- Page 1 Installation Guide Frontier-S DX100 printer with DarkRoom Pro Software Windows V4 Driver Version 9.1.1978 Basic Driver DarkRoom 9.20.2232 or higher for Advanced Driver integration Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 2 This page is intentionally left blank Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 3 Setting up the Frontier-S DX100 Printer Installing the DarkRoom Pro software on the Client PC Setting up the Frontier-S DX100 printer(s) on the DarkRoom PC Setup and use of DarkRoom Pro Appendix: Operation Notes; Color Management with Windows Driver and DarkRoom Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 4 DX100 with DarkRoom Pro software using Version 9.1.1978 and Version 9.2 and higher. Please Note: To take full advantage of the Fujifilm DX100 V 4 Driver with DarkRoom Pro you must have DarkRoom Pro Version 9.2.2232 or higher. This will enable automatic set up of the “Fujifilm DX100 EX”...
- Page 5 General System Information Note on Printer USB Port Installation: The Frontier-S DX100 printer connects to DarkRoom Pro computer as USB connection one computer to multiple printers. Note location, port number and printer number when installing. If a printer is disconnected or replaced connect only to the port that the printer was originally installed on.
- Page 6 System Topology The illustration below shows a Host PC which meets minimum configurations outlined in the DX100 Installation Manual, Frontier-S Printer Driver Operation Guide EN.pdf Fourth Edition. DarkRoom Pro is installed on the Client PC. The DX100 Printer is connected to the Host PC via USB.
-
Page 7: Printer Installation
Installation and Settings: Frontier-S DX100 Printer Driver Operation Guide EN.pdf Fourth Edition pages 9 through 12 Review Review and follow the instructions for the use of the Frontier-S DX100 Printer Driver Operation Guide EN.pdf Fourth Edition Pages 12 through 50. Revision 2.04 - V4.3 Driver- 11/23/16... - Page 8 Installing DarkRoom Pro software on the System PC The Frontier-S DX100 S should be set up following instructions found in General Information and Frontier-S Printer Driver Operation Guide EN.pdf Fourth Edition To Install DarkRoom Pro on your host computer: 1. Insert the DarkRoom Pro installation disk into the DVD drive 2.
- Page 9 8. When the DarkRoom Professional installer starts, Click Next 9. Select the Radio button to “Accept the terms in the license agreement” and Click Next Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 10 10. Click Next 11. Click Install Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 11 12. The progress of the installation will be shown as in the illustration below. 13. Click Finish 14. Remove the DVD from the drive, and reboot the system. Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 12 Setting up the DX100 printer(s) on the DarkRoom PC 1. Be sure that DX100 is connected to the computer USB, and properly registered to the Fujifilm DX100 Maintenance Menu. The printer should be on with Blue Power Light Button on solid. Insert DarkRoom USB Dongle in Client PC.
- Page 13 5. From the Set Up Tab Click on “Printer Options” Click on “add printer” Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 14 IF- your version of DarkRoom Pro is V 9.10.1978 select Windows Driver as in Figure A. Figure A IF- your version DarkRoom Pro is V 9.20.2232 or higher Select Fujifilm DX100 as in Figure B. Figure B Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 15 8. The Printer Setup dialog box will appear with printer(s) found connected to the computer. Select the Fujifilm DX100 EX printer and Click “OK”. 9. In the DarkRoom DX100 Set Up Dialog Box Check the boxes for “Enable Driver” and Allow printer to be used offline”.
- Page 16 10. DX100 Printer Set Up DarkRoom Pro V 9.20.2233 or higher Select Fujifilm DX100 EX Printer and Click OK. Check Boxes Enable Driver and Allow printer to be used offline. 11. Make sure that the proper paper size has been selected in the Paper Size box.
- Page 17 Windows Printer Set Up DarkRoom Pro V 9.10.1978 DX100 Printer Set Up DarkRoom Pro V 9.20.2232- Make sure that the proper paper size has been selected in the Paper Size box. Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 18 12. Next be sure to select the proper paper surface has been selected in the Paper Type box. Windows Printer Set Up DarkRoom Pro V 9.10.1978 DX100 Printer Set Up DarkRoom Pro V 9.20.2232 or higher- Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 19 13. In DarkRoom Pro V 9.20.2232 or higher--Click on the Refresh Button. (Not available in Windows Print Driver Set Up.) 14. After clicking on the Refresh button you will note that the Remaining Paper footage and prints remaining will be displayed. You can also select workflow settings of Paper Match and Print Mode/Speed that you would like to use.
- Page 20 16. …. Bring up the DX100 Windows Driver Status Dialog. This window confirms printer status, ink levels remaining and Printer Paper Set Up. Selecting Print Queue Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 21 17. Print Queue: After selecting Print Queue the Windows Driver Print Queue is shown. When jobs are being printed you can monitor progress of jobs in the Windows Print Driver. 18. Selecting the Start Frontier-S DX100 Printer Maintenace Button launches Fujifilm DX100 Maintence Menu. Revision 2.04 - V4.3 Driver- 11/23/16...
- Page 22 19. From the Fujifilm DX100 Maintence Menu you may perform printer maintenace funtions as necessary. Instructions for use of the Maintence Menu can be found in the document Frontier-S DX100 Printer Driver Operation Guide EN 1st edition.pdf 20. Color ICC Profile Use and Color Management: ICC Profile use is very important to mainatining color quality and fidelity for InkJet output.
- Page 23 21. The lower portion of the Advanced Tab/Other Settings contains a check box in which you can limit the number of sheets sent to in to each printer order. Using this setting a user can easily load balanace jobs between two printers loaded with the same roll width and surface materails.
- Page 24 23. By selecting Chosse Print Size and choosing the specific roll width as user is brought to the print size selections for that particualr roll width. 24. The Set Up Print Size dialog box allows users to manualy or automatically select prints sizes for each roll width specific to that printers set up.
- Page 25 26. To Set up additional printers connected to your computer with DarkRoom Pro repeat Steps 5 - 24 above. Setup and use of DarkRoom Pro Follow instructions provided on the DarkRoom Pro operation manual which can be found in the DarkRoom Pro Set Up Tab in the Left Hand Column under Help.
