3-6-3 MAIN-A UNIT
LINE
Receive 8 V converted from the 14 V line and
R8V regulated by the R8V regulator circuit (Q601,
Q602, D601).
Transmit 8 V converted from the 14 V line and
T8V regulated by the T8V regulator circuit (Q611,
Q612, D611).
3-6-4 CTRL AND PLL UNITS
LINE
Common 5 V for the antenna tuner CPU (CTRL
unit; IC5) and the EEPROM (CTRL unit; IC6),
5V
converted from the 14 V line and regulated by
the +5 regulator circuit (CTRL unit; IC13).
Common 5 V for each PLL-A and PLL-B circuits
regulated from the 8 V line and regulated by the
5V
+5 regulator circuit (PLL unit; IC382: PLL-A,
IC682: PLL-B).

3-7 LOGIC CIRCUITS

3-7-1 BAND SELECTION DATA
(RF-A, CTRL AND PLL UNITS)
To select the correct bandpass, low-pass filters and VCOs
on the RF-A, FILTER and PLL units, the main CPU (MAIN-
A unit, IC3501) outputs the following band selection data via
the I/O expander (RF-A unit, IC901, IC902, CTRL unit, IC11)
or DDS IC (PLL unit, IC101, IC401) depending on the dis-
played frequency.
IC901, IC902
Frequency
(RF-A unit) (CTRL)
[MHz]
BPF
0.003–1.599999 B0
1.6–1.999999 B1
2.0–2.999999 B2
3.0–3.999999 B3
4.0–5.999999 B4
6.0–7.999999 B5
8.0–10.999999 B6
11.0–14.999999 B7
15.0–19.999999
B8
20.0–21.999999
22.0–29.999999 B9
30.0–44.999999
B10W
45.0–49.999999
50.0–54.000000 B10
54.000001–
B10W
60.000000
The D/A convertor (MAIN-A unit, IC3751) output signal from
pin 7 is amplified at IC101b (pins 5–7) to obtain the band volt-
age for external equipment via the [ACC 2] connector pin 4.
DESCRIPTION
DESCRIPTION
IC11 IC101 IC401
(PLL) (PLL)
LPF VCO-A VCO-B
L1S
VA1S VB1S
L2S
L3S
L4S
VA2S VB2S
L5S
L6S VA3S VB3S
L7
VA4S VB4S
3-7-2 SUB-CPU PORT ALLOCATIONS
(DISPLAY BOARD; IC401)
Pin Port
number name
OSC1,
7, 8
OSC2
9 DRES
MSB,
12, 83
MSA
DOTK,
56, 57
DSHK
MDM0–
64–66
MDM2
TNRD, MOND
NBD, NRD
LOCD, TXD
67–75
RXD, PBTD
NOTD
PB1B,
77, 79
PB1A
81 METV
RSA,
82, 84
RSB
PB2A,
85, 88
PB2B
86 LMFD
87 LFMD
92 BALL
93 NRL
94 MIGL
95 PWRL
CMPL
96
97 KYSL
98 DELL
NOTL
99
100 PITL
3 - 10
Description
Input and output ports for the system
clock oscillator (X401; 9.8304 MHz).
Input port for the reset signal.
Input port for the [DIAL]; pulse-type
signals are applied.
Input ports for the [ELEC-KEY] jack.
Output ports for the S/RF meter back-
light and function switch activation
indicator brightness control signal.
Backlight level
Port
1 2 3 4
High Low High Low High
MDM0
Low High High Low Low
MDM1
MDM2 Low Low Low High High High High
Control signal output ports for the acti-
vation indicator of function switches.
High: When the function is activated.
Input port for the [TWIN PBT (inner)]
control (PBT board, S1/inner).
Outputs the S/RF meter (ME1) drive
signal.
Input ports for the [RIT/∆TX] control;
pulse-type signals are applied.
Input port for the [TWIN PBT(outer)]
control (PBT board, S1/outer).
Input port for data signal from the
main-CPU (MAIN unit; IC3501).
Outputs data signal for the main-CPU
(MAIN unit; IC3501).
A/D input port for the [BAL] control
(R702/ inner).
A/D input port for the [NR] control
(R702/ outer).
A/D input port for the [MIC GAIN] con-
trol (R712).
Input port for the [RF POWER] control
(R714).
Input port for the [COMP] control
(R716).
Input port for the [KEY SPEED] control
(R718).
Input port for the [BK-IN DELAY] con-
trol (R720).
Input port for the [NOTCH] control
(PBT board, R1/inner).
Input port for the [CW PITCH] control
(PBT board, R1/outer).
5 6 7
Low High
High High
