etc.). If your windshield needs repairs, contact your Lexus dealer. ● GS450h_OM_OM30E99U_(U)
Page 236 4-5. Using the driving support systems Turning LKA system on Press the LKA switch to turn the LKA system on. The LKA indicator illuminates and a message is displayed on the multi-infor- mation display. Press the LKA switch again to turn the LKA system off.
Page 237 4-5. Using the driving support systems Lane departure alert function display Displayed when the multi-information display is switched to the driving assist system information screen. Inside of displayed white lines is Inside of displayed white lines is   white black Indicates that the system is recognizing Indicates that the system is not able to...
Page 238 4-5. Using the driving support systems Vehicle sway warning ● This function operates when all of the following conditions are met. • Setting for “Sway Warning” in of the multi-information display is set to “On”. (P. 93) • Vehicle speed is approximately 32 mph (50 km/h) or more. •...
Page 239 4-5. Using the driving support systems Hands off steering wheel alert ■ When the system determines that the driver has removed their hands from the steering wheel while the lane departure control function or lane centering function is operating, a warning message is displayed on the multi-information display and the buzzer sounds.
Page 240 4-5. Using the driving support systems The headlight lenses are dirty and emit a faint amount of light at night, or the beam axis ● has deviated. The vehicle is struck by a crosswind. ● The vehicle has just changed lanes or crossed an intersection. ●...
Page 241: Dynamic Radar Cruise Control With Full-Speed Range
4-5. Using the driving support systems Dynamic radar cruise controlwith full-speed  range Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically acceler- ates, decelerates and stops to match the speed changes of the preceding vehicle even if the accelerator pedal is not depressed. In constant speed control mode, the vehicle runs at a fixed speed.
Page 242 4-5. Using the driving support systems WARNING Before using dynamic radar cruise control with full-speed range ■ Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your surroundings. The dynamic radar cruise control with full-speed range provides driving assistance to reduce the driver’...
Page 243 4-5. Using the driving support systems WARNING Situations unsuitable for dynamic radar cruise control with full-speed range ■ Do not use dynamic radar cruise control with full-speed range in any of the following situations. Doing so may result in inappropriate speed control and could cause an accident result- ing in death or serious injury.
Page 244 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suitable following distance from the vehicle ahead.
Page 245 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON/OFF” button to acti- vate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deactivate the cruise control.
Page 246 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is dis- played. Increases the speed (Except when the vehicle has been stopped by system control in vehicle-to- vehicle distance control mode) Decreases the speed Fine adjustment: Momentarily move...
Page 247 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle distance control mode) Pressing the button changes the vehi- Preceding cle-to-vehicle distance as follows: vehicle mark Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the power switch is turned to ON mode.
Page 248 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the speed control. The speed control is also canceled when the brake pedal is depressed. (When the vehicle has been stopped by system control, depressing the brake pedal does not cancel the setting.) Pushing the lever up resumes the...
Page 249 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will maintain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 250 • The driver’ s door is opened. • The vehicle has been stopped for about 3 minutes If vehicle-to-vehicle distance control mode is automatically canceled for any other rea- son, there may be a malfunction in the system. Contact your Lexus dealer. GS450h_OM_OM30E99U_(U)
Page 251 Pre-collision braking is activated. ● If constant speed control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Lexus dealer. Warning messages and buzzers for dynamic radar cruise control with full-speed range ■...
Page 252 4-5. Using the driving support systems Preceding vehicle has an extremely high ● ground clearance Conditions under which the vehicle-to-vehicle distance control mode may not function ■ correctly In the case of the following conditions, operate the brake pedal (or accelerator pedal, depending on the situation) as necessary.
Page 253: Cruise Control
4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelera- tor pedal. Set speed Indicators Cruise control switch Setting the vehicle speed Press the “ON/OFF” button to acti- vate the cruise control.
Page 254 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction. Large adjustment: Hold the lever in the desired direction.
Page 255 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehi- cle inspected by your Lexus dealer. WARNING To avoid operating the cruise control by mistake ■...
Page 256: Driving Mode Select Switch
4-5. Using the driving support systems Driving mode select switch The driving modes can be selected to suit driving condition. Except F SPORT models F SPORT models Normal mode/Customized mode Normal mode and customized mode are selected by pressing the driving mode select switch.
Page 257 4-5. Using the driving support systems Sport mode • SPORT S mode Assists acceleration response by controlling the transmission and engine. When not in SPORT S mode and the driving mode select switch is turned to the right, the “SPORT S” indicator comes on in the multi-information display, and the Hybrid System Indicator changes to the tachometer.
Page 258: (Blind Spot Monitor)
4-5. Using the driving support systems  BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; The Blind Spot Monitor function ● Assists the driver in making the decision when changing lanes The Rear Cross Traffic Alert function ●...
Page 259: The Blind Spot Monitor
4-5. Using the driving support systems The outside rear view mirror indicators visibility ■ When under strong sunlight, the outside rear view mirror indicator may be difficult to see. Rear Cross Traffic Alert buzzer hearing ■ Rear Cross Traffic Alert function may be difficult to hear over loud noises such as high audio volume.
Page 260: The Blind Spot Monitor
If the sensor or surrounding area is subject to a strong impact, always have the area inspected by your Lexus dealer. Do not disassemble the sensor.
Page 261: The Blind Spot Monitor Function
4-5. Using the driving support systems The Blind Spot Monitor function The Blind Spot Monitor function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicle’...
Page 262 4-5. Using the driving support systems The Blind Spot Monitor function is operational when ■ The BSM function is turned on. ● Vehicle speed is greater than approximately 10 mph (16 km/h). ● The Blind Spot Monitor function will detect a vehicle when ■...
Page 263: The Rear Cross Traffic Alert Function
4-5. Using the driving support systems The Rear Cross Traffic Alert function The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehicle’...
Page 264 4-5. Using the driving support systems The Rear Cross Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away.
Page 265 4-5. Using the driving support systems Conditions under which the Rear Cross Traffic Alert function may not function cor- ■ rectly The Rear Cross Traffic Alert function may not detect vehicles correctly in the following conditions: During bad weather such as heavy rain, fog, snow etc. ●...
Page 266: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems oper- ate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle.
Page 267 When SPORT S+ mode is selected by the driving mode select switch, the damping force is suitable for sporty driving (P. 256) ◆ LDH (Lexus Dynamic Handling system) (if equipped) Provides independent control of the VGRS, DRS and EPS. Contributes to turning characteristics at low speeds, responsiveness at medium speeds and...
Page 268 4-5. Using the driving support systems When the TRAC/VSC/ABS systems are operating The slip indicator light will flash while the TRAC/VSC/ABS systems are operating. Disabling the TRAC system If the vehicle gets stuck in mud, dirt or snow, the TRAC system may reduce power from the hybrid system to the wheels.
Page 269 When the message is displayed on the multi-information display showing that TRAC ■ has been disabled even if has not been pressed TRAC and hill-start assist control cannot be operated. Contact your Lexus dealer. VGRS is disabled when ■ VGRS may stop operating in the following situations.
Page 270 4-5. Using the driving support systems ECB operation sound ■ ECB operating sound may be heard in the following cases, but it does not indicate that a malfunction has occurred. Operating sound heard from the engine compartment when the brake pedal is oper- ●...
Page 271 The ABS, TRAC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Lexus dealer for further information when replacing tires or wheels. Handling of tires and the suspension ■...
Page 272: 4-6. Driving Tips
4-6. Driving tips Hybrid vehicle driving tips For economical and ecological driving, pay attention to the following points: ◆ Using Eco drive mode When using Eco drive mode, the torque corresponding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 273 4-6. Driving tips ◆ Delays Repeated acceleration and deceleration, as well as long waits at traffic lights, will lead to bad fuel economy. Check traffic reports before leaving and avoid delays as much as possible. When driving in a traffic jam, gently release the brake pedal to allow the vehicle to move forward slightly while avoiding over- use of the accelerator pedal.
Page 274: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehi- cle in winter. Always drive the vehicle in a manner appropriate to the prevail- ing weather conditions. Preparation for winter Use fluids that are appropriate to the prevailing outside temperatures. ●...
Page 275 4-6. Driving tips When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road conditions. When parking the vehicle Park the vehicle and move the shift lever to P without setting the parking brake. The parking brake may freeze up, preventing it from being released.
Page 276 4-6. Driving tips Shifting the windshield wiper position If heavy snow or icy condition is expected, shift the rest position manually. Grip the hook section of the wiper arm firmly when shifting the wiper position. To rest position ■ Raise the wiper in line with the wind- shield.
Page 277 NOTICE Repairing or replacing snow tires ■ Request repairs or replacement of snow tires from Lexus dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the operation of the tire pressure warning valves and transmitters.
Page 278 4-6. Driving tips GS450h_OM_OM30E99U_(U)
Page 279: Interior Features
• Vanity mirrors ......312 • Clock ......... 313 • Power outlets ......313 • Armrest........315 • Rear sunshade/ rear door sunshades.... 316 • Coat hooks......318 • Assist grips....... 318 • Garage door opener ..319 LEXUS Enform Safety Connect........326 GS450h_OM_OM30E99U_(U)
Page 280 5-1. Remote Touch screen Remote Touch/12.3-inch display The Remote Touch can be used to operate the Remote Touch screens. Owners of models equipped with a navigation system should refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”. Remote Touch operation “•”...
Page 281 5-1. Remote Touch screen Using the Remote Touch knob ■ Select: Move the knob in the desired direction. Enter: Press the knob or “ENTER” button. Screen display during low temperatures ■ When the ambient temperature is extremely low, screen response may be delayed even if the Remote Touch is operated.
Page 282: Display
Select to display the media control screen. Select to display the hands-free operation screen. 1, 2 Select to display the “LEXUS App Suite” screen. Select to display the “Information” screen. Select to display the air conditioning control screen. (P. 285) Select to display the “Setup”...
Page 283 5-1. Remote Touch screen 12.3-inch display operation Full screen display ■ The following functions can be displayed full screen: Initial screen Map screen ● ● “Menu” screen (P. 282) ● : Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MAN- UAL”.
Page 284 5-1. Remote Touch screen 12.3-inch display function For details of the functions and operation of the main display, refer to the respec- tive section. Display the side display ■ Basic screens  The following functions can be displayed and operated on the side display. Select the desired button.
Page 285: Using The Air Conditioning System And Defogger
5-2. Using the air conditioning system and defogger Front automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temper- ature setting. Press the “MENU” button on the Remote Touch, then select to display the air conditioning operation screen. Vehicles with 12.3-inch display: The air conditioning system can be displayed and operated on the side display.
Page 286 5-2. Using the air conditioning system and defogger Adjusting the temperature setting ■ Press “”on to increase the temperature and “” to decrease the temper- ature. Without rear air conditioning system  When “DUAL” on the control screen is selected or the passenger’ s side tem- perature control button is pressed, the temperature for the driver and passen- ger seats can be adjusted separately.
Page 287 5-2. Using the air conditioning system and defogger Control screen Without rear air conditioning system With rear air conditioning system   Adjust the left-hand side temperature setting Select the air flow to the feet and operate the windshield defogger Adjust the fan speed setting Select the air flow mode (the front seats)
Page 288 5-2. Using the air conditioning system and defogger  Air flows to the upper body  Air flows to the upper body and feet  Air flows to the feet Option control screen ■ Select on the control screen to display the option control screen. The functions can be switched on and off.
Page 289 5-2. Using the air conditioning system and defogger Side display ■ Without rear air conditioning system With rear air conditioning system   Adjust the left-hand side temperature setting Select the air flow mode (the front seats) Adjust the fan speed setting Adjust the right-hand side temperature setting Adjust the temperature for the driver’...
Page 290 5-2. Using the air conditioning system and defogger Air conditioning control Using the automatic mode ■ Press or select “AUTO” on the control screen. Press to switch to automatic air intake mode. The air conditioning system automatically switches between outside air and recir- culated air modes.
Page 291: Other Functions
5-2. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes ■ Press The mode switches among (recirculated air mode), automatic and (outside air mode) modes each time the button is pressed. When the system is switched to automatic mode, the air conditioning system oper- ates automatically.
Page 292 5-2. Using the air conditioning system and defogger Changing the rear seat settings (with rear air conditioning system) Select on the control screen to display the rear air conditioning control screen. Using the automatic mode ■ Select “REAR AUTO” on the screen. The air conditioning system will operate, and air outlets and speed will be set auto- matically.
Page 293 Settings for the electronic key and the corresponding door can be changed. Contact ● your Lexus dealer. Using automatic mode ■ Fan speed is adjusted automatically according to the temperature setting and the ambi- ent conditions.
Page 294 5-2. Using the air conditioning system and defogger When the outside temperature exceeds 75°F (24°C) and the air conditioning system ■ is on In order to reduce the air conditioning power consumption, the air conditioning system ● may switch to recirculated air mode automatically. This may also reduce fuel consump- tion.
Page 295 5-2. Using the air conditioning system and defogger Air conditioning filter ■ P. 375 Customization ■ Settings (e.g. exhaust gas sensor sensitivity) can be changed. (Customizable features: P. 491) WARNING To prevent the windshield from fogging up ■ Do not use during cool air operation in extremely humid weather.
Page 296: Rear Air Conditioning System
5-2. Using the air conditioning system and defogger  Rear air conditioning system Air outlets and fan speed are automatically adjusted according to the temper- ature setting. Control panel Set automatic mode on/off Change the airflow mode Turn the fan off Adjust the temperature setting Adjusting the temperature setting ■...
Page 297 5-2. Using the air conditioning system and defogger Using automatic air conditioning system Press The air conditioning system will operate, and air outlets and fan speed will be adjusted automatically. “AUTO” will be displayed on the control panel. Adjust the temperature setting. When the rear seat heaters are set to “AUTO”...
Page 298 5-2. Using the air conditioning system and defogger Button lock function ■ To prevent inadvertent operation, the buttons on the rear armrest can be locked. Press until you hear a beep to lock the buttons. Press- again until you hear a beep will release the lock.
Page 299: Heated Steering Wheel/ Seat Heaters/Seat Ventilators
5-2. Using the air conditioning system and defogger Heated steering wheel/seat heaters/seat ventila- tors Heated steering wheel and seat heaters heat the side grips of the steering wheel and seats, respectively. Seat ventilators maintain good airflow by blow- ing air from the seats. WARNING Care should be taken to prevent injury if anyone in the following categories comes in ●...
Page 300 5-2. Using the air conditioning system and defogger Heated steering wheel Turns the heated steering wheel on/off The indicator light comes on when the heater is operating. The heated steering wheel can be used when the power switch is in ON mode. ●...
Page 301 5-2. Using the air conditioning system and defogger Modes and indicators ● The mode can be changed by pressing the switch. Mode “AUTO” indicator light Level indicator lights Automatic* 3 to 1, or off : When automatic mode is selected, the level automatically changes depending on the air conditioning settings.
Page 302: 5-3. Using The Interior Lights
5-3. Using the interior lights Interior lights list Outer foot lights Rear personal lights (P. 303) Rear interior light Shift lever light Ornament lights Front interior light (P. 303) Door courtesy lights Front personal lights (P. 303) Power window switch lights Inside door handle lights Footwell lights When the instrument panel light control switch is turned to minimum and the tail lights...
Page 303: Interior Lights
5-3. Using the interior lights Interior lights Turns the lights on/off The rear interior light is also turned on/ off. Turns the door position on/off Personal lights Front ■ Turns the light on/off Rear ■ Turns the light on/off GS450h_OM_OM30E99U_(U)
Page 304 5-3. Using the interior lights Illuminated entry system: The lights automatically turn on/off according to power switch ● mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed. If the interior lights remain on when the power switch is turned off, the lights will go off ●...
Page 305: Using The Storage Features
5-4. Using the storage features List of storage features Cup holders (P. 307) Auxiliary boxes (P. 309) Glove box (P. 306) Console box (P. 306) WARNING Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause ●...
Page 306: Glove Box
5-4. Using the storage features Glove box Open (press the button) Unlock with the mechanical key Lock with the mechanical key The glove box light turns on when the tail lights are on. ● The trunk opener main switch is located in the glove box. (P. 128) ●...
Page 307: Cup Holders
5-4. Using the storage features The tray slides forward/backward and can be ● removed. The console box light turns on when the tail lights are on. ● WARNING When using the console box with half-open, do not apply too much load on the arm- rest.
Page 308 5-4. Using the storage features Front cup holder: The cup holder insert may ● be removed for cleaning. Rear cup holder: When stowing the cup holder, stow the cup holder with the armrest ● down. The cup holder cannot be stowed if the armrest is not down. WARNING Do not place anything other than cups or beverage cans in the cup holders.
Page 309: Auxiliary Boxes
5-4. Using the storage features Auxiliary boxes Type A Type B   Press in the button. Pull up the lever to release the lock and lift the lid. Type C  Open the lid. WARNING Type C: Do not use the auxiliary box as an ashtray. Doing so may cause a fire.
Page 310: Trunk Features
5-4. Using the storage features Trunk features Cargo hooks Raise the hooks when needed. The cargo hooks are provided for securing loose items. WARNING To avoid injury, always return the cargo hooks to their stowed positions when not in use. Luggage hook Pull the strap when using the hook.
Page 311 5-4. Using the storage features First-aid kit storage net Luggage mat Pull the strap upwards to lift up the lug- gage mat. Warning reflector storage belt Loosen the belt Tighten the belt To prevent damage to the warning reflector storage belt when it is not in use, fold the belt (as shown in ) and secure it with the clip ( ).
Page 312: 5-5. Using The Other Interior Features
5-5. Using the other interior features Other interior features Sun visors To set the visor in the forward posi- tion, flip it down. To set the visor in the side position, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 313: Clock
5-5. Using the other interior features Clock The GPS clock’ s time is automatically adjusted by utilizing GPS time informa- tion. For details, refer to “NAVIGATION SYSTEM OWNER’S MANUAL”. Power outlets 12 V: Please use as a power supply for electronic goods that use less than 12 VDC/10 A (power consumption of 120 W).
Page 314 5-5. Using the other interior features 120 V AC (if equipped for rear only) ■ Open the lid. The power outlets can be used when ■ 12 V: The power switch is in ACCESSORY or ON mode. 120 V AC: The power switch is in ON mode. NOTICE To avoid damaging the power outlets, close the power outlet lids when the power out- ●...
Page 315: Armrest
5-5. Using the other interior features Armrest Fold down the armrest for use. NOTICE To prevent damage to the armrest, do not apply too much load on the armrest. GS450h_OM_OM30E99U_(U)
Page 316: Rear Sunshade
5-5. Using the other interior features Rear sunshade/rear door sunshades (If equipped) Rear sunshade ■ The rear sunshade can be raised and lowered by operating the button shown below. From the front seats From the rear seats (if equipped)  ...
Page 317 5-5. Using the other interior features The rear sunshade can be used when the power switch is in ON mode. ● The rear sunshade can be operated for approximately 1 minute even after the power ● switch is turned to ACCESSORY mode or turned off. Reverse operation feature: To ensure adequate rear visibility, the rear sunshade auto- ●...
Page 318: Coat Hooks
5-5. Using the other interior features Coat hooks The coat hooks are provided with the rear assist grips. WARNING Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS cur- tain shield airbags deploy, these items may become projectiles, causing death or seri- ous injury.
Page 319: Garage Door Opener
5-5. Using the other interior features Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® Programming HomeLink ® The HomeLink wireless control system in your vehicle has 3 buttons which can be programmed to operate 3 different devices.
Page 320 5-5. Using the other interior features ® Programming HomeLink ■ ® Press and release the HomeLink button you want to program and check ® that the HomeLink indicator light flashes (orange). Perform within 60 seconds of , or the indicator light will stop flashing and programming will not be able to be completed.
Page 321 5-5. Using the other interior features If the garage door or other device does not operate, proceed to “Pro- ● gramming a rolling code system”. Repeat the steps above to program another device for any of the remaining ® HomeLink buttons.
Page 322 5-5. Using the other interior features Enabling 2-way communication with a garage door (only available for com- ■ patible devices) When enabled, 2-way communication allows you to check the status of the opening and closing of a garage door through indicators in your vehicle. 2-way communication is only available if the garage door opener motor used is a compatible device.
Page 323 5-5. Using the other interior features Garage door operation indicators The status of the opening and closing of a garage door is shown by the indica- tors. Opening Closing This function is only available if the garage door opener motor used is a compatible device.
Page 324 5-5. Using the other interior features ® Codes stored in the HomeLink memory ■ The registered codes are not erased even if the battery cable is disconnected. ● ® If learning failed when registering a different code to a HomeLink button that already ●...
Page 325 5-5. Using the other interior features WARNING When programming a garage door or other remote control device ■ The garage door or other device may operate, so ensure people and objects are out of danger to prevent potential harm. Conforming to federal safety standards ■...
Page 326: Lexus Enform Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Lexus.com. All use of the Safety Connect service is subject to such then- applicable Terms and Conditions.
Page 327 After you have signed the Telematics Subscription Service Agreement and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Lexus dealer, call 1-800-25-LEXUS (1-800-255-3987) or push the “SOS” button in your vehicle for further subscription details.
Page 328 If your vehicle is stolen, Safety Connect can work with local authorities to assist them in locating and recovering the vehicle. After filing a police report, call the Safety Connect response center at 1-800-25-LEXUS (1-800-255- 3987) and follow the prompts for Safety Connect to initiate this service.
Page 329 For a description of the Roadside Assistance services and their limitations, please see the Safety Connect Terms and Conditions, which are available at Lexus.com. Safety information for Safety Connect Important! Read this information before using Safety Connect.
Page 330 5-5. Using the other interior features Certification for Lexus Enform ■ FCC ID: O6Y-CDMRF101 FCC ID: XOECDMRF101B FCC ID: N7NGTM2 FCC WARNING: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supple- ment C to OET65.
Page 331: Maintenance And Care
Maintenance and care 6-1. Maintenance and care 6-3. Do-it-yourself maintenance Cleaning and protecting Do-it-yourself service the vehicle exterior....332 precautions........345 Cleaning and protecting Hood ..........347 the vehicle interior ....336 Positioning a floor jack.....348 6-2. Maintenance Engine compartment ....349 Maintenance requirements ...339 12-volt battery......358 General maintenance ....
Page 332: Cleaning And Protecting The Vehicle Exterior
6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condi- tion: Working from top to bottom, liberally apply water to the vehicle body, wheel ● wells and underside of the vehicle to remove any dirt and dust. Wash the vehicle body using a sponge or soft cloth, such as a chamois.
Page 333 • Do not use wax or glass cleaners that contain abrasives when cleaning the windows. • Do not use any metallic objects to remove condensation build up. When the water-repellent performance has become insufficient, the coating can be ● repaired. Contact your Lexus dealer. GS450h_OM_OM30E99U_(U)
Page 334 Precaution regarding the rear bumper with Blind Spot Monitor (if equipped) ■ If the paint of the rear bumper is chipped or scratched, the system may malfunction. If this occurs, consult your Lexus dealer. GS450h_OM_OM30E99U_(U)
Page 335 6-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and components (aluminum ■ wheels etc.) Wash the vehicle immediately in the following cases: ● • After driving near the sea coast • After driving on salted roads •...
Page 336: Cleaning And Protecting The Vehicle Interior
6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 337 6-1. Maintenance and care Caring for leather areas ■ Lexus recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’ s interior. Shampooing the carpets ■ There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 338 Water may also cause the body to rust. When cleaning the inside of the windshield (vehicles with Lexus Safety System+) ■ Do not allow glass cleaner to contact the lens. Also, do not touch the lens. (P. 216) Cleaning the inside of the rear window ■...
Page 339: Maintenance
It is recommended that genuine Lexus parts be used for repairs to ensure performance of each system. If non-Lexus parts are used in replacement or if a repair shop other than a Lexus dealer performs repairs, confirm the warranty coverage.
Page 340 Allow inspection and repairs to be performed by a Lexus dealer ■ Lexus technicians are well-trained specialists and are kept up to date with the latest ser- ● vice information. They are well informed about the operations of all systems on your vehicle.
Page 341: General Maintenance
Listed below are the general maintenance items that should be performed at the intervals specified in the “Warranty and Service Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Lexus dealer or qualified service shop for advice. Engine compartment...
Page 342: Vehicle Interior
6-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly Accelerator pedal (without uneven pedal effort or catching). Hybrid transmission “Park” • When parked on a slope and the shift lever is in P, mechanism is the vehicle securely stopped? •...
Page 343: Vehicle Exterior
6-2. Maintenance Vehicle exterior Items Check points Doors/trunk • Do the doors/trunk operate smoothly? • Does the engine hood lock system work prop- Engine hood erly? • There should not be any signs of fluid leakage Fluid leaks after the vehicle has been parked. •...
Page 344: Emission Inspection And Maintenance (I/M) Programs
The error code in the OBD system will not be cleared unless the vehicle is driven 40 or more times. If your vehicle does not pass the I/M test Contact your Lexus dealer to prepare the vehicle for re-testing. GS450h_OM_OM30E99U_(U)
Page 345: 6-3. Do-It-Yourself Maintenance
6-3. Do-it-yourself maintenance Do-it-yourself service precautions If you perform maintenance by yourself, be sure to follow the correct proce- dure as given in these sections. Items Parts and tools • Grease 12-volt battery con- dition (P. 358) • Conventional wrench (for terminal clamp bolts) •...
Page 346 6-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. When working on the engine compartment ■ Make sure that the “POWER ON” on the multi-information display and the ●...
Page 347: Hood
6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. WARNING Pre-driving check ■...
Page 348: Positioning A Floor Jack
6-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack correctly. Improper placement may damage your vehicle or cause injury. ◆...
Page 349: Engine Compartment
6-3. Do-it-yourself maintenance Engine compartment Engine oil level dipstick Brake fluid reservoir (P. 351) (P. 356) Engine coolant reservoir Fuse box (P. 379) (P. 354) Washer fluid tank (P. 357) Engine oil filler cap (P. 352) Electric cooling fans Power control unit coolant Condenser (P.
Page 350 6-3. Do-it-yourself maintenance Engine compartment cover Removing the engine compartment cover ■ Right-hand side  Center  Installing the clips ■ Push up center portion Insert Press NOTICE Checking the engine compartment cover after installation ■ Make sure that the cover is securely installed in its original position. GS450h_OM_OM30E99U_(U)
Page 351 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 352 6-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 353 ● used oil and filters in household trash, in sewers or onto the ground. Call your Lexus dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 354 If the coolant level drops within a short time of replenishing ■ Visually check the radiator, hoses, engine/power control unit coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Lexus dealer test the cap and check for leaks in the cooling system. GS450h_OM_OM30E99U_(U)
Page 355 Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condi- tion, have your vehicle inspected by your Lexus dealer. WARNING When the hybrid system is hot ■...
Page 356 6-3. Do-it-yourself maintenance Brake fluid Checking fluid level ■ The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Adding fluid ■ Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel...
Page 357 6-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the warning message appears on the multi- information display, the washer tank may be empty. Add washer fluid. WARNING When adding washer fluid ■ Do not add washer fluid when the hybrid system is hot or operating as washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 358: 12-Volt Battery
6-3. Do-it-yourself maintenance 12-volt battery Location The 12-volt battery is located on the left-hand side of trunk. Removing the 12-volt battery cover Pull the strap upwards to lift up the 12- volt battery cover. Exterior Make sure that the 12-volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps.
Page 359 12-volt battery. Take extra care when connecting the 12-volt battery if the power switch mode prior to discharge is unknown. If the system will not start even after multiple attempts at all methods above, contact your Lexus dealer. WARNING Chemicals in the 12-volt battery ■...
Page 360 Use a 12-volt battery designed for this vehicle. Failure to do so may cause gas (hydro- gen) to enter the passenger compartment, causing a fire or explosion. For replacement of the 12-volt battery, contact your Lexus dealer. NOTICE When recharging the 12-volt battery ■...
Page 361: Tires
6-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance schedules and tread- wear. Checking tires Check if the treadwear indicators are showing on the tires. Also check the tires for uneven wear, such as excessive wear on one side of the tread. Check the spare tire condition and pressure if not rotated.
Page 362 When new tire pressure warning valves and transmitters are installed, new ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Lexus dealer. (P. 364) GS450h_OM_OM30E99U_(U)
Page 363 6-3. Do-it-yourself maintenance ◆ Initializing the tire pressure warning system The tire pressure warning system must be initialized in the following circum- ■ stances: When rotating the tires. ● When the tire inflation pressure is changed such as when changing travel- ●...
Page 364 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is nec- essary to register the ID code. Have the ID code registered by your Lexus dealer.
Page 365 6-3. Do-it-yourself maintenance Maximum load of tire ■ Check that the maximum load of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater. For the GAWR, see the Certification Label.
Page 366 In the following cases, the tire pressure warning system may not operate properly. ● • If non-genuine Lexus wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equipment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 367 6-3. Do-it-yourself maintenance Tire pressure warning system certification ■ For vehicles sold in the U.S.A.  Transmitter ● FCC ID: PAXPMVC010 Initiator ● FCC ID: HYQ22AAA NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 368 Do not mix tires of different makes, models or tread patterns. ● Also, do not mix tires of remarkably different treadwear. Do not use tire sizes other than those recommended by Lexus. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 369 When a tire is repaired with liquid sealants, the tire pressure warning valve and trans- mitter may not operate properly. If a liquid sealant is used, contact your Lexus dealer or other qualified service shop as soon as possible. After use of liquid sealant, make sure to replace the tire pressure warning valve and transmitter when repairing or replacing the tire.
Page 370: Tire Inflation Pressure
6-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire inflation pressure and tire size are displayed on the tire and loading information label. (P. 473) GS450h_OM_OM30E99U_(U)
Page 371 Reduced fuel economy ● Reduced driving comfort and poor handling ● Reduced tire life due to wear ● Reduced safety ● Damage to the drive train ● If a tire needs frequent inflating, have it checked by your Lexus dealer. GS450h_OM_OM30E99U_(U)
Page 372 6-3. Do-it-yourself maintenance Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: Check only when the tires are cold. ● If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 373: Wheels
● Steel wheels (F SPORT models only) ● Aluminum wheel precautions Use only Lexus wheel nuts and wrenches designed for use with your alumi- ● num wheels. When rotating, repairing or changing your tires, check that the wheel nuts are ●...
Page 374 Because tire repair or replacement may affect the tire pressure warning valves and ● transmitters, make sure to have tires serviced by your Lexus dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Lexus dealer.
Page 375: Air Conditioning Filter
6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air condi- tioning efficiency. Removal method Turn the power switch off. Open the glove box. Lift up the side with the stay, disconnect the stay tabs and remove the partition by pulling horizontally.
Page 376 6-3. Do-it-yourself maintenance Remove the air conditioning filter from the filter case and replace it with a new one. The “UP” marks shown on the filter and the filter case should be pointing up. Changing interval ■ Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required.
Page 377: Electronic Key Battery
6-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2032 ● Replacing the battery Take out the mechanical key. Remove the cover.
Page 378 6-3. Do-it-yourself maintenance Use a CR2032 lithium battery ■ Batteries can be purchased at your Lexus dealer, local electrical appliance shops or ● camera stores. Replace only with the same or equivalent type recommended by the manufacturer. ● Dispose of used batteries according to local laws.
Page 379: Checking And Replacing Fuses
6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the power switch off. Open the fuse box cover. Engine compartment ...
Page 380 6-3. Do-it-yourself maintenance Driver’ s side instrument panel Passenger’ s side instrument panel   Remove the lid. Remove the lid. Trunk  Push the tab in and lift the lid off. Remove the lid. GS450h_OM_OM30E99U_(U)
Page 381 6-3. Do-it-yourself maintenance The upper part of the 12-volt battery  Pull the strap upwards to lift up the 12-volt battery cover. When one or more of the fuses in this unit are blown, the unit needs to be replaced as a whole. Remove the fuse with the pullout tool.
Page 382 Type A and B: Replace the blown fuse with a new fuse of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type C and D: Contact your Lexus dealer. Type A Type B ...
Page 383 If the lights do not turn on even after the fuse has been replaced, a bulb may need ● replacement. (P. 386) If the replaced fuse blows again, have the vehicle inspected by your Lexus dealer. ● If there is an overload in a circuit ■...
Page 384: Headlight Aim (Vehicles With Single-Beam Headlights)
6-3. Do-it-yourself maintenance Headlight aim (vehicles with single-beam head- lights) Vertical movement adjusting bolts Adjustment bolt A Adjustment bolt B Before checking the headlight aim Make sure the vehicle has a full tank of gasoline and the area around the headlight is not deformed.
Page 385 Turn bolt B the same number of turns and in the same direction as step If the headlight cannot be adjusted using this procedure, take the vehicle to your Lexus dealer to adjust the headlight aim. GS450h_OM_OM30E99U_(U)
Page 386: Light Bulbs
You may replace the following bulbs by yourself. The difficulty level of replace- ment varies depending on the bulb. If necessary bulb replacement seems diffi- cult to perform, contact your Lexus dealer. For more information about replacing other light bulbs, contact your Lexus dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced.
Page 387 6-3. Do-it-yourself maintenance Replacing light bulbs Front turn signal light (vehicles with single-beam headlights) ■ For the left side only: Remove the bolt and move the washer fluid filler opening. Turn the bulb base counterclock- wise. Remove the light bulb. GS450h_OM_OM30E99U_(U)
Page 388 Right side Left side   Replacing the following bulbs ■ If any of the lights listed below has burnt out, have it replaced by your Lexus dealer. Headlights ● Parking lights/daytime running lights ● Front side marker lights ●...
Page 389 ■ Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. Contact your Lexus dealer for more information in the following situations: Large drops of water have built up on the inside of the lens.
Page 390 6-3. Do-it-yourself maintenance GS450h_OM_OM30E99U_(U)
Page 391: When Trouble Arises
When trouble arises 7-1. Essential information 7-2. Steps to take in an emergency Emergency flashers....392 If your vehicle needs to be towed........394 If your vehicle has to be stopped in an emergency ..393 If you think something is wrong....399 If a warning light turns on or a warning buzzer sounds..
Page 392: Emergency Flashers
7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 393: If Your Vehicle Has To Be Stopped In An Emergency
7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 394: 7-2. Steps To Take In An Emergency
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Lexus dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/provincial and local laws.
Page 395 7-2. Steps to take in an emergency Using a flatbed truck If your vehicle is transported by a flat- bed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.
Page 396 7-2. Steps to take in an emergency Emergency towing procedure Take out the towing eyelet. (P. 438) Remove the eyelet cover using a flathead screwdriver. To protect the bodywork, place a rag between the screwdriver and the vehicle body as shown in the illustration. Except F SPORT models F SPORT models ...
Page 397 7-2. Steps to take in an emergency While towing ■ If the hybrid system is off, the power assist for the brakes and steering will not function, making steering and braking more difficult. Wheel nut wrench ■ Wheel nut wrench is installed in trunk. (P. 438) WARNING Observe the following precautions.
Page 398 7-2. Steps to take in an emergency NOTICE To prevent damage to the vehicle when towing using a wheel-lift type truck ■ Do not tow the vehicle from the rear when the power switch is off. The steering lock ● mechanism is not strong enough to hold the front wheels straight.
Page 399: If You Think Something Is Wrong
7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Lexus dealer as soon as possible. Visible symptoms Fluid leaks under the vehicle.
Page 400: If A Warning Light Turns On Or A Warning Buzzer Sounds
(U.S.A.) • Malfunction in the electronically controlled brake system  Immediately stop the vehicle in a safe place and contact your Lexus dealer. Continuing to drive the vehicle may be dangerous. (Canada) Charging system warning light Indicates a malfunction in the vehicle’ s charging system ...
Page 401 Electric power steering system warning light (warning buzzer) Indicates a malfunction in the EPS (Electric Power Steering) sys-  Have the vehicle inspected by your Lexus dealer immediately. PCS (Pre-Collision System) warning light When the warning light flashes (and a buzzer sounds): ●...
Page 402 Warning light/Details/Actions Parking brake indicator (Flashes) (U.S.A.) Indicates a malfunction in the parking brake system  Have the vehicle inspected by your Lexus dealer immediately. (Flashes) (Canada) Brake system warning light Indicates a malfunction in: • The electronically controlled brake system;...
Page 403 If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Lexus dealer as soon as possible. Electric power steering system warning light (warning buzzer) ■...
Page 404 If both the ABS and the brake system warning lights remain on ■ Stop your vehicle in a safe place immediately and contact your Lexus dealer. The vehi- cle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 405 7-2. Steps to take in an emergency WARNING Maintenance of the tires ■ Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label). (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label [tire and load information label], you should determine the proper tire inflation pressure for those tires.)
Page 406: If A Warning Message Is Displayed
The master warning light also comes on or flashes in order to indicate that a message is currently being displayed on the multi-information display. Multi-information display If any of the warning light comes on again after the following actions have been performed, contact your Lexus dealer. Warning message and warning buzzer list Warning message Details/Actions...
Page 407  Check around the vehicle and back to inside of the lane lines. (If equipped) Indicates a malfunction in the brake system A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer immediately. Continuing to drive the vehicle may be dangerous. (U.S.A.) (Canada)
Page 408 Indicates a malfunction in the hybrid system A buzzer also sounds.  Immediately stop the vehicle in a safe place and contact your Lexus dealer. Indicates that hood or one or more of the doors or trunk are not fully closed The system also indicates which hood or doors or trunk are not fully closed.
Page 409 Details/Actions Indicates a malfunction in the Lexus parking assist All assist-sensors flash. A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer. (If equipped) Indicates that Lexus parking assist-sensor is dirty or cov- ered with ice A buzzer also sounds.
Page 410 7-2. Steps to take in an emergency Warning message Details/Actions Indicates that the driver’ s door was opened with the shift position in any position other than P A buzzer also sounds.  Shift the shift position to P. (Flashes) Indicates that the accelerator pedal is depressed while the shift position is in N A buzzer also sounds.
Page 411 P. The battery cannot be charged with the shift lever in N. (Flashes) Indicates a malfunction in the EPS (Electric Power Steer- ing) system A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer. GS450h_OM_OM30E99U_(U)
Page 412 Indicates a malfunction in the brake hold system A buzzer also sounds.  Depress the brake pedal to turn off the brake hold system. Have the vehicle inspected by your Lexus dealer immediately. Indicates that the brake hold system is turned on while on a steep slope A buzzer also sounds.
Page 413 7-2. Steps to take in an emergency Warning message Details/Actions Indicates an attempt was made to release the parking brake without depressing the brake pedal A buzzer also sounds.  Release the parking brake while depressing the brake pedal. Indicates that the shift position was changed and drive start control was operated while depressing the acceler- ator pedal A buzzer also sounds.
Page 414  Do not use the parking brake until the message dis- appears. (U.S.A.) (Canada) Indicates an engine malfunction A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer. (U.S.A.) (Canada) Indicates an engine malfunction A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer.
Page 415 • The ABS; or • The brake assist system A buzzer also sounds.  Immediately stop the vehicle in a safe place and contact your Lexus dealer. Continuing to drive the vehicle may be dangerous. (U.S.A.) (Canada) Indicates that the engine coolant temperature is too high A buzzer also sounds.
Page 416 Indicates that the radar cruise control system brake con- trol function is temporarily unavailable  Depress the brake. (If equipped) Indicates a malfunction in the smart access system with push-button start A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer. (Flashes) GS450h_OM_OM30E99U_(U)
Page 417 A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer. Indicates a malfunction in the dynamic radar cruise con- trol with full-speed range Depress the brake pedal.
Page 418 (Flashes) (If equipped) Indicates a malfunction in the PCS (Pre-Collision Sys- tem) A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer. (Flashes) (If equipped) GS450h_OM_OM30E99U_(U)
Page 419 Details/Actions Indicates a malfunction in the BSM (Blind Spot Monitor) system A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer. (If equipped) Indicates abnormal engine oil pressure A buzzer also sounds.  Immediately stop the vehicle in a safe place and contact your Lexus dealer.
Page 420 Warning message Details/Actions Indicates a malfunction in the DRS (Dynamic Rear Steering) A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer. (If equipped) Indicates a malfunction in the electronically controlled brake system A buzzer also sounds.
Page 421 A buzzer also sounds.  Close all the windows and the moon roof. (Flashes) (If equipped) Indicates a malfunction in the brake hold system A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer immediately. (Flashes) GS450h_OM_OM30E99U_(U)
Page 422 7-2. Steps to take in an emergency Warning message Details/Actions Indicates that the brake hold system cannot be turned off A buzzer also sounds.  Depress the brake pedal. Indicates that the brake hold system is not available The reason the brake hold system is not available may be displayed.
Page 423 A buzzer also sounds.  Release the parking brake. Indicates a malfunction in the drive start control system A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer immediately. GS450h_OM_OM30E99U_(U)
Page 424 Details/Actions Indicates a malfunction in the brake override system A buzzer also sounds.  Have the vehicle inspected by your Lexus dealer. Indicates that engine oil level is low This message may appear if the vehicle is stopped on a slope.
Page 425  Stop the vehicle in a safe place and turn the power switch off then on again. If the tire pressure warning indicator flashes for 1 minute then illuminates, there is a malfunction in the system. Have the vehicle inspected at your Lexus dealer. GS450h_OM_OM30E99U_(U)
Page 426 If the tire pressure is still not displayed even after repeating this process several times, have the vehicle inspected at your Lexus dealer. Indicates that the washer fluid level is low  Add washer fluid.
Page 427 Indicates that the engine oil and oil filter should be changed  Have the engine oil and oil filter checked and/or changed by your Lexus dealer. After changing the engine oil, the oil change system should be reset. (P. 351)
Page 428 Indicates that the PCS (Pre-Collision System) is tempo- rarily unavailable  When conditions improve, the system resumes operation. If this item is displayed continuously, have the vehicle inspected by your Lexus dealer. (Flashes) (If equipped) Air conditioning, heater and other operations are tem- porarily limited due to high power consumption ...
Page 429 7-2. Steps to take in an emergency Warning message Details/Actions Indicates that the EV drive mode is not available The reason the EV drive mode is not available (the vehicle is idling, battery charge is low, speed is higher than the EV drive mode operating speed range, accel- erator pedal is depressed too much) may be dis- played.
Page 430 7-2. Steps to take in an emergency Warning message Details/Actions Indicates that the EV drive mode has been automatically canceled The reason the EV drive mode is not available (the battery charge is low, speed is higher than the EV drive mode operating speed range, accelerator pedal is depressed too much) may be displayed.
Page 431 7-2. Steps to take in an emergency Warning message in radar cruise mode (if equipped) ■ In the following cases, the warning message may not be displayed even if vehicle-to-vehi- cle distance decreases: When your vehicle and the vehicle ahead are traveling at the same speed or the vehicle ●...
Page 432 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer The electronic key is not detected when an attempt is made to start the  Once hybrid system.  Start the hybrid system with the electronic key present. (Flashes) The electronic key was carried out- side the vehicle and a door other...
Page 433 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer An attempt was made to drive when the regular key was not inside the  9 times vehicle.  Confirm that the electronic key is inside the vehicle. (Flashes) The driver’...
Page 434 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer • An attempt was made to lock the doors using the smart access sys- tem with push-button start while the electronic key was still inside the vehicle. •...
Page 435 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer The electronic key has a low battery.   Replace the electronic key bat- Once tery. (P. 377) The driver’ s door was opened and closed with the power switch turned off and then the power switch was put in ACCESSORY mode twice without the hybrid system being...
Page 436 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer After the power switch has been turned off with the shift lever in a  Once position other than P, the shift lever has been shifted to P. ...
Page 437: If You Have A Flat Tire
7-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 361 WARNING If you have a flat tire ■...
Page 438 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Jack handle Wheel nut wrench Parking brake release tool Spare tire Screwdriver Jack Towing eyelet GS450h_OM_OM30E99U_(U)
Page 439 7-2. Steps to take in an emergency WARNING Using the tire jack ■ Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. Do not use the tire jack for any purpose other than replacing tires or installing and ●...
Page 440 7-2. Steps to take in an emergency Taking out the jack and jack handle Remove the center luggage mat. (P. 311) Remove the spacer and take out the jack handle from the reverse side of the center luggage mat. Take out the jack. For tightening For loosening Taking out the spare tire...
Page 441 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 442 • When installing a tire, only use wheel nuts that have been specifically designed for that wheel. • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Lexus dealer. GS450h_OM_OM30E99U_(U)
Page 443 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign matter from the wheel contact surface. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 444 7-2. Steps to take in an emergency Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) Stow the flat tire, tire jack and all tools. The compact spare tire ■...
Page 445 When replacing the tires ■ When removing or fitting the wheels, tires or the tire pressure warning valve and trans- mitter, contact your Lexus dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. GS450h_OM_OM30E99U_(U)
Page 446: If The Hybrid System Will Not Start
The 12-volt battery may be discharged. (P. 453) ● One or both of the 12-volt battery terminals may be disconnected. (P. 358) ● Contact your Lexus dealer if the problem cannot be repaired, or if repair procedures are unknown. GS450h_OM_OM30E99U_(U)
Page 447 Press and hold the power switch for about 15 seconds while depressing the brake pedal firmly. Even if the hybrid system can be started using the above steps, the system may be malfunctioning. Have the vehicle inspected by your Lexus dealer. GS450h_OM_OM30E99U_(U)
Page 448: If The Shift Lever Cannot Be Shifted From P
If the shift lever cannot be shifted with your foot on the brake pedal, there may be a problem with the shift lock system (a system to prevent accidental opera- tion of the shift lever). Have the vehicle inspected by your Lexus dealer imme- diately.
Page 449: If The Parking Brake Cannot Be Released
If the switch cannot be operated even when the 12-volt battery is normal, the parking brake system may be malfunctioning. Have the vehicle inspected by your Lexus dealer immediately. Before releasing the parking brake manually Shift the shift lever to P.
Page 450 7-2. Steps to take in an emergency Remove the plug. Insert the tool and press it down firmly while turning it counterclock- wise until it stops. Manual operation of the parking brake ■ The parking brake cannot be set manually. WARNING When releasing the parking brake manually ■...
Page 451: If The Electronic Key Does Not Operate Properly
Turning the key once again within 5 seconds unlocks the other doors. Opens the windows and moon roof (turn and hold) : This setting must be customized at your Lexus dealer. Trunk ■ Turn the mechanical key clockwise to open.
Page 452 Firmly depress the brake pedal and check that is shown on the multi- information display. Press the power switch. In the event that the hybrid system still cannot be started, contact your Lexus dealer. Stopping the hybrid system ■ Shift the shift lever to P and press the power switch as you normally do when stopping the hybrid system.
Page 453: If The 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid system if the 12-volt battery is discharged. You can also call your Lexus dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 454 7-2. Steps to take in an emergency Remove the engine cover. Connect the jumper cables according to the following procedure: Connect a positive jumper cable clamp to the exclusive jump starting ter- minal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle.
Page 455 Once the hybrid system has started, remove the jumper cables in the exact reverse order from which they were connected. Once the hybrid system starts, have the vehicle inspected at your Lexus dealer as soon as possible. Starting the hybrid system when the 12-volt battery is discharged ■...
Page 456 After recharging the 12-volt battery ■ Have the 12-volt battery inspected at your Lexus dealer as soon as possible. If the 12-volt battery is deteriorating, continued use may cause the 12-volt battery to emit a malodorous gas, which may be detrimental to the health of passengers.
Page 457: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the hybrid system has cooled down sufficiently, inspect the hoses and cooling system for leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Lexus dealer. GS450h_OM_OM30E99U_(U)
Page 458 If it is difficult to check these, turn the air conditioning system on and off repeatedly. (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the hybrid system immediately and contact your Lexus dealer. If the fans are operating: Have the vehicle inspected at the nearest Lexus dealer.
Page 459 Start the hybrid system and check for the multi-information display. If the message does not disappear: Stop the hybrid system and contact your Lexus dealer. If the message is not displayed: Have the vehicle inspected at the nearest Lexus dealer.
Page 460 7-2. Steps to take in an emergency When adding coolant ■ Add coolant in accordance with the following procedure. Remove caps A and B. Add coolant through the inlet of cap A up to the “[GR-HV] B” line, and then install cap A. Add coolant through the inlet of cap B until it is full, and then install cap B.
Page 461 7-2. Steps to take in an emergency WARNING When inspecting under the hood of your vehicle ■ Observe the following precautions. Failure to do so may result in serious injury such as burns. If steam is seen coming from under the hood, do not open the hood until the steam ●...
Page 462: If The Vehicle Becomes Stuck
7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the hybrid system. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the rear wheels.
Page 463 7-2. Steps to take in an emergency NOTICE To avoid damaging the transmission and other components ■ Avoid spinning the rear wheels and depressing the accelerator pedal more than nec- ● essary. If the vehicle remains stuck even after these procedures are performed, the vehicle ●...
Page 464 7-2. Steps to take in an emergency GS450h_OM_OM30E99U_(U)
Page 465: Vehicle Specifications
Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.)....466 Fuel information......478 Tire information......481 8-2. Customization Customizable features ..... 491 8-3. Initialization Items to initialize......504 GS450h_OM_OM30E99U_(U)
Page 466: Maintenance Data (Fuel, Oil Level, Etc.)
8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 190. 9 in. (4850 mm) Overall width 72.4 in. (1840 mm) Overall height 57.3 in. (1455 mm) Wheelbase 112.2 in. (2850 mm) Front 62.0 in. (1575 mm) Tread 62.6 in.
Page 467 ■ The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Lexus. It is used in register- ing the ownership of your vehicle. This number is stamped on the top left of the instrument panel and in the engine compartment.
Page 468 8-1. Specifications Engine Model 3.5 L 6-cylinder (2GR-FXE) Type 6-cylinder V type, 4-cycle, gasoline 3.70  3.27 in. (94.0  83.0 mm) Bore and stroke Displacement 210. 9 cu.in. (3456 cm Valve clearance Automatic adjustment Drive belt tension Fuel Fuel type Unleaded gasoline only Octane Rating 91 (Research Octane Number 96) or higher...
Page 469 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 470 8-1. Specifications Recommended viscosity: SAE 0W-20 SAE 0W-20 is the best choice for good fuel economy and good start- ing in cold weather. If SAE 0W-20 is not available, SAE 5W-20 oil may be used. However, it must be replaced with SAE 0W-20 at the next oil change.
Page 471 8-1. Specifications Cooling system Gasoline 9.7qt. (9.2 L, 8.1 Imp.qt.) engine Capacity Power 2.2qt. (2.1 L, 1.8 Imp.qt.) control unit Coolant type Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-sili- cate, non-amine, non-nitrite, and non-borate cool- ant with long-life hybrid organic acid technology Do not use plain water alone.
Page 472 Oil type and viscosity 75W-85 GL-5 or equivalent Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent of match- ing quality to satisfy the above specification. Please contact your Lexus dealer for further details.
Page 473 8-1. Specifications Brakes Pedal clearance 4.5 in. (115 mm) Min. Pedal free play 0.04 — 0.24 in. (1.0 — 6.0 mm) Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) Fluid type SAE J1703 or FMVSS No.
Page 474 8-1. Specifications Type B  Tire size 225/50R17 94W, T145/70D18 107M (spare) Driving under normal conditions Front: 35 psi (240 kPa, 2.4 kgf/cm or bar) Rear: 35 psi (240 kPa, 2.4 kgf/cm or bar) Spare: 60 psi (420 kPa, 4.2 kgf/cm or bar) Tire inflation pressure (Recommended cold...
Page 475 8-1. Specifications Type D  Tire size P235/45R18 94V, T145/70D18 107M (spare) Driving under normal conditions Front: 35 psi (240 kPa, 2.4 kgf/cm or bar) Rear: 35 psi (240 kPa, 2.4 kgf/cm or bar) Spare: 60 psi (420 kPa, 4.2 kgf/cm or bar) Tire inflation pressure (Recommended cold...
Page 476 8-1. Specifications Type F  Front tires: 235/40R19 96Y XL Tire size Rear tires: 265/35R19 94Y Spare tire: T145/70D18 107M Driving under normal conditions Front: 35 psi (240 kPa, 2.4 kgf/cm or bar) Rear: 36 psi (250 kPa, 2.5 kgf/cm or bar) Spare: 60 psi (420 kPa, 4.2 kgf/cm or bar)
Page 477 8-1. Specifications Light bulbs Light bulbs Bulb No. Type Front turn signal lights 7444NA Exterior Outer foot lights  Vanity lights Interior  Trunk light A: Wedge base bulbs (amber) B: Wedge base bulbs (clear) : Vehicles with single-beam headlights GS450h_OM_OM30E99U_(U)
Page 478: Fuel Information
Recommendation of the use of gasoline containing detergent additives ■ Lexus recommends the use of gasoline that contains detergent additives to avoid the ● build-up of engine deposits. All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or ●...
Page 479 Some gasoline contains an octane enhancing additive called MMT (Methylcyclopenta- dienyl Manganese Tricarbonyl). Lexus does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected. The malfunction indicator lamp on the instrument cluster may come on. If this happens, contact your Lexus dealer for service.
Page 480 8-1. Specifications NOTICE Notice on fuel quality ■ Do not use improper fuels. If improper fuels are used, the engine will be damaged. ● Do not use leaded gasoline. ● Leaded gasoline can cause damage to your vehicle’ s three-way catalytic converters causing the emission control system to malfunction.
Page 481: Tire Information
8-1. Specifications Tire information Typical tire symbols Full-size tire  Compact spare tire  GS450h_OM_OM30E99U_(U)
Page 482 8-1. Specifications Tire size (P. 483) DOT and Tire Identification Number (TIN) (P. 483) Location of treadwear indicators (P. 361) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Radial tires or bias-ply tires A radial tire has “RADIAL”...
Page 483 8-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’ s identification mark Tire size code Manufacturer’ s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 484 8-1. Specifications Tire dimensions ■ Section width Tire height Wheel diameter Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer GS450h_OM_OM30E99U_(U)
Page 485 National Highway Traffic Safety Administration of the U.S. Department of Trans- portation. It provides the purchasers and/or prospective purchasers of Lexus vehicles with information on uniform tire quality grading. Your Lexus dealer will help answer any questions you may have as you read this infor- mation. DOT quality grades ■...
Page 486 8-1. Specifications Temperature A, B, C ■ The temperature grades are A (the highest), B, and C, representing the tire’ s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 487 8-1. Specifications Tire related term Meaning Distribution of occupants in a vehicle as specified in the Occupant distribution third column of Table 1 below The combined weight of installed regular production options weighing over 5 lb. (2.3 kg) in excess of the standard items which they replace, not previously con- Production options weight sidered in curb weight or accessory weight, including...
Page 488 8-1. Specifications Tire related term Meaning Cord separation The parting of cords from adjacent rubber compounds Any parting within the tread, sidewall, or innerliner of Cracking the tire extending to cord material A pneumatic tire with an inverted flange tire and rim system in which the rim is designed with rim flanges pointed radially inward and the tire is designed to fit on the underside of the rim in a manner that encloses the...
Page 489 8-1. Specifications Tire related term Meaning The linear distance between the exteriors of the side- Overall width walls of an inflated tire, including elevations due to label- ing, decorations, or protective bands or ribs A tire intended for use on passenger cars, multipurpose Passenger car tire passenger vehicles, and trucks, that have a gross vehicle weight rating (GVWR) of 10,000 lb.
Page 490 8-1. Specifications Tire related term Meaning The rim on which a tire is fitted for testing, and may be Test rim any rim listed as appropriate for use with that tire That portion of a tire that comes into contact with the Tread road Tread rib...
Page 491: Customization
Your vehicle includes a variety of electronic features that can be personalized to your preferences. These preferences can be changed by using the meter control switches, by using the Remote Touch, or at your Lexus dealer. Customizing vehicle features Changing by using the Remote Touch ■...
Page 492 8-2. Customization Meters and multi-information display (P. 93) ■ Default Customized Function setting setting French Language English O O — Spanish miles (MPG Imperial) miles Units O O — (MPG US) km (L/100 km) km (km/L) EV indicator — O — Drive Desired status switch settings...
Page 493 8-2. Customization Default Customized Function setting setting Hybrid system indicator Changeover to tachometer (always) Auto — O — when sport mode is selected Tachometer (always) 12-hour Clock 24-hour display — O — display Needle Blue — O — White 2000 to 6000 rpm Rev indicator 4000 rpm...
Page 494 8-2. Customization LKA (Lane-Keeping Assist) (P. 232) ■ Default Customized Function setting setting Lane centering function — O — Steering assist — O — Adjust alert type — O — (Steering (Buzzer) vibration) Alert sensitivity High Standard — O — Vehicle sway warning —...
Page 495 8-2. Customization AFS (Adaptive Front-lighting System) (P. 198) ■ Default Customized Function setting setting AFS (Adaptive Front-lighting System) — O — : If equipped ■ Door lock (P. 120, 451) Default Customized Function setting setting (Driver’ s Unlocking on second key turn door (Allows all doors to be unlocked by turn- unlocked in...
Page 496 8-2. Customization Smart access system with push-button start and wireless remote control ■ (P. 116, 133) Default Customized Function setting setting Operation signal O — O (Buzzers) 1 to 7 Operation signal O — O (Emergency flashers) Time elapsed before automatic door lock function is activated if a door is not seconds O —...
Page 497 8-2. Customization Wireless remote control (P. 116) ■ Default Customized Function setting setting Wireless remote control — — O (Driver’ s door unlocked in (All doors Unlocking operation O — O one step, all unlocked in one doors step) unlocked in two steps) One short press...
Page 498 8-2. Customization Power windows and moon roof (P. 158, 161) ■ Default Customized Function setting setting Mechanical key linked operation — — O Wireless remote control linked opera- — — O tion (Open only) Buzzer sounds if operated using wire- —...
Page 499 8-2. Customization 1, 2 Intuitive parking assist ■ Default Customized Function setting setting Detection distance of the front center Near O — O sensor Detection distance of the rear center Near O — O sensor Buzzer volume 1 to 5 O —...
Page 500 8-2. Customization Automatic air conditioning system (P. 285) ■ Default Customized Function setting setting A/C Auto switch operation O — O Exhaust gas sensor information Standard -3 to 3 O — O ■ Front seat heaters and ventilators/rear seat heaters (P.
Page 501 8-2. Customization Illumination (P. 302) ■ Default Customized Function setting setting Interior lights illumination control — — O seconds Time elapsed before the interior lights O — O turn off seconds seconds Operation after the power switch is — — O turned off Operation when the doors are unlocked —...
Page 502 8-2. Customization Rear sunshade (P. 316) ■ Default Customized Function setting setting Reverse operation — — O 0 second 0. 9 Time elapsed before the reverse opera- seconds — — O tion feature activates seconds seconds ■ Seat belt reminder buzzer (P. 402) Default Customized Function...
Page 503 8-2. Customization WARNING During customization ■ As the hybrid system needs to be operating during customization, ensure that the vehi- cle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Page 504: 8-3. Initialization
8-3. Initialization Items to initialize The following items must be initialized for normal system operation after such cases as the 12-volt battery being reconnected, or maintenance being per- formed on the vehicle: Item When to initialize Reference Message indicating mainte- •...
Page 505: For Owners
For owners Reporting safety defects for U.S. owners........506 Seat belt instructions for Canadian owners (in French) ..........507 SRS airbag instructions for Canadian owners (in French) ..........509 Headlight aim instructions for Canadian owners (in French) (vehicles with single-beam headlights).....517 GS450h_OM_OM30E99U_(U)
Page 506: Reporting Safety Defects For U.s. Owners
However, NHTSA cannot become involved in indi- vidual problems between you, your dealer, or Lexus Division of Toyota Motor Sales, U.S.A., Inc.
Page 507: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation adéquate des ceintures de sécurité...
Page 508 Entretien et soin Ceintures de sécurité ■ Avec un chiffon ou une éponge, nettoyez à l’aide d’un savon doux et de l’eau tiède. Vérifiez aussi les ceintures régulièrement pour vous assurer qu’elles ne présentent pas d’usure excessive, d’effilochage ou de coupures. AVERTISSEMENT Dommages et usure de la ceinture de sécurité...
Page 509: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instructions in English. GS450h_OM_OM30E99U_(U)
Page 510 ◆ Coussins gonflables SRS avant Coussin gonflable SRS du conducteur/du passager avant Peuvent aider à protéger la tête et la poitrine du conducteur et du passager avant contre les impacts avec des composants intérieurs Coussins gonflables SRS de protection des genoux Peuvent aider à...
Page 511 Composants du système de coussins gonflables SRS Système de classification de l’occu- Coussins gonflables latéraux avant pant du siège du passager avant Lampe témoin SRS (ECU et capteurs) Coussin gonflable du conducteur Capteurs d’impact latéral Coussins gonflables latéraux arrière (portières avant) Capteurs d’impact latéral (arrière) Coussins gonflables de protection Capteur de position du siège du...
Page 512 Votre véhicule est doté de COUSSINS GONFLABLES ÉVOLUÉS dont la con- ception s’appuie sur les normes de sécurité des véhicules à moteur américains (FMVSS208). Le module de capteur de coussin gonflable (ECU) contrôle le déploiement des coussins gonflables en fonction des informations obtenues des capteurs et d’autres éléments affichés dans le diagramme des composants du système ci-dessus.
Page 513 être correctement retenu à l’aide d’un dispositif de retenue pour enfants. Lexus recommande vivement de placer et d’attacher correctement tous les bébés et tous les enfants sur les sièges arrière du véhicule à...
Page 514 AVERTISSEMENT Précautions relatives aux coussins gonflables SRS ■ Ne laissez pas un enfant se tenir face au cous- ● sin gonflable SRS du passager avant ni s’asseoir sur les genoux d’un passager avant. Ne laissez pas les occupants des sièges avant ●...
Page 515 à gants et les garnitures des montants avant et arrière, sont endommagés ou fissurés, faites-les remplacer par votre concessionnaire Lexus. Ne placez aucun objet, par exemple un coussin, sur le siège du passager avant. Cela ●...
Page 516 ■ Ne mettez pas votre véhicule au rebut et n’effectuez aucune des modifications suiva- ntes sans d’abord consulter votre concessionnaire Lexus. Les coussins gonflables SRS pourraient fonctionner de manière incorrecte ou se déployer (gonfler) accidentelle- ment, ce qui serait susceptible d’occasionner des blessures graves, voire mortelles.
Page 517: Headlight Aim Instructions For Canadian Owners (In French) (Vehicles With Single-Beam Headlights)
Headlight aim instructions for Canadian owners (in French) (vehicles with single-beam headlights) The following is a French explanation of headlight aim instructions from the headlight aim section in this manual. Boulons de réglage vertical Boulon de réglage A Boulon de réglage B Avant de vérifier la portée des phares Assurez-vous que le réservoir de carburant du véhicule est plein et que la partie de carrosserie située autour des phares n’est pas déformée.
Page 518 Tournez le boulon B du même nom- bre de tours et dans le même sens qu’à l’étape Si vous n’arrivez pas à régler vos phares en suivant cette procédure, apportez le véhicule chez votre concessionnaire Lexus afin qu’il règle la portée des pha- res. GS450h_OM_OM30E99U_(U)
Page 519: Index
What to do if... (Troubleshooting)........520 Alphabetical index......... 524 For information regarding the equipment listed below, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MAN- UAL”. • Audio system • Navigation system • Intuitive parking assist • Lexus parking assist monitor GS450h_OM_OM30E99U_(U)
Page 520 What to do if... (Troubleshooting) What to do if... (Troubleshooting) If you have a problem, check the following before contacting your Lexus dealer. The doors cannot be locked, unlocked, opened or closed You lose your keys If you lose your mechanical keys, new genuine mechanical keys can be made ●...
Page 521 What to do if... (Troubleshooting) If you think something is wrong The hybrid system does not start Did you press the power switch while firmly depressing the brake pedal? ● (P. 180) Is the shift lever in P? (P. 182) ●...
Page 522 What to do if... (Troubleshooting) A warning buzzer sounds during driving The seat belt reminder light is flashing ● Are the driver and the front passenger wearing the seat belts? (P. 402) The parking brake indicator is on ● Is the parking brake released? (P. 193) Depending on the situation, other types of warning buzzer may also sound.
Page 523 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire Stop the vehicle in a safe place and replace the flat tire with the spare tire. ● (P. 437) The vehicle becomes stuck Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow. ●...
Page 524: Alphabetical Index
Alphabetical index Alphabetical index Airbags............35 A/C............285 Airbag operating conditions ...42 Air conditioning filter......375 Airbag precautions Changing the rear seat for your child ........38 settings..........292 Airbag warning light ....... 400 Front automatic air conditioning Correct driving posture....28 system ..........285 Curtain shield airbag Micro dust and pollen filter....
Page 525 Alphabetical index Approach warning.......248 Brake Armrest ............. 315 Brake Hold ..........195 Assist grips ..........318 Fluid ............356 Audio input Parking brake ........193 Regenerative braking......67 Audio system Automatic headlight leveling Warning light......400, 402 system ............199 Warning message......406 Automatic light control system..197 Brake assist..........266 AUX port Brake Hold..........195...
Page 526 Alphabetical index Child restraint system......53 Child-protectors ........123 Booster seats, definition ....53 Cleaning ........332, 336 Booster seats, installation....61 Aluminum wheels......333 Convertible seats, definition....53 Exterior ........... 332 Convertible seats, installation..59 Interior.............336 Front passenger occupant Seat belts..........337 classification system......46 Clock............313 Infant seats, definition......53 Coat hooks ..........318 Infant seats, installation .......59...
Page 527 Alphabetical index Doors ............120 Daytime running light system... 198 Automatic door locking Defogger and unlocking system....123 Front windshield ........291 Door glasses......... 158 Outside rear view mirrors....291 Door lock..........122 Rear window ......... 291 Open door warning buzzer ..134 Differential..........472 Outside rear view mirrors ....154 Dimensions ..........
Page 528: If Your Vehicle Has To Be
Alphabetical index Emergency flashers ......392 Eco drive mode........256 Energy monitor ........108 EDR (Event data recorder)....10 Engine Electric motor (traction motor)..66 Accessory mode ........181 Compartment ........349 Electric Power Steering (EPS) ..267 Function ..........267 Engine switch ........180 Warning light ........
Page 529 Alphabetical index Engine switch .......... 180 Front side marker lights....... 197 Auto power off function....182 Light switch..........197 Changing the power switch Replacing light bulbs ...... 388 modes .............181 Welcome light illumination If your vehicle has to be stopped control............121 in an emergency ......393 Front turn signal lights......192 Starting the hybrid system....180...
Page 530 Alphabetical index Horn.............. 151 Hands-free system Hybrid battery (traction battery) (for cellular phone) Location ............ 70 ® HD Radio system Specification.........468 Hybrid battery (traction battery) Head restraints........148 Headlight cleaner..... 205, 207 air vents.............70 Headlights ..........197 Hybrid system..........66 Adaptive Front-lighting Emergency shut off system ....
Page 531 Alphabetical index I/M test ............. 344 Jack Identification........... 467 Positioning a floor jack....348 Engine............467 Vehicle-equipped jack....438 Vehicle ............467 Jack handle ..........438 Ignition switch (power switch) ..180 Jam protection function Auto power off function....182 Moon roof..........162 Changing the power switch Power trunk opener modes .............181 and closer ..........128...
Page 532 Lexus Dynamic Handling LKA (Lane-Keeping Assist) .....232 system (LDH)........267 Operation..........236 Lexus Enform Warning messages ......406 Lexus Enform Safety Connect..326 Load capacity .......... 177 Lexus parking assist monitor Lock steering column......182 Lexus Safety System+......214 Low profile tire ........364 Automatic High Beam ....
Page 533 Alphabetical index Malfunction indicator lamp ....400 Master warning light ......402 Navigation system Meter............86 Noise from under vehicle......8 Head-up display........101 Indicators...........82 Instrument panel light control..89 Odometer..........86 Meters............86 Multi-information display ....93 Engine oil ..........469 Warning lights ......... 81 Differential oil........472 Micro dust and pollen filter ....291 Opener Mirrors Fuel filler door........210...
Page 534 Alphabetical index Power easy access system....143 Paddle shift switches......189 Power outlets...........313 Parking assist sensors Power steering (Electric Power (intuitive parking assist) Steering system).........267 Warning light.........401 Parking brake...........193 If the parking brake Warning message......406 cannot be released......449 Power switch........... 180 Operation..........
Page 535 Alphabetical index Regenerative braking......67 Radar cruise control (dynamic Remote Touch ........280 radar cruise control with Replacing full-speed range) .........241 Electronic key battery ......377 Fuses ............379 Radiator............355 Radio Light bulbs..........386 RBDS (Radio Broadcast Tires............437 Data Systems) Reporting safety defects Rear air conditioning system ...
Page 536 Alphabetical index Seat heaters ..........300 S-FLOW mode........286 Seat position memory......143 Shift lever...........187 Seat ventilators........300 Hybrid transmission ......187 Seating capacity........177 If the shift lever cannot be shifted from P....448 Seats.............. 141 Adjustment..........141 Shift lever light ........302 Adjustment precautions ....142 Shift lock system ........
Page 537 Alphabetical index Spare tire..........437 Switches Inflation pressure........473 Audio remote control switches Storage location .........473 Automatic High Beam switch..200 Spark plug ..........471 Brake hold switch........195 Cruise control switch ....241, 253 Specifications......... 466 Speedometer ..........86 Door lock switches......122 Sport mode ..........256 Driving mode select switch..256 Steering lock ...........
Page 538 Alphabetical index Power door lock switch ....122 Talk switch Power switch.........180 Telephone switches Power window switches ....158 Theft deterrent system Rear sunshade switch....... 316 Alarm ............77 Rear window and outside Immobilizer system.......74 rear view mirror defoggers Tire inflation pressure......473 switch............. 291 Maintenance data......
Page 539 Alphabetical index Replacing ..........437 Trunk ............126 Rotating tires ........362 Internal trunk release lever .....129 Size............473 Jam protection function....128 Snow tires ..........277 Luggage security system....128 Spare tire..........437 Open trunk warning message..406 Tire inflation pressure display Power trunk opener function..........362 and closer ..........126 Tire pressure warning system ..362 Smart access system...
Page 540 Alphabetical index Vanity lights..........312 Warning buzzers Vanity lights ..........312 Approach warning ......248 Wattage..........477 Brake system ........400 Downshifting........... 191 Vanity lights..........312 Vanity mirrors........312 Intuitive parking assist Variable Gear Ratio Steering Key reminder........434 (VGRS) ..........267 Open door .......... 408 Function ..........267 Open moon roof .........421 Warning message......
Page 541 Alphabetical index Warning messages......406 Winter driving tips ........274 Warning reflector storage belt..311 Wireless remote control key..... 127 Washer .............204 Battery-Saving Function ....135 Checking..........357 Locking/Unlocking ......127 Low washer fluid Replacing the battery .......377 warning message ......406 WMA disc Preparing and checking before winter ........
Page 542 Alphabetical index GS450h_OM_OM30E99U_(U)
Page 543 Alphabetical index GS450h_OM_OM30E99U_(U)
Page 544 GAS STATION INFORMATION Auxiliary catch lever Trunk opener Fuel filler door P. 347 P. 126 P. 211 Hood lock release lever Tire inflation pressure P. 347 P. 473 Fuel tank capacity 17.5 gal. (66.3 L, 14.6 Imp.gal.) (Reference) Fuel type Unleaded gasoline only P.
