Audiovox XSN1V1 Quick Start Manual

What's in the Box? 1 Mount the Magnetic Mount Antenna
CAUTION: Do not attempt to install, activate, or adjust any of the setting options described in this A. Mount the Magnetic Mount Antenna outside your vehicle, on a clean and dry
Quick Start Guide unless your vehicle is parked in a safe location.
horizontal surface that will always face the sky.
B. The best location is on the roof above the front windshield, centered between
the left and right sides.
1 2 3 4 5
Cable
Sedans and Coupes
Routing Adapter
Alcohol C. Install the Cable Routing Adapter to direct the antenna cable downward, if mounting on an
Prep Pad
edge.
TIP: Use the Alcohol Prep Pad to clean
the surface.
Snap Radio Magnetic Mount Aux In Cable Antenna Alcohol
Antenna Preparation Pad
2 Route the Antenna Cable
A. Tuck the antenna cable under the windshield rubber
molding and run it to the nearest corner.
B. Route the cable out of the molding and into the rubber
weather stripping around the door opening.
C. Lift the weather stripping. Tuck and run the cable
inside it to the bottom of the door opening. Replace the
weather stripping.
D. Pull the cable out and route it toward the power adapter
or cigarette lighter socket location.
E. Plug the Magnetic Mount Antenna connector into the
ANTENNA connector on the Base of Snap.
Pickups and SUVs Convertibles*
* If the antenna can not
be placed above the
windshield, place it on TIP: Include enough slack in your routing to
vehicle hood.
accommodate open doors or the hood lid. Coil
any excess cable in a hidden location and
keep it away from any vehicle pedals or
controls.
3 Find a Location for Snap and Mount It
A. Mount Snap by plugging the Base into the power adapter or cigarette lighter socket.
B. Grasp the rear of Snap's Base and gently push in, while at the same time rotating the Base
slightly to the right and then to the left. Do not push it in by holding the Radio Control Unit or
Place Antenna
Flexible Stalk.
Closer to A-Pillar
if Cable Doesn't Reach
Center of Roof TIP: Choose a socket that doesn't interfere with the driver's vision or access to driving controls, won't
interfere with the deployment of airbags or other safety equipment, and makes Snap easily accessible for
Power Adapter or operation.
Cigarette Lighter
Socket Location
Power Adapter or
Cigarette Lighter
Socket
Flexible Antenna
Plug
Stalk
Antenna
Connector
AUDIO FM
Base
4 Initiate the Courtesy Period 5 Connect the Audio
A. Power on your Snap by pressing the Power button. Ensure the Decide on one of the following in-box audio connection options. Refer to "Connect the Audio" on page
vehicle is outside and the antenna has a clear view of the sky.
23 of the User Guide for details including other connection options.
B. When prompted, press the number button 1, then 2, then 3. The
Option 1: Best: Use the provided Aux In Cable, if your vehicle's stereo system has an auxiliary input jack.
Courtesy Period Begun message will verify that the Courtesy Period
MENU FM
A. Plug one end of the cable into the AUDIO connector on Snap and the other end into the auxiliary
has begun.
input jack on the vehicle's stereo system.
C. You will be notified about the length of the Courtesy Period and
Press 1,2,3
prompted to set up the audio connection. Snap will then tune to B. Turn on your vehicle's stereo system and set it to play from the auxiliary input source.
channel 1.
To Begin
C. You should now hear the XM channel 1. The installation is complete.
TIP: At this point, you should have access to all the channels in a few
minutes. However, leave Snap tuned to channel 1 until you have set up the TIP! Refer to your vehicle's owner's manual to find the location of the auxiliary input jack, or consult the
audio connection. vehicle dealer.
Courtesy
NOTE: If Acquiring Signal or Chk Antenna Connection is displayed, verify Period Begun
that you have mounted and connected the antenna. Refer to "Mount the
Magnetic Mount Antenna" on page 14, or to "Troubleshooting" on page 42 of
the User Guide for additional help. Audio
Connector
AUDIO FM
Aux In
Aux In Cable
continued on other side...
