Installation, Operation,
and Maintenance
Split System
Air-Cooled Condensers — 20 to 120 Tons
CAUJ-C20
CAUJ-C25
CAUJ-C30
CAUJ-C40
CAUJ-C50
CAUJ-C60
CAUJ-C80
CAUJ-D10
CAUJ-D12
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and
air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered
equipment by an unqualified person could result in death or serious injury. When working on the equipment, observe all precautions in the
literature and on the tags, stickers, and labels that are attached to the equipment.
July 2016
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
CAUJ-SVX01E-EN
