Geemarc DALLAS 100 VM Manual

Geemarc DALLAS 100 VM Manual

Amplified telephone with outgoing voice modulation
Hide thumbs Also See for DALLAS 100 VM:
Table of Contents

Advertisement

Quick Links

DALLAS 100 VM
AMPLIFIED TELEPHONE WITH
OUTGOING VOICE MODULATION
English

Advertisement

Table of Contents
loading

Related Manuals for Geemarc DALLAS 100 VM

Summary of Contents for Geemarc DALLAS 100 VM

  • Page 1 DALLAS 100 VM AMPLIFIED TELEPHONE WITH OUTGOING VOICE MODULATION English...

  • Page 2: General Description

    DESCRIPTION GENERAL DESCRIPTION Line cord Indirect Clip for Voice Quick Dial socket* memory wall meter locations, button mounting M1,M2 and M3 Ringer Volume settings Ringer tone setting Sending level amplified setting Last number redial Memory storing key Handset Amplify R button (for private exchanges) Handset tone Handset volume...
  • Page 3 DESCRIPTION REAR Voice level Amplify Dialing Flash Telephone meter setting default mode setting line socket setting setting BASE Thread the line cord through this groove...

  • Page 4: Connecting Telephone

    SETTING UP 1 - CONNECTING TELEPHONE 1 - Connect the handset cord. 2 - Connect the line cord to the socket located at rear of telephone then connect the PTT plug*. 2 - RINGER VOLUME SETTING A switch located on the right side allows the ringer to be switched to HI, LOW or OFF...

  • Page 5: Ringer Tone Setting

    SETTING UP 3 - RINGER TONE SETTING A switch located on the right side allows the melody to be switched to HI, Middle or LOW. 4 - WALL MOUNTING To wall-mount your telephone, slide out the clip turn around and slide back into the wall mounting position (located in the base unit, just below the ear piece).This will ensure that the handset stays firmly in position.

  • Page 6: Tone/Pulse Switch (T/P)

    SETTING UP 5 - TONE/PULSE SWITCH (T/P)** The Tone/Pulse switch is factory pre-set to Tone position (T).In the UK,all telephone exchanges now use Tone dialing. If your phone does not dial out it is probably being used from an older pri- vate switch board (PBX).

  • Page 7: Using The Phone

    USING THE PHONE 1 - ANSWERING INCOMING CALL - When an incoming call is received the phone will ring and flash. To answer the call lift the handset and speak. - On completion of the call, carefully replace the handset in the cradle to release the line. 2 - VOLUME RECEIVING ADJUSTMENT You can increase the volume according to your own hearing requirements.

  • Page 8: Tone Receiving Adjustment

    USING THE PHONE 3 - TONE RECEIVING ADJUSTMENT If the receiver volume has been amplified, the tone control can also be adjusted. You can adjust and increase the low frequency or high frequency sounds with the tone slide control on the front edge of the unit.

  • Page 9: Sending Level Adjustment

    USING THE PHONE 5 - SENDING LEVEL ADJUSTMENT If your voice is quiet or called parties have difficulty hearing you, you can increase the sending level volume with the switch located on the right side. +4db 6 - LAST NUMBER REDIAL - Lift the handset.

  • Page 10: Storing Telephone Numbers

    USING THE PHONE 8 - STORING TELEPHONE NUMBERS Your phone can store 3 direct and 10 indirect memories (16 digits maximum for each memory). - Lift the handset. - Press button. - Dial the telephone number you wish to store. - Press button.

  • Page 11: Dialling Stored Number

    USING THE PHONE 9 - DIALLING STORED NUMBER - Lift the handset and await the dial tone. - Press appropriate direct memory button M1, M2, or M3. The stored number will be dialled out automatically. Or press the M button followed by the keypad 0 to 9 button under which the desired number is stored.
  • Page 12 USING THE PHONE 11 - AMPLIFICATION SETTING a.Set the AMPLIFY Switch located at rear side of unit to ON position, the Amplification is auto on when handset is lifted. b.Set the AMPLIFY Switch to OFF posi- tion, the Amplification is off when handset is lifted. 12 - RECEIVE VOLUME AMPLIFICATION When unit is off-hook, press the button to...

  • Page 13: Flash Time Setting

    USING THE PHONE 13 - FLASH TIME SETTING a.Set the flash Switch located at rear side of unit .set to 100ms position (for UK), the time is auto set in 100ms mode when handset is lifted. b.Set the flash Switch to 300ms position (for French), the time is auto set in 300ms mode when handset is lifted.
  • Page 14 GUARANTEE From the moment your Geemarc product is purchased, Geemarc guarantee it for the period of one year. During this time, all repairs or replacements (at our discretion) are free of charge. Should you experience a problem then contact our help line or visit our website at www.geemarc.com.

  • Page 15: Recycling Directives

    - Or, hand the old product to the retailer. If you purchase a new one, they should accept it. Thus if you respect these instructions you ensure human health and environmental protection. For product support and help visit our website at www.geemarc.com Telephone 01707 384438 Or fax 01707 372529...
  • Page 16 Hertfordshire, AL7 1SB 59760 Grande Synthe Deutschland For product support: For product support: TEL. SERVICE APRES VENTE: Tel: 069 / 96 217 635 01707 384438 01707 384438 03 28 58 75 99 Fax: 069 / 96 217 620 www.geemarc.com www.geemarc.com www.geemarc.com www.geemarc.com...
