This unit is Caller ID compatible. To display the caller's phone
number, you must subscribe to Caller ID service.
Charge the batteries for about 7 hours before initial use.
Please read these Operating Instructions before using the unit and save them for
future reference.
Digital Cordless Phone
Operating Instructions
KX-TCD430NZ
Model No.
Advertisement
Table of Contents
Related Manuals for Panasonic KX-TCD430NZ
Summary of Contents for Panasonic KX-TCD430NZ
-
Page 1: Operating Instructions
Caller ID service. Charge the batteries for about 7 hours before initial use. Please read these Operating Instructions before using the unit and save them for future reference. Digital Cordless Phone Operating Instructions KX-TCD430NZ Model No. -
Page 2: Table Of Contents
Table of Contents Preparation Accessory information ....3 Important information ....4 Location of controls . -
Page 3: Preparation
Preparation Accessory information Thank you for purchasing a new Panasonic digital cordless phone. Dear Purchaser, You have acquired a product made in compliance with the digital enhanced cordless telecommunications (DECT) standard. DECT technology is characterized by high-security protection against interceptions as well as high-quality digital transmission. This telephone was designed for a wide range of applications. -
Page 4: Important Information
Important information General L Use only the power supply included with this product, noted on page 3. L Do not connect the AC adaptor to any AC outlet other than a standard 220–240 V AC outlet. L This product is unable to make calls when: −... -
Page 5: Location Of Controls
Location of controls Handset A Receiver B Display C {k} (Phonebook) D {C} (Talk) E Navigator L{e}{v}: To search for the desired item in the setting menu, caller information or phonebook. L{>}: To select the desired item or move the cursor to the right. L{<}: To go back to the previous display or move the cursor to the left. -
Page 6: Connections
Preparation Connections Hooks LIN E Note: L If the handset is not charged, you cannot make or answer calls. L Never install telephone wiring during a lightning storm. L The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) L Use only the AC adaptor, noted on page Battery installation... -
Page 7: Battery Replacement
If 074 flashes even when the handset batteries have been fully charged, both batteries must be replaced. Important: L Please use only the Panasonic batteries, noted on page 3. L Use only rechargeable batteries. If you install non-rechargeable batteries and start charging, the batteries may leak electrolyte. -
Page 8: Wall Mounting
Preparation Wall mounting Hooks Hook Note: L Make sure the screws are securely fastened to the wall. L Use the following wall template to position the screws before drilling. Setting the time and date Important: 8 cm L Confirm that the AC adaptor is connected. L Ensure that w is not flashing. -
Page 9: Telephone
Telephone Making calls Lift the handset and dial the phone number. L To correct a digit, press {C}, then enter the correct number. Press {C}. When finished talking, press {ih} or place the handset on the base unit. To adjust the receiver volume You can select the desired receiver volume from level 1 to 3. -
Page 10: Answering Calls
Telephone displayed. To turn off key lock, press {j} for about 2 seconds. Note: L Emergency calls cannot be made until key lock is turned off. L Key lock is turned off when the handset is turned off. R button (to use the recall feature) {R} is used to access optional telephone services. -
Page 11: Phonebook
Phonebook Storing phone numbers and names Up to 20 phone numbers can be stored in the phonebook for quick access. Press {j} 2 times. Enter a phone number (24 digits max.). L Each number stored in the phonebook will be given an index number (01–20). This number will be shown to the left of the stored phone number. -
Page 12: Hot Key (Quick Dial)
Making calls using the phonebook Before using this feature, store the desired phone numbers and names into the phonebook (page 11). Press {k}. Press {e} or {v} repeatedly to display the desired entry. Press {C}. Hot key (quick dial) Assigning an entry in the phonebook to a hot key Dial keys {1} to {9} can each be used as a “hot key”, allowing you to dial a number from... -
Page 13: Caller Id Service
Caller ID service Important: L This unit is Caller ID compatible. To display the caller’s phone number, you must subscribe to Caller ID service. After subscribing to Caller ID, this unit will display caller information. For all local and national incoming calls, your display will show the area code (e.g. -
Page 14: Erasing Caller Information
information will be automatically erased. You can easily view caller information and use it to make calls. Press {v}. Press {v} repeatedly to search from the most recent caller information. Example: *1 Shown when this call has already been viewed or answered. Press {C} to call back the displayed party. -
Page 15: Useful Telephone Settings
Useful Telephone Settings Guide to handset settings For your reference, a chart of all items which can be customised for the handset is printed below. Details of each item can be found on the corresponding pages. To enter the 2nd menu, first press {>}. Press {v} repeatedly to display “SETTING HS”, then press {>}. -
Page 16: Handset Settings
Useful Telephone Settings Handset settings Time alarm An alarm will sound for 3 minutes at the set time once or daily. “ONCE”: The alarm will ring only once. “REPEAT DAILY”: The alarm will ring at the set time everyday. “OFF”: Turns this feature off. Set the time and date beforehand (page 8). -
Page 17: Display Options
“ALARM”: For alarm Press {j}. Press {v} repeatedly to display “SETTING HS”, then press {>}. Press {v} repeatedly to display “RINGER OPT”, then press {>}. Press {v} repeatedly to display the desired item, then press {>}. Press {v} repeatedly to select the desired setting from “RING TYPE 1”... -
Page 18: Call Options
Useful Telephone Settings “PHONE NO”: The phone number will be displayed. Press {j}. Press {v} repeatedly to display “SETTING HS”, then press {>}. Press {v} repeatedly to display “DISPLAY OPT”, then press {>}. Press {v} repeatedly to display “TALK MODE”, then press {>}. Press {v} repeatedly to select the desired setting, then press {>}. -
Page 19: Other Options
L If you change the PIN, please write down your new PIN as the unit will not reveal the PIN to you. If you forget your PIN, consult your nearest Panasonic service centre. Press {j}. Press {v} repeatedly to display “SETTING HS”, then press {>}. -
Page 20: Guide To Base Unit Settings
L If you change the PIN, please write down your new PIN as the unit will not reveal the PIN to you. If you forget your PIN, consult your nearest Panasonic service centre. Press {j}. Press {v} repeatedly to display “SETTING BS”, then press {>}. -
Page 21: Setting Call Restriction
Select the desired setting by pressing {1} for 100 ms or {2} for 600 ms. Press {>}, then press {ih}. Setting pause length Press {j}. Press {v} repeatedly to display “SETTING BS”, then press {>}. Press {3}. Enter “0000” (default base unit PIN). L If you changed PIN, enter it (page 20). -
Page 22: Default Settings
Press {C}. Press {>}, then press {ih}. Storing emergency numbers This feature determines which phone numbers may be dialled while the call bar feature is turned on. A total of 4 emergency numbers (memory locations 1–4) can be stored. Press {j}. Press {v} repeatedly to display “SETTING BS”, then press {>}. -
Page 23: Multi-Unit Operation
Multi-unit Operation Operating additional units Additional handsets Up to 6 handsets can be registered to a single base unit. Additional handsets will give you the freedom to, for example, have an intercom call with another handset while a third handset is on an outside call. See page 3 for information on ordering additional handsets. -
Page 24: Selecting A Base Unit
successfully, a confirmation tone will sound, and w will stop flashing. Note: L If all registered handsets start ringing in step 5, press {x} to stop, then start again from step 1. Selecting a base unit When “AUTO” is selected, the handset will automatically use any available base unit it is registered to. -
Page 25: Setting All Or Selected Handsets To Ring
Setting all or selected handsets to ring You can select one of 3 methods to determine how the handsets ring for incoming calls. − “1”: All handsets will ring. − “2”: Selected handset(s) will ring. − “3”: Selected handset(s) will ring, then all handsets will ring. -
Page 26: Intercom Between Handsets
Multi-unit Operation Intercom between handsets You can make intercom calls between 2 handsets in the same radio cell. Example: When handset 1 calls handset 2 Handset 1: Press {INT} and {2} (desired handset number). Handset 2: Press {C} to answer. When finished talking, press {ih}. -
Page 27: Useful Information
Useful Information Troubleshooting If you still have difficulties after following the instructions in this section, disconnect the AC adaptor and turn off the handset, then reconnect the AC adaptor and turn on the handset. 0w4 is flashing. L The handset is not registered to the base unit. - Page 28 (page 24). L You entered the wrong PIN number. If you forget your PIN, consult your nearest Panasonic service centre. L Locate the handset and the base unit away from other electrical appliances.
-
Page 29: Technical Information
Technical information Standard: DECT (Digital Enhanced Cordless Telecommunications), GAP (Generic Access Profile) Number of channels: 120 Duplex Channels Frequency range: 1.88 GHz to 1.9 GHz Duplex procedure: TDMA (Time Division Multiple Access) Channel spacing: 1728 kHz Bit rate: 1152 kbit/s Modulation: GFSK (Gaussian Frequency Shift Keying) RF Transmission Power: Approx. -
Page 30: Index
Index Index Index A Additional base units: 23 Additional handsets: 23 All handsets to ring: 25 Selected handsets to ring: 25 Answering calls: 10 Auto talk: 10 B Base unit Cancelling: 24 Guide to settings: 20 PIN: 20 Resetting: 22 Selecting: 24 Battery Charge: 6... - Page 32 350 Te Irirangi Drive East Tamaki Private Bag 14911 Panmure Auckland NEW ZEALAND Manufacturer: Panasonic Communications Zhuhai Co., Ltd. 3 Ping Xi 8 Lu, Nanping Keji Gongye Yuan, Zhuhai, Guangdong, China 519060 © 2004 Panasonic Communications Co., Ltd. All Rights Reserved. PQQX14071ZA DC0204PN0...
