–Check beforehand whether sufficient free space for the drill -
outlet is present.
–In order to prevent a running of the drill, prick punch before with hammer
and prick punch.
–Debur all drill holes and provide with rust protection.
Drill at the points drawn beforehand a hole of Ø 4 mm.
Screw on camera holder with the metal screws 5 x 20 mm.
(see
G 7).
Necessary parts for the attachment with sheet metal screws
see
G 1 and G 2.
When fastening with thread screws
The following has to be observed when making drill-holes:
–Check beforehand whether sufficient free space for the drill -
outlet is present.
–Pay attention that the nuts cannot pull themselves through
the construction when tightening (use possibly larger washers
or sheet metal plates).
Drill at the points drawn beforehand a hole of Ø 5.5 mm.
Screw on camera holder with the thread screws M 5 x 20 mm or longer
thread screws, depending upon construction strength.
Necessary parts for the attachment with thread screws
see
G 4 and G 5.
Execution of the breakthrough for the connecting cable of the
camera
Observe the information of the cable laying starting from page 27.
For the feed-through of the connecting cable, use depending on the
possibility existing feed-through possibilities like e.g. ventilation grids.
If no feed-throughs are available, then a hole with Ø 13 mm must be
drilled. Check beforehand,
whether sufficient free space is available for the drill outlet.
Drill a hole of Ø 13 mm nearby the camera
(see
G 9).
Debur all drill holes which are made in the sheet metal and provide-
with rust protection.
Provide all sharp-edged openings with a
bushing.
