Attachment of the camera in the camera holder
Use only the hexagon socket screws for theassembly of the camera.
Longer screws damage the camera. .
Insert the camera into the camera holder and align in such a way
that the objective forms an angle of approx. 50° (see
vertical axle of the vehicle.
Fasten the camera loosely with the hexagon socket screws.
The screws are tightened as soon as the alignment of the
camera has taken place by means of the monitor.
In order to minimize the corrosion of the screws, it is recommendable to
grease the threads. .
Necessary parts for the attachment of the camera see
General information on the cable laying!
Unprofessional cable laying and cable connections cause again and again
malfunctions or damage of components.
A proper cable laying or cable connection is the basic prerequesite for a
continuous and faultless functioning of the retrofitted components.
Observe the following points:
– Install the cable, depending on the possibility, always in the interior of the
vehicle, there it is better protected than outside the vehicle. If you install
the cable nevertheless outside the vehicle, pay attention to a safe
attachment (by additional cable clips, insulating tape etc.).
– In order to avoid damage to the cable, keep always sufficient distance to
overheated and moving vehicle parts (exhaust pipes, driving shafts,
generators, ventilators etc.) when installing cables.
– Wrap each connection at the cable (also in the vehicle) tightly with a
good insulating-tape.
– Pay attention when installing the cable that these:
1. are not sharply bent and twisted (see
2. do no rub at the edges,
3. are not installed without protection through sharp-edged openings.
Assembly of the outside camera
Cable laying
G 10) to the
G 10.
