Drill a hole of Ø 18 mm behind the monitor.
Debur all drill holes which are made in the sheet metal and provide-
with rust protection.
Provide all sharp-edged openings with a
bushing.
Plug extension cable into the bush "camera" (see
connecting cable into the bush "Power" (see
rear side of the monitor.
Install the connecting cable and the extension cable below
the instrument panel.
Attachment of the monitor in the monitor holder
For the assembly of the monitor in the monitor holder (see
the knurled screws are to be used. Longer screws damage the
monitor.
The sun shield is fastened between the monitor holder and the
monitor.
Hold the monitor with the sun shield in the monitor fixture and
screw in the knurled screws by hand.
Align the monitor and tighten the knurled screws.
Necessary parts for the attachment of the monitor
see
F 13 and F 14.
Attention! If the vehicle height or vehicle length which is entered in
the car documents is modified by the installation of the camera, then
a new inspection by the official bodies responsible (TÜV, DEKRA etc.)
must take place. Let the new acceptance be entered into the car
documents by your appropriate traffic office.
Warning! Select the location of the outside camera in such a way, or
attach it in such a secure manner, that under no circumstances (by
branches brushing against the vehicle roof) can persons hurt
standing in the vicinity.
Since the outside camera should be attached at a height of at least 2
m to allow a reasonable angle of view, ensure that there is a
sufficiently stable workstation.
40
Assembly of the monitor
Assembly of the outside camera
E 5) and
E 6) on the
F 15)
