Summary of Contents for Emotiva LCR SERIES
-
Page 3: Table Of Contents
About This Manual ......................4 Features ..........................5 Unpacking ..........................6 BasX LCR ..........................7 BasX SAT ..........................8 Quick Start .........................9 Speaker Placement ...................... 10 Connections ........................12 Care and Maintenance ....................13 Emotiva Audio Corporation Three-Year Limited Warranty ......14 Notes ..........................17 Page 1... - Page 4 BasX Speakers Page 2...
-
Page 5: Introduction
Introduction Thank you for purchasing our new Emotiva BasX™ speakers. The Emotiva BasX series of speakers leverage many of the advanced design features and technologies we developed for our high-end speakers to deliver both excellent technical performance and superb sound quality in a compact form factor. However, by exercising exceptional care in the design process, we’ve managed to add another feature that’s important... -
Page 6: About This Manual
BasX Speakers About This Manual This manual will provide you with all the information you need to achieve great performance, accurate sound, and many years of reliable service from your BasX speakers. We suggest that you read through the entire manual; we kept things as short and direct as possible. -
Page 7: Features
BasX Speakers Features The Emotiva BasX LCR and BasX SAT speakers were designed to deliver superb sound for any audiophile stereo or home theater sound system. When paired with a high-quality amplifier or receiver, and a subwoofer, the BasX speakers will deliver clean well-balanced sound with very low distortion and excellent sound stage imaging. -
Page 8: Unpacking
Unpacking Your BasX speakers were carefully packed and should reach you in perfect condition. If you notice any shipping damage or other issues when you unpack them, please contact Emotiva immediately. Gently remove your BasX speakers from the packing carton and remove all wrappings and shipping material. -
Page 9: Basx Lcr
BasX Speakers BasX LCR The BasX LCR is a two way speaker, featuring a ferro-fluid cooled 1 inch silk dome tweeter, a pair of matched long throw 4 inch mid/bass drivers with mineral filled polypropylene cones and rubber surrounds, and dual rear firing tuning ports. The BasX LCR may be used vertically as a left or right main or surround speaker, or horizontally as the center channel speaker in a surround sound system. -
Page 10: Basx Sat
BasX Speakers BasX SAT The BasX SAT is a two way speaker, featuring a ferro-fluid cooled 1 inch silk dome tweeter, a long throw 4 inch mid/bass driver with a mineral filled polypropylene cone and rubber surround, and a rear firing tuning port. The BasX SAT is designed to be used vertically, as a left or right main or surround speaker, or as the center channel speaker in a surround sound system. -
Page 11: Quick Start
BasX Speakers Quick Start To get the most from your Emotiva BasX speakers, we urge you to read the entire manual. If you just can’t wait to hear how great your BasX speakers sound, this section will cover the basics you need to get started. -
Page 12: Speaker Placement
BasX Speakers Speaker Placement Speaker placement is often a compromise between optimum performance, personal preference, and site requirements. The optimum location for stereo speakers will depend on the speakers and the acoustics of your listening room. Many surround sound standards have specific recommendations about the optimum position for each speaker, and the different surround sound systems recommend slightly different locations. - Page 13 BasX Speakers Guidelines for home theater / surround sound speaker placement: • It’s best to use speakers that all use similar technology, and that are “timbre matched” to each other. If this is impossible, then at least the front left, front right, and center speakers should be well matched.
-
Page 14: Connections
If you use stranded cables, use care to avoid short circuits (from stray strands touching) • Emotiva offers very high quality pre-made speaker cables at reasonable prices (you will find them in the Interconnects section of our website at www.emotiva.com) Page 12... -
Page 15: Care And Maintenance
BasX Speakers Care and Maintenance Periodic Maintenance Your BasX speakers require no periodic maintenance or calibration. Cleaning the Cabinet and Baffle • The cabinets of the BasX speakers should normally be cleaned with a rag dampened with plain water. DO NOT spray water directly onto or into the speaker and DO NOT use abrasive or chemical cleaners. -
Page 16: Emotiva Audio Corporation Three-Year Limited Warranty
The original owner must make a claim within the Term of the Warranty. A claim shall not be valid (and Emotiva has no obligation related to the claim) if it is not made within the Term and if it is not made in strict compliance with the requirements of the “How do you get service?”... - Page 17 When a Product or part is repaired or replaced, any replacement item becomes your property and the replaced item becomes Emotiva’s property. When a refund or credit is given, the Product for which the refund or credit is provided must be returned to Emotiva and becomes Emotiva’s property.
- Page 18 If your Product was not adequately packaged, we will refuse receipt and the damaged package will be returned to you at your cost. If you do not have the original Emotiva Audio packaging, please check with our sales department to purchase replacement-shipping cartons.
-
Page 19: Notes
Notes All information contained in this manual is accurate to the best of our knowledge at the time of publication. In keeping with our policy of ongoing product improvement, we reserve the right to make changes to the design and features of our products without prior notice. User Manual Revision 1.0 September 2016...
