Audiovox Jensen XCH10RF Owner's Manual

XCH10RF
Owner's Manual
DIGITAL AUDIO
COMPACT DISC CHANGER
Audiovox Electronics Corporation
150 Marcus Boulevard
Hauppauge, NY 11788
1-800-323-4815
www.jensen.com
© 2004 Audiovox
Note: The products pictured in this manual are for illustrative purposes only, intended to
help install and/or operate the product. The actual product you have may be slightly
different from the one illustrated herein.
Thank You!
Thank you for choosing a Jensen product. We hope you will find the instructions in this owner's
manual clear and easy to follow. If you take a few minutes to look through it, you'll learn how to
use all the features of your new Jensen 10-Disc CD Changer for maximum enjoyment.
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Loading the CD Changer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Remote Control Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
XCH10RF
/
v.051604
Introduction
Description
Congratulations on your purchase of the Jensen XCH10RF remote control 10-Disc CD
Changer. This system allows you to easily upgrade your vehicle's existing audio system to
include a quality CD entertainment function. Once installed, this system utilizes an unused FM
frequency on the vehicle's existing audio system to play audio through the existing stereo
speaker system.
Features
XCH10RF CD CHANGER CONTROL
• Remote mount changer holds up to 10 compact discs.
• Remote control with backlit LCD panel displays disc number, track number and function.
• Remote controls include forward and reverse track and disc search, track and disc scan,
CHANGER SCAN REPEAT SHUFFLE
DISC SELECT
shuffle and repeat play, plus high-speed audible cue and review search.
TRACK SKIP SEARCH
• Advanced technology includes 8x oversampling digital filter and twin 1-bit digital/analog
OFF
converters.
/
• The special design allows horizontal, vertical or 45-degree mounting.
Preparation
Getting Started
It's a good idea to read all of the instructions before beginning the installation. We recommend
having your Jensen 10-Disc CD changer installed by a reputable installation shop.
Note: Antenna extensions and adapters may be necessary depending on the type of
vehicle you have. Check with an installation shop before you begin the installation.
Tools and Supplies
The following tools and supplies are needed to install the CD changer.
• Torx type, flat-head and Phillips screwdrivers
• Cordless drill / drill bit set
• Wire cutters and strippers
• Electrical tape
• Crimping tool
• Crimp connections
• Double-sided tape (or wire ties)
• Isopropyl (Rubbing) alcohol
• Paper towels
• RTV silicone sealer
Disconnect Battery
Before you begin, disconnect the battery negative terminal.
