General safety and installation instructions
The following data must be entered again depending upon the vehicle
equipment:
Radio-code...vehicle clock
seat position
Information on the adjustment can be read in the respective operating
instruction.
Warning! Parts of the back-up video system RV 250 which are
fastened in the vehicle, must be fastened in such a way that they do
not detach under any circumstances (hard-braking, traffic accident)
and thus cause injuries of the passengers.
Pay attention when locating the monitor that this is not assembled
within the radius of an AIRBAG. Otherwise danger of injury exists
when released.
Always observe the safety information of the manufacturer! Some
work (e.g. at retaining systems such as AIRBAG etc.) may be
executed only by trained technical personnel!
Attention! Only a diode test lamp (see
A2) may be used for checking the voltage in electrical lines. Test
lamps (see
and so the vehicle electronics can be damaged.
Attention! In order to avoid damage, pay attention that there is
sufficient free space for the drill outlet (see
and treat with anticorrosive agent.
Attention! Observe when installing the electrical connections that
these:
1. are not sharply bent and twisted (see
2. do no scour at edges (see
3. are not installed without protection
through sharp-edged lead-throughs (see
The camera is watertight. The sealings, however, do not withstand a high-
pressure cleaner (see
Do not open the equipment since this impairs the tightness and the
operability (see
Do not pull at the cables since this could impair the tightness and the
operability of the camera (see
The camera is not suitable for operation under water (see
time switch clock on-board computer
A3) with a luminous element draw too high a current
A 6).
A 7).
A 8).
A1) or a voltmeter (see
A 4). Debur each drill
A 5 a)
A 5 b)
A 5) c).
A 9).
35
