NEWLY DEVELOPED AV DISC RECORDER
OFFERING LARGE-CAPACITY RECORDING AND SPEEDY SEARCHES
The WJ-DR200 is a disc based digital recorder capable of
large-capacity recording using DVD RAM disc for video
surveillance applications. Still images are recorded instantly
on receiving a signal from a sensor. Digital technology
yields high image quality, and also makes possible a
recording system with outstanding search functions.

Key Features

High-quality and large-capacity recording with DVD
More than 43,000 high-quality still images can be recorded on a single
DVD RAM disc. In addition, image quality always remains sharp no matter
many times they are played back. Blur-free recording has also been
made possible using a newly developed 3D scan conversion system.
Recording capacity (approx.)
Audio input Pixels
720 x 576
Audio : On
720 x 288
720 x 576
Audio : Off
720 x 288
Three recording methods chosen to suit usage
•
Multi-shot recording
When the sensor activates, the images from security cameras A and B
are recorded continuously and in pairs. The internal video buffer
allows the images
immediately before and
after the instant of sensor
activation to be recorded
without omissions.
The maximum recording rate is 25 fields per second*, and a maximum
of 150 pictures can be recorded. The numbers of frames recorded
before and after the signal input can be preset. *
Fine Normal
15,000-picture 20,000-picture 24,000-picture
22,000-picture 26,000-picture 29,000-picture
23,000-picture 36,000-picture 53,000-picture
43,000-picture 67,000-picture 91,000-picture
Sensor signal Sensor signal
Recording Recording
for field images
•
Single-shot recording
One frame each from
cameras A and B is
recorded in pairs in
response to the sensor
signal input.
•
Time-lapse recording
One frame each from cameras A and B is recorded in pairs at preset
intervals. Sound is also
recorded simultaneously,
giving a clear recorded
overview of a given
situation.
Search by displaying 16 pictures at a time Speedy checking
Rough
Thumbnail searches are possible with 8 or 16 pictures displayed at a
time. Select the desired pictures using the cursor to display the full-
screen image.
Searching is also possible
directly by displaying
pictures for a specified
time, or by selecting from
a list of recording times.
Time
Security camera
A image
Two video input
Security camera
B image
The WJ-DR200 includes two video input jacks A and B, allowing two
security cameras to be connected. Still images from A and B are
recorded continuously in pairs, giving a recorded overview of a given
situation.
WJ-DR
AV Disc Recorder
Sensor signal Sensor signal Sensor signal Sensor signal
Recording Recording Recording
Recording Recording Recording Recording Recording
Select by setting
8 pictures
00015 00016 00017 00018
96/06/04 96/06/04 96/06/04 96/06/04
11:10:07 12:22:25 15:33:52 15:40:42
00019 00020 00021 00022
96/06/04 96/06/04 96/06/04 96/06/04
16:10:11 17:01:44 17:20:20 17:30:55
* In a thumbnail search, only A input images are displayed.
Time
Recording
Time
16 pictures
00001
00002 00003 00004
00005 00006 00007 00008
00009 00010
00011 00012
00013 00014 00015 00016
