Cable installation from the monitor to the camera
Install the connecting cable of the camera into the interior of the vehicle.
Install the extension cable from the monitor to the camera
(see
H 13).
Connect the camera connecting cable with the extension-
cable (see
H 14).
Insulate the plug connection with the supplied seal strip
(see
H 14 and H 16).
Fasten the cable safely in the vehicle in order to avoid it getting caught
(risk of dropping). This can be done by using
cable belts, insulating belt or by sticking with glue.
Begin with the sealing of the openings only after all
adjustment work at the camera is concluded and the required
lengths of the connecting cables are determined.
Required parts for the cable installation from the monitor to the
camera see
H 13 and H 15).
Attention! The plug connection of the system does not offer any
protection against water penetration. Make absolutely sure to provide
the connection with a seal strip. Self-vulcanizing seal strip e.g. of 3M
is best suited.
Further extension cables can be obtained from your dealer if necessary:
Length Article-No. .
5 m
RV-205
10 m
RV-210
Electrical connection of the monitor see
Connect the monitor connecting cable as follows:
– Red cable to terminal 15 (ignition).
– Black cable to terminal 31 (mass).
– Brown cable to the cable (plus +) back-up light.
– White cable to the cable (plus +) instrument lighting.
Cable laying
H 17).
45
