bizhub 226
USER'S GUIDE
Copy

Advertisement

Table of Contents
loading

Related Manuals for Konica Minolta BIZHUB 226

Summary of Contents for Konica Minolta BIZHUB 226

  • Page 1 226 USER’S GUIDE Copy...

  • Page 3: Table Of Contents

    Loadable number of sheets ....................... 3-5 3.1.4 Precautions for using paper....................... 3-5 Image copy/printing area ....................... 3-6 Storing paper........................... 3-7 Loading paper ..........................3-8 3.4.1 Loading paper into Tray1 ........................3-8 3.4.2 Loading paper to Tray2/Tray3/Tray4/Tray5 ..................3-9 bizhub 226 Contents-1...
  • Page 4 Making Copies in Advanced Manner Finishing setting (sorting, grouping) ..................... 5-3 5.1.1 Finishing type............................. 5-3 5.1.2 Setting finishing ..........................5-5 Making 1-sided or 2-sided copy ....................5-6 Configuring 2in1 or 4in1 copy settings ..................5-8 Using the ID Copy ......................... 5-10 Contents-2 bizhub 226...
  • Page 5 Specifying the quality priority......................6-24 6.7.4 Specifying the density priority......................6-25 6.7.5 Specifying the density level priority (Auto) ..................6-25 6.7.6 Specifying the density level priority (Manual)................... 6-26 6.7.7 Setting 2-sided printing ........................6-26 6.7.8 Setting the copy page margin......................6-27 bizhub 226 Contents-3...
  • Page 6 If this copy is output ........................7-3 Major messages and troubleshooting ..................7-5 The copier does not function......................7-7 Others Major specifications ........................8-3 8.1.1 bizhub 226 ............................8-3 8.1.2 Reverse Automatic Document Feeder DF-625 .................. 8-4 8.1.3 Paper Feeder Unit PF-507 ......................... 8-4 8.1.4 Automatic Duplex Unit AD-509......................

  • Page 7: Introduction

    Introduction...

  • Page 9: Welcome

    Note that basic technical knowledge about the product is required to enable users to perform maintenance work or troubleshooting operations. Limit your maintenance and troubleshooting operations to the areas ex- plained in this manual. Should you experience any problems, please contact our service representative. bizhub 226...

  • Page 10: Conventions Used In This Manual

    This symbol indicates transition of the Display to access a desired menu item. UTILITY MODE MACHINE SETTING PAPER SOURCE SETUP CUSTOM SIZE MENORY DRUM DEHUMIDIFY This symbol indicates a desired page. bizhub 226...

  • Page 11: Key Symbols

    X side the length. Original and paper indications w indicates the paper size with the length (X) being longer than the width (Y). v indicates the paper size with the length (X) being shorter than the width (Y). bizhub 226...
  • Page 12 Conventions used in this manual bizhub 226...

  • Page 13: Before Using This Machine

    Before Using This Machine...

  • Page 15: Part Names And Their Functions

    The original is scanned by the scanner section, and the scanned image is printed by the printer section. The main unit is hereinafter referred to as "this machine", "main unit", or bizhub 226 through this manual. Original Cover OC-512 Fixes the loaded originals.
  • Page 16 For details, refer to the [User's Guide Network Administrator]. FAX Kit FK-510 Allows this machine to function as a fax machine. Alternative- ly, it allows more telephone lines to be connected. Indicates a built-in option that is not shown in the figure above. bizhub 226...

  • Page 17: Main Body

    Main Body Main Body 2.2.1 Exterior of the main unit bizhub 226...
  • Page 18 Auto Duplex Unit 1st Side Cover USB Port (Host:Scan to USB) Jack for connecting a telephone (TEL PORT) Telephone Jack (LINE PORT) USB Port (Type B) USB 2.0/1.1 Network Connector (10 Base-T/100 Base-TX) Total Counter Main Power Switch Control Panel bizhub 226...

  • Page 19: Interior Of The Main Unit

    Main Body 2.2.2 Interior of the main unit Name Original Pad Original Scale Slit Scan Glass Toner Bottle Drum Unit Fusing Unit Release Lever Original Glass bizhub 226...

  • Page 20: Reverse Automatic Document Feeder (Option)/Automatic Duplex Unit (Option)

    Main Body 2.2.3 Reverse Automatic Document Feeder (Option)/Automatic Duplex Unit (Option) Reverse Automatic Document Feeder Name Lateral Guide Document Feeder Cover Original Tray Original Output Tray Stopper Automatic Duplex Unit Name Duplex Cover bizhub 226...

  • Page 21: Paper Feeder Unit (Option)

    Main Body 2.2.4 Paper Feeder Unit (Option) Name 1 to 4 Tray 2/3/4/5 2nd/3rd/4th/5th Side Cover bizhub 226...

  • Page 22: Control Panel

    Press this key to copy a multi-page original on one p. 5-8 Combine Original sheet. Press this key to select the copy finishing mode. p. 5-5 Finishing Press this key to use the 1-Sided or 2-Sided printing p. 5-6 Simplex/Duplex function. 2-10 bizhub 226...
  • Page 23 Lights up blue when the machine is ready to ac- cept a copy job, and lights up orange when the machine is not ready to start a copy operation. • Specify the number of copies. Keypad • Enter various settings. bizhub 226 2-11...

  • Page 24: Extended Operation Panel Mk-749 (Option)

    One-Touch Dial Key • Press this key to dial a pre-registered destination. • Use keys 01 to 32 to configure one-touch dial key and group dial settings. • Use keys 29 to 32 to configure program dial set- tings. 2-12 bizhub 226...

  • Page 25: Display Message

    Indicates that Tray2 is selected. Indicates that Tray3 is selected. Indicates that Tray4 is selected. Indicates that Tray5 is selected. Indicates that Bypass Tray is selected. Paper size Displays the selected paper size. [X/Y] Indicates that custom size paper is set. bizhub 226 2-13...
  • Page 26 Indicates that Recycled Paper is selected. Indicates that Special Paper is selected. Indicates that Single Side Only is selected. Indicates that Thick 1 is selected. Indicates that Thick 2 is selected. Indicates that Transparency is selected. Indicates that Envelope is selected. 2-14 bizhub 226...
  • Page 27 If [MANUAL] is selected, the density is displayed on a level one to nine on the copy mode screen. Message display Displays the status of this machine and the status of the PC printing in copy mode. bizhub 226 2-15...
  • Page 28 The upper icon indicates that Sort is selected. The low- er icon indicates that Group is selected. Indicates that ID Copy is selected. Indicates that Page Margin is selected. Indicates that Neg./Pos. Reverse is selected. Indicates that Stamp is selected. Simplex/Duplex is selected. 2-16 bizhub 226...
  • Page 29 The edges of copied text are reproduced with sharpness, providing an image that is easy to read. You can select this setting in combination with the Auto Density mode. Mode or function Displays setting menus or options. bizhub 226 2-17...

  • Page 30: Power

    The time period until the auto panel reset function is enabled can be set to 30 seconds or between one and five minutes. The auto panel reset function can be disabled. For details, refer to page 6-5. 2-18 bizhub 226...

  • Page 31: Sleep Mode

    This function reserves the next copy job by loading the original when [Warming Up] is displayed on the Display and Start is pressed. When Warming Up disappears, scanning of the loaded original starts to perform copy operation. bizhub 226 2-19...

  • Page 32: Saving Electricity

    Use +,, to select [SLEEP MODE], then press OK. Enter time until the function is enabled using the Keypad, then press OK. SLEEP MODE 15min(1-240min) Tips Timer setting can be configured between one and 60 minutes. To correct the value, press Clear/Stop. 2-20 bizhub 226...

  • Page 33: Specifying The Auto Shut Time

    180min(15-240min) If the auto shut time is already specified, the currently specified time is displayed. Press OK. Tips The timer can be specified to be between 15 and 240 minutes. To correct the numeric value, press Clear/Stop. bizhub 226 2-21...
  • Page 34 Saving electricity 2-22 bizhub 226...

  • Page 35: Before Making Copies

    Before Making Copies...

  • Page 37: Paper

    157 g/m (64 to 90 g/m Others Bypass Tray Tray1 Tray2 Tray3 Tray4 Tray5 Paper type Special paper Transparency Envelope Paper source/ Others Bypass Tray Tray1 Tray2 Tray3 Tray4 Tray5 o: Loadable -: Not loadable Tips Tray2/Tray3/Tray4/Tray5 are optional. bizhub 226...

  • Page 38: Paper Size

    B4 w A4 w A4 v A5 w A5 v Paper LGL w LTR w LTR v INV w INV v source/ Others Bypass Tray Tray1 Tray2 Tray3 Tray4 Tray5 o: Loadable -: Not loadable Tips Tray2/Tray3/Tray4/Tray5 are optional. bizhub 226...

  • Page 39: Loadable Number Of Sheets

    Paper that has been decorated with foil or embossing Paper of a non-standard shape (paper that is not rectangular) Paper that is bound with glue, staples or paper clips Paper with labels attached Paper with ribbons, hooks, buttons, etc., attached bizhub 226...

  • Page 40: Image Copy/Printing Area

    (full size) (C) Paper output direction A, B, C: 3/16 inch (4 mm) (at full size) Reference If documents are printed from the computer or if an optional Image Controller IC-209 is installed, refer to [User's Guide Print]. bizhub 226...

  • Page 41: Storing Paper

    Dusty locations Once paper is taken out of a packet, put it in a plastic bag and be sure to store it in a cool and dark location. Do not place paper within reach of infants or children. bizhub 226...

  • Page 42: Loading Paper

    % Be sure to load the paper below the tab, so that the stack height does not exceed the , mark. Adjust the lateral guide to the size of the paper. % Push the lateral guide firmly up against the edges of the paper. Reset the tray. bizhub 226...

  • Page 43: Loading Paper To Tray2/Tray3/Tray4/Tray5

    % Be sure to load the paper below the tab, so that the stack height does not exceed the , mark. Adjust the lateral guide to the size of the paper. % Push the lateral guide firmly up against the edges of the paper. Reset the tray. bizhub 226...

  • Page 44: Original

    Highly translucent or transparent 11 e 17w to 5-1/2 e 8-1/2w/v original, book original, three-di- (A3w to A5w/v) mensional objects Original width: Max. 11-11/16 Max. weight: 4-7/16 lb (2 kg) inches (297 mm) Original length: Max. 17 inches (431.8 mm) 3-10 bizhub 226...

  • Page 45: Precautions On Originals

    When you set the original of custom size on the Original Glass, you cannot use the Auto Paper and Auto Zoom functions. If you set the original of custom size, press Paper to select paper used for cop- ying or press Zoom to select the zoom ratio. For details, refer to page 4-20. bizhub 226 3-11...

  • Page 46: Loading The Original

    Tips If you load the original with two sides into the ADF, the front and back side of the original are inversely scanned automatically. For details on how to copy a 2-sided original, refer to page 5-6. 3-12 bizhub 226...

  • Page 47: Setting The Original On The Original Glass

    Original Glass. Gently close the ADF. Tips You can copy the 2-sided original by setting it on the Original Glass. For details on how to copy a 2- sided original, refer to page 5-6. bizhub 226 3-13...

  • Page 48: Loading The Highly Translucent Or Transparent Original

    % Set the original along the Original Scale on the left and at the top of the Original Glass. Place a blank sheet of paper that is the same size as the original over the original. Gently close the ADF. 3-14 bizhub 226...

  • Page 49: Setting The Book Original

    % For book separation copy, place the top part (upper part) of the original at the back side, and align the cent- er of the book original with — mark of the Original Scale at the back. Gently close the ADF. bizhub 226 3-15...

  • Page 50: Setting Originals Of Different Sizes (Mixed Original)

    Adjust the Lateral Guide to the original size. % If the original is not loaded correctly, it may not be fed in straight. Press Mixed Original. Mixed Original lights up. Press Paper. 3-16 bizhub 226...
  • Page 51 Press the Start key. Tips The mixed original setting, the auto zoom setting, 1side % 2side copy setting, the book separation copy setting, ID copy setting, 2 in 1/4 in 1 copy setting cannot be set at the same time. bizhub 226 3-17...
  • Page 52 Loading the original 3-18 bizhub 226...

  • Page 53: Making Copies

    Making Copies...

  • Page 55: Copy

    % Press Clear/Stop to clear the number of copies you have set. Press the Start key. Copying begins. % To stop the copy operation being performed, press Clear/Stop. % For details on stopping copying, refer to page 4-7. bizhub 226...

  • Page 56: Reducing Or Enlarging A Standard Size Original To A Different Standard Size

    Use +,to select [TEXT/PHOTO], [TEXT], or [PHOTO], then press OK. The screen returns to the basic screen. Configure other desired settings. % For details on the basic functions, refer to page 4-3. % For details on the Application, refer to page 5-3. Press the Start key. bizhub 226...

  • Page 57: Specifying The Density

    % For details on the basic functions, refer to page 4-3. % For details on the Application, refer to page 5-3. Press the Start key. Tips You cannot specify the automatic density control and the [PHOTO] image quality setting at the same time. bizhub 226...

  • Page 58: Setting The Original Direction

    The screen returns to the basic screen. Configure other desired settings. % For details on the basic functions, refer to page 4-3. % For details on the Application, refer to page 5-3. Use the Keypad to specify the number of copies, then press Start. bizhub 226...

  • Page 59: Stopping, Restarting, Or Erasing The Copy Job

    Press Clear/Stop when copying operations were being carried out. The [Please wait] message appears and the job stops. % To restart the stopped job, select [NO], then press OK. % To erase the stopped job, select [YES], then press OK. bizhub 226...

  • Page 60: Selecting The Tray

    If all trays have run out of paper, replenish paper according to the on-screen instructions. Even if you load paper to a tray other than the tray displayed on the screen, copy or print operations may not re- start. bizhub 226...

  • Page 61: Tray Selection Order By Tray Change Function

    For details on how to set special paper, refer to page 4-15 or page 6-12. When a priority tray is set in the Utility menu, that tray is given priority. For details on the setting proce- dure, refer to page 6-24. bizhub 226...

  • Page 62: Manually Making Copies

    Width: 3-9/16 inches to 11-11/16 inches (90 mm to 297 mm) Length: 5-1/2 inches to 17 inches (140 mm to 432 mm) 4.4.2 Adjusting the Bypass Tray You can adjust the Bypass Tray Extension to fit the paper size as shown below. 4-10 bizhub 226...

  • Page 63: Loading Plain Paper Into The Bypass Tray

    For details on how to set the size and type of paper, refer to Steps 4 to 7 in page 4-15. % The relation between the orientation of the original image and that of the copy image to be printed on paper is as shown below. bizhub 226 4-11...

  • Page 64: Loading Ohp Transparencies Into Bypass Tray

    For details on how to set the size and type of paper, refer to Steps 4 to 7 in page 4-15. % The relation between the orientation of the original image and that of the copy image to be printed on OHP transparencies is as shown below. 4-12 bizhub 226...

  • Page 65: Loading Envelopes Into The Bypass Tray

    For details on how to set the size and type of paper, refer to Steps 4 to 7 in page 4-15. NOTICE Do not load envelopes in the v direction. Do not load envelopes with the flap side down. Do not load envelopes with the flap side placed as the trailing edge. bizhub 226 4-13...
  • Page 66 Manually making copies The relation between the orientation of the original image and that of the copy image to be printed on enve- lopes is as shown below. 4-14 bizhub 226...

  • Page 67: Manually Making Copies (Bypass Tray)

    % When you want to change the size or type settings, take out the set paper and repeat Step 2 to 8. Configure other desired settings. % For details on the basic functions, refer to page 4-3. % For details on the Application, refer to page 5-3. Press the Start key. bizhub 226 4-15...

  • Page 68: Making Copies On Various Types Of Paper

    Use +, to select [AUTO], then press OK. TRAY1 PAPER TYPE AUTO Use +, to select [TRAY1], then press OK. Use +, to select [PAPER TYPE], then press OK. Use +, to select [TRANSPARENCY], then press OK. TRAY1 PAPER TYPE TRANSPARENCY CARD1 CARD2 ENVELOPE 4-16 bizhub 226...

  • Page 69: Making Copies On Custom Size Paper

    % To correct the entered value, press Clear/Stop. BYPASS PAPER SIZE X=150(140-432) Y= 90( 90-297) Input=10key (Fin.=OK) % Refer to the illustration below to enter the length (X) and width (Y) of the paper correctly. 1. Length (X) 2. Width (Y) bizhub 226 4-17...
  • Page 70 Press Back to return to the basic screen. Configure other desired settings. % For details on the basic functions, refer to page 4-3. % For details on the Application, refer to page 5-3. Press the Start key. 4-18 bizhub 226...

  • Page 71: Making Copies On Envelopes

    Press Back to return to the basic screen. Configure other desired settings. % For details on the basic functions, refer to page 4-3. % For details on the Application, refer to page 5-3. Press the Start key. bizhub 226 4-19...

  • Page 72: Specifying The Zoom Ratio To Copy The Original

    The auto zoom setting and the auto paper setting, the mixed original setting, the book separation copy setting, the ID copy setting, or the 2 in 1/4 in 1 copy setting cannot be set at the same time. 4-20 bizhub 226...

  • Page 73: Setting The Fixed Zoom Ratio

    % For details on the Application, refer to page 5-3. Press the Start key. Tips The manual zoom setting and the mixed original setting, the ID copy setting, or the 2 in 1/4 in 1 copy setting cannot be set at the same time. bizhub 226 4-21...

  • Page 74: Setting The X/Y Variable Zoom Ratio

    Press the Start key. Tips The X/Y variable zoom ratio setting and the auto paper setting, the mixed original setting, the ID copy setting, or the 2 in 1/4 in 1 copy setting cannot be set at the same time. 4-22 bizhub 226...

  • Page 75: Changing Copy Density To Copy The Original

    MANUAL The screen returns to the basic screen. Configure other desired settings. % For details on the basic functions, refer to page 4-3. % For details on the Application, refer to page 5-3. Press the Start key. bizhub 226 4-23...

  • Page 76: Confirming The Machine Counter

    Use +, to select [TOTAL PAGE], then press OK. Use +, to confirm each count value. TOTAL PAGE TOTAL COUNT:000000 SIZE COUNT :000000 TOTAL SCAN :000000 COLOR SCAN :000000 Press OK. The screen returns to the basic screen. 4-24 bizhub 226...

  • Page 77: Printing Reports

    Use +, to select the list to be printed, then press OK. PRINT REPORT TX RESULT REPORT ACTIVITY REPORT MEMORY DATA LIST MEMORY IMAGE PRINT The report is printed and the screen returns to the basic screen. bizhub 226 4-25...
  • Page 78 Printing reports 4-26 bizhub 226...

  • Page 79: Making Copies In Advanced Manner

    Making Copies in Advanced Manner...

  • Page 81: Finishing Setting (Sorting, Grouping)

    When copying or printing two or more sets, you can copy each set in order of page (Sort) or make copies by page (Group). 5.1.1 Finishing type Non-sort: Copies the original without sorting them. Sort: Automatically sorts and copies a multi-page original per set. Group: Sorts and copies a multi-page original per page. bizhub 226...
  • Page 82 – Auto Paper is set. – Mixed Original is not set. – Book Separation is not set. – In the Utility menu, [CRISSCROSS MODE] is set to [ON]. (For details, refer to page 6-32.) bizhub 226...

  • Page 83: Setting Finishing

    Set the next original and press OK. Repeat this operation the same number of times as there are originals. When all pages have been scanned, press Start. Tips If the optional Reverse Automatic Document Feeder DF-625 is not installed, [GROUP] will not be dis- played. bizhub 226...

  • Page 84: Making 1-Sided Or 2-Sided Copy

    Select [LEFT], [RIGHT], or [TOP], then press OK. % When you select [2-SIDE % 2-SIDE] and press ), you can specify the binding position for the orig- inal. When you press ) next, you can specify the binding position for the printed sheets. Press OK. bizhub 226...
  • Page 85 The 1side % 2side setting and the mixed original setting or ID copy setting cannot be set at the same time. The 2side % 1side setting or the 2side % 2side setting and the book separation setting or ID copy set- ting cannot be set at the same time. bizhub 226...

  • Page 86: Configuring 2In1 Or 4In1 Copy Settings

    Copies images of four original pages on one sheet of paper. Horizontal Vertical Load the original. % For details on how to load the original, refer to page 3-12. Press Combine Original. The screen for setting up the 2in1 and 4in1 appears. bizhub 226...
  • Page 87 The 2 in 1/4 in 1 copy setting and the manual zoom setting, the X/Y variable zoom ratio setting, the mixed original setting, the book separation copy setting, the ID copy setting, the page margin setting, or the erase setting cannot be set at the same time. bizhub 226...

  • Page 88: Using The Id Copy

    The ID copy setting and the auto paper setting, the zoom setting, the mixed original setting, the book sepa- ration copy setting, the 2-sided copy setting, the 2 in 1/4 in 1 copy setting, the page margin setting, or the erase setting cannot be set at the same time. 5-10 bizhub 226...

  • Page 89: Making Copies By Entering The Id (Account) Number

    Press the Start key. When the copy operation completes, press Access again. The screen for entering the ID (Account) appears. Tips If the auto panel reset time has elapsed, the screen for entering the ID (Account) appears. bizhub 226 5-11...

  • Page 90: Setting Book Separation Copy

    The binding position can be changed at [BINDING POSITION] in the Utility menu. For details, refer to page 6-28. Use +, to select [ERASE], then press OK. 5-12 bizhub 226...

  • Page 91: Frame/Center Erase Type

    Copy inal and copy data. [CENTER] Erases the center area of the Original Copy original and copy data. [CENTER + FRAME] Erases the area to the outside Original Copy and center of the original and copy data. bizhub 226 5-13...

  • Page 92: Erasing A Part Of The Original And Making Copies (Erase)

    5.7.1 Precautions when making copies in the erase mode When you make copies in the erase mode, exercise care regarding the direction in which the original is load- Finishing Original Glass Left erase Upper erase Frame erase 5-14 bizhub 226...

  • Page 93: Setting The Erase

    [LEFT] or [UPPER] for [ERASE] and the book separation copy setting, the ID copy setting, or 2 in 1/4 in 1 copy setting cannot be set at the same time. [FRAME] for [ERASE] and the ID copy setting or 2 in 1/4 in 1 copy setting cannot be set at the same time. bizhub 226 5-15...

  • Page 94: Making Copies With Black And White Reversed (Neg./Pos. Reverse)

    Configure other desired settings. % For details on the basic functions, refer to page 4-3. % For details on the Application, refer to page 5-3. Use the Keypad to specify the number of copies, then press Start. 5-16 bizhub 226...

  • Page 95: Making Copies With A Binding Margin

    If you set a binding margin for the paper on which you want to copy data, you will be able to easily file the pages. 5.9.1 Precautions when making copies with a binding margin When you make copies with a binding margin, exercise care regarding the direction in which the original is loaded. Original Glass bizhub 226 5-17...

  • Page 96: Setting A Binding Margin

    Use the Keypad to specify the number of copies, then press Start. Tips The binding margin setting and the ID copy setting or the 2 in 1/4 in 1 copy setting cannot be set at the same time. 5-18 bizhub 226...

  • Page 97: Making Copies With A Date And

    Configure other desired settings. % For details on the basic functions, refer to page 4-3. % For details on the Application, refer to page 5-3. Use the Keypad to specify the number of copies, then press Start. bizhub 226 5-19...

  • Page 98: Registering Or Recalling The Copy Settings

    The current copy setting is registered. MODE MEMORY REGIST. PROGRAM1 PROGRAM2 % If you register a new copy setting to a program number for which a program has been already reg- istered, the previous copy setting is erased. 5-20 bizhub 226...

  • Page 99: Recalling The Copy Setting And Making Copies

    The program screen appears. Use +, to select [RECALL], then press OK. Use +, to select the program number to be recalled, then press OK. The selected program is recalled. MODE MEMORY RECALL PROGRAM1 PROGRAM2 Press the Start key. bizhub 226 5-21...
  • Page 100 Registering or recalling the copy settings 5.11 5-22 bizhub 226...

  • Page 101: Utility And Copy Settings

    Utility and Copy Settings...

  • Page 103: Utility

    IC-209 or Network Card NC-504 is installed in this machine. For details, refer to [User's Guide Network Scan]. Tips Some items cannot be configured depending on which optional device is installed in this machine. If an unavailable item is selected, an error message appears. bizhub 226...

  • Page 104: Machine Setting

    IC-209, or Network Card NC-504 is installed. You can set re- maining amount of memory when you interrupt to scan the original because the memory becomes full. • The factory default is [512Kbyte]. For details, refer to [User's Guide Fax]. bizhub 226...

  • Page 105: Select Machine Setting

    Use +, to select [AUTO PANEL RESET], then press OK. Use +, to select [OFF], [30 sec], [1 min], [2 min], [3 min], [4 min], or [5 min], then press OK. AUTO PANEL RESET 30sec 1min 2min This returns to the Machine Setting screen. bizhub 226...

  • Page 106: Changing The Sleep Mode Setting

    % If you select [ON], enter the time required to automatically turn the power off using the Keypad, then press OK. AUTO SHUT TIME 180min(15-240min) % The timer can be specified between 15 and 240 minutes. % To correct the numeric value, press Clear/Stop. This returns to the machine setting screen. bizhub 226...

  • Page 107: Changing The Image Quality When Using The Adf

    % For details on selecting [MACHINE SETTING], refer to page 6-5. Use +, to select [DENSITY(BOOK)], then press OK. Use +, to select [MODE1] or [MODE2], then press OK. DENSITY(BOOK) MODE1 MODE2 This returns to the Machine Setting screen. bizhub 226...

  • Page 108: Changing The Density

    % For details on selecting [MACHINE SETTING], refer to page 6-5. Use +, to select [LCD CONTRAST], then press OK. Use *) to select the contrast level, then press OK. LCD CONTRAST This returns to the Machine Setting screen. bizhub 226...

  • Page 109: Changing Key Speed Setting

    Use +, to select [INTERVAL], then press OK. Use +, to select the key speed changing interval, then press OK. INTERVAL 0.1sec 0.3sec 0.5sec 1.0sec The screen returns to the one for setting key speed. % Press Back to return to the Machine Setting screen. bizhub 226...

  • Page 110: Changing The Language To Be Displayed On The Display

    % For details on selecting [MACHINE SETTING], refer to page 6-5. Use +, to select [LANGUAGE], then press OK. Use +, to select the language, then press OK. LANGUAGE ENGLISH GERMAN FRENCH ITALIAN This returns to the Machine Setting screen. 6-10 bizhub 226...

  • Page 111: Tray Settings

    Same as TRAY2. [TRAY4] Same as TRAY2. [TRAY5] Same as TRAY2. 6.3.1 Selecting tray settings Press the Utility key. The Utility screen appears. Use +, to select [PAPER SOURCE SETUP], then press OK. The Tray Settings screen appears. bizhub 226 6-11...

  • Page 112: Setting The Unit Of The Paper Size

    OK. TRAY1 PAPER SIZE X=210(140-432) Y=297( 90-297) Input=10key (Fin.=OK) This returns to the Tray Settings screen. % To continuously set the paper type, go to Step 5. Use +, to select [PAPER TYPE], then press OK. 6-12 bizhub 226...

  • Page 113: Configuring Settings For Tray2 To Tray5

    % For details on setting the unit of the paper size, refer to page 6-12. Use +, to select [PAPER TYPE], then press OK. TRAY2 INCH/METRIC PAPER TYPE Use +, to select the paper type, then press OK. This returns to the Tray Settings screen. bizhub 226 6-13...

  • Page 114: Registering A Custom Size

    % Refer to the illustration below to enter the length (X) and width (Y) of the paper correctly. % Enter the paper length (X) within the range from 140 mm to 432 mm. % To correct the entered value, press Clear/Stop. 1. Length (X) 2. Width (Y) 6-14 bizhub 226...
  • Page 115 X=200(140-432) Y=130( 90-297) % Enter the paper width (Y) within the range from 90 mm to 297 mm. % To correct the entered value, press Clear/Stop. The screen returns to the one for registering a custom size. bizhub 226 6-15...

  • Page 116: Drum Dray (Dew Condensation Removal)

    Use +, to select [DRUM DEHUMIDIFY], then press OK. The Drum Dry screen appears. Use ,+ to select [DRUM DEHUMIDIFY], then press OK. ACCEPTED DRUM DEHUMIDIFY RETURN This starts the drum dry operation, and returns to the Drum Dry screen. 6-16 bizhub 226...

  • Page 117: Administrator Settings

    NC-504 is installed. Select whether to save scanned data in USB memory. The factory default is [ENABLE]. For details, refer to [User's Guide Network Scan]. Tips The administrator of this machine must not forget the administrator number. bizhub 226 6-17...

  • Page 118: Selecting The Administrator Setting

    CURRENT NO.:------ % To correct a value, press Clear/Stop. Enter a new administrator number using the Keypad, then press OK. For confirmation, enter the new administrator number, then press OK. This returns to the Administrator Settings screen. 6-18 bizhub 226...

  • Page 119: Enabling A Change Of The Auto Shut Time

    Use +, to select [ACCOUNT TRACK], then press OK. Use +, to select [ACCOUNT TRACK MODE], then press OK. Use +, to select [COPY] or [PC-PRINT], then press OK. Select [ON] or [OFF], then press OK. This returns to the Account Track Settings screen. bizhub 226 6-19...

  • Page 120: Registering Id (Account)

    % If you select [ADD], you can continuously register another ID (account) number. % If the number of registered ID (account) numbers exceeds 50, the [UP TO 50 ACCOUNT] message appears. This returns to the Account Track Settings screen. 6-20 bizhub 226...

  • Page 121: Changing Or Deleting The Id (Account)

    % If the entered ID (account) number has been already registered, [REGISTERED!] is displayed. % To continuously change or delete the next number, repeat Steps 6 to 7. When all changing or deleting operations have been completed, press Back. This returns to the Administrator Settings screen. bizhub 226 6-21...

  • Page 122: Displaying Or Erasing The Total Counter By Id (Account)

    Use +, to select [ACCOUNT TRACK], then press OK. Use +, to select [ACCOUNT TRACK DATA], then press OK. Use +, to select [ALL COUNTER CLEAR], then press OK. This returns to the screen for the counter by account. 6-22 bizhub 226...

  • Page 123: Copy Setting 1

    • The factory default is [ENABLE]. 6.7.1 Selecting COPY SETTING 1 Press the Utility key. The Utility screen appears. Use +, to select [COPY SETTING 1], then press OK. The COPY SETTING 1 screen appears. bizhub 226 6-23...

  • Page 124: Setting The Tray Priority

    % For details on selecting [COPY SETTING 1], refer to page 6-23. Use +, to select [QUALITY PRIORITY], then press OK. Use +, to select a target quality, then press OK. QUALITY PRIORITY TEXT/PHOTO TEXT PHOTO This returns to the COPY SETTING 1 screen. 6-24 bizhub 226...

  • Page 125: Specifying The Density Priority

    Use +, to select [DENSITY LEVEL], then press OK. Use +, to select [AUTO], then press OK. Use *) to select the density level, then press OK. DENSITY LEVEL(A) This returns to the COPY SETTING 1 screen. bizhub 226 6-25...

  • Page 126: Specifying The Density Level Priority (Manual)

    If the optional Reverse Automatic Document Feeder DF-625 is not installed, [1-SIDE % 2-SIDE] and [2-SIDE % 2-SIDE] will not be displayed. If the optional Automatic Duplex Unit AD-509 is not installed, [2-SIDE % 1-SIDE] and [2-SIDE % 2-SIDE] will not be displayed. 6-26 bizhub 226...

  • Page 127: Setting The Copy

    % For details on selecting [COPY SETTING 1], refer to page 6-23. Use +, to select [ORIG. BINDING POS.], then press OK. Use +, to select [LEFT], [RIGHT], or [TOP], then press OK. ORIG. BINDING POS. LEFT RIGHT This returns to the COPY SETTING 1 screen. bizhub 226 6-27...

  • Page 128: Setting The Book Binding Position

    % You can set the binding margin width within the range from 0 mm to 20 mm. % To correct the value, press Clear/Stop, and enter a new value using the Keypad. This returns to the COPY SETTING 1 screen. 6-28 bizhub 226...

  • Page 129: Setting The Erase Width

    % For details on selecting [COPY SETTING 1], refer to page 6-23. Use +, to select [SMALL ORIGINAL], then press OK. Use +, to select [DISABLE] or [ENABLE], then press OK. SMALL ORIGINAL DISABLE ENABLE This returns to the COPY SETTING 1 screen. bizhub 226 6-29...

  • Page 130: Copy Setting 2

    [MM/DD/YY], [DD/MM/YY], and [YY/MM/DD]. • The factory default is [MM/DD/YY]. 6.8.1 Selecting COPY SETTING 2 Press the Utility key. The Utility screen appears. Use +, to select [COPY SETTING 2], then press OK. The COPY SETTING 2 screen appears. 6-30 bizhub 226...

  • Page 131: Setting The Copy Mode Priority

    % For details on selecting [COPY SETTING 2], refer to page 6-30. Use +, to select [OUTPUT PRIORITY], then press OK. Use +, to select [NON-SORT], [SORT], or [GROUP], then press OK. OUTPUT PRIORITY NON-SORT SORT GROUP This returns to the COPY SETTING 2 screen. bizhub 226 6-31...

  • Page 132: Specifying The Alternate Output

    Use +, to select [PATTERN1] or [PATTERN2], then press OK. 4IN1 COPY ORDER PATTERN1 PATTERN2 % Page arrangements of PATTERN 1 and PATTERN 2 are as shown below. PATTERN 1 PATTERN 2 This returns to the COPY SETTING 2 screen. 6-32 bizhub 226...

  • Page 133: Specifying The Mixed Original Priority

    % For details on selecting [COPY SETTING 2], refer to page 6-30. Use +, to select [ORIG. DIRECTION], then press OK. Use +, to select [TOP], [LEFT], [RIGHT], or [BOTTOM], then press OK. ORIG. DIRECTION LEFT RIGHT BOTTOM This returns to the COPY SETTING 2 screen. bizhub 226 6-33...

  • Page 134: Configuring Book Separation Setting

    % For details on selecting [COPY SETTING 2], refer to page 6-30. Use +, to select [STAMP], then press OK. Use +, to select [OFF], [PAGE NUMBER], [DATE&TIME], or [PAGE+D&T], then press OK. STAMP PAGE NUMBER DATE&TIME DATE+D&T This returns to the COPY SETTING 2 screen. 6-34 bizhub 226...

  • Page 135: Setting The Page Number Print Format

    % For details on selecting [COPY SETTING 2], refer to page 6-30. Use +, to select [DATE&TIME FORMAT], then press OK. Use +, to select [MM/DD/YY], [DD/MM/YY], or [YY/MM/DD], then press OK. DATE&TIME FORMAT MM/DD/YY DD/MM/YY YY/MM/DD This returns to the COPY SETTING 2 screen. bizhub 226 6-35...
  • Page 136 COPY SETTING 2 6-36 bizhub 226...

  • Page 137: If You Suspect A Failure Then Do The Following

    If you suspect a failure then do the following...

  • Page 139: If This Copy Is Output

    Press Density to select a lighter background den- sity. (p. 4-5) The end of the service life of Contact your service representa- tive. Drum Unit. bizhub 226...
  • Page 140 (p. 3-12) Are the adjustable Lateral Guide Slide the adjustable Lateral Guide correctly positioned against the against the edges of the paper. edges of the paper? Was curled paper loaded into Flatten the paper before loading the paper tray? bizhub 226...

  • Page 141: Major Messages And Troubleshooting

    Load paper of the suitable-size combination of the original size paper or press Zoom to select a and paper size is outside the zoom ratio. range from 25% to 400% when the original is copied in the auto zoom select mode. bizhub 226...
  • Page 142 Drum Unit. [MACHINE TROUBLE SERVICE An error has occurred in this ma- Turn off the Main Power Switch CALL (CXXXX)] chine. of this machine, then turn it on again. If this error recurs, contact your service representative. bizhub 226...

  • Page 143: The Copier Does Not Function

    Has the power cord been re- Plug in the power cord. been supplied to this machine. moved from the outlet? Has the breaker for the location Turn on the breaker. where this machine is installed been turned OFF? bizhub 226...
  • Page 144 The copier does not function. bizhub 226...

  • Page 145: Others

    Others...

  • Page 147: Major Specifications

    Major specifications Others Major specifications 8.1.1 bizhub 226 Specifications Type Scanner, printer, or desktop Document holder Fixed mount type Photo conductor Copy system Laser electrostatic copying Developing system HMT system Fusing system Heat roller fusing system Resolution 600 dpi e 600 dpi...

  • Page 148: Reverse Automatic Document Feeder Df-625

    11 e 17w to 5-1/2 e 8-1/2 v, A3w to B5v Number of loadable sheets 250 sheets Max. power consumption 9 W or less Size Width: 22-7/16 inches (570 mm) e Depth: 20-7/8 inches (530 mm) e Height: 4-1/4 inches (108 mm) Weight 11-7/8 lb (5.4 kg) bizhub 226...

  • Page 149: Automatic Duplex Unit Ad-509

    13. Any one of these sizes is selectable. For details, contact your service representative. Power supply Supply from machine Max. power consumption 6 W or less Size Width: 15-3/16 inches (386 mm) e Depth: 4-3/16 inches (107 mm) e Height: 8-7/8 inches (225 mm) Weight 3-5/16 lb (1.5 kg) bizhub 226...

  • Page 150: Daily Maintenance

    Wipe the surface of the Original Glass using a soft cloth. 8.2.3 Slit Scan Glass Wipe the surface of the Slit Scan Glass using a soft cloth. Wipe off stains from the back side to the front side along the guide. bizhub 226...

  • Page 151: Original Pad

    Wipe the surface of the Original Pad using a soft cloth mois- tened with alcohol. 8.2.5 Control Panel Wipe the surface of the Control Panel using a soft cloth. Important Do not use a mild household detergent or glass cleaner, otherwise the keys may be damaged. bizhub 226...
  • Page 152 Daily maintenance bizhub 226...

  • Page 153: Index

    Index...

  • Page 155: Index By Item

    Image quality setting Copy mode screen 2-13 2-18 Initial mode 6-23 COPY SETTING 1 Interior of the main unit COPY SETTING 2 6-30 5-20 Copy setting registration Copying area Key speed setting 4-17 Custom size paper Keypad 2-10 bizhub 226...
  • Page 156 Specifying the quality priority 4-23 Photo mode 2-12 Speed Dial Plain paper Standard paper 2-10 Power Save Standard size printing Power saving 2-20 2-10 Start 3-11 Precautions on originals Stop Print density setting Stop copy job Storing paper 2-12 Switching Plate bizhub 226...
  • Page 157 Transparency Tray change 6-11 Tray Settings Tray1 6-12 6-13 Tray2 6-13 Tray3 6-13 Tray4 6-13 Tray5 Troubleshooting 2-18 Turning ON/OFF the power 6-12 Unit of paper size Utility 2-10 X/Y variable zoom ratio 4-20 4-22 Zoom 2-10 4-20 bizhub 226...

  • Page 158: Index By Button

    6-23 6-25 6-23 6-24 PAPER PRIORITY DENSITY(ADF) 6-12 PAPER SIZE DENSITY(BOOK) PAPER SOURCE SETUP DIAL REGISTRATION 4-15 PLAIN 6-17 6-19 DISPLAY AUTO SHUT PLAIN 2-SIDE 4-15 6-16 DRUM DEHUMIDIFY PRINT DENSITY 6-23 6-26 DUPLEX PRIORITY 4-25 PRINT REPORT bizhub 226...
  • Page 159 6-19 SLEEP SHIFT 6-23 6-29 SMALL ORIGINAL SORT 4-15 SPECIAL STAMP 6-30 6-34 TOTAL PAGE 4-24 4-15 4-16 TRANSPARENCY TRAY1 6-11 6-12 6-11 TRAY2 6-11 TRAY3 6-11 TRAY4 6-11 TRAY5 TYPE 4-15 USER SETTING 6-17 X/Y ZOOM 4-22 bizhub 226...
  • Page 160 Index by button bizhub 226...

Table of Contents
