8.0 Jøtul 50 TL Rangeley Part List
No. Description
1. Air Baffle Manifold Assembly
2. Gasket, LD2, .500 Ø Fiberglass Rope, SS Jacket
3. Nut, M8, Serrated Flange
4. Upper Union Plate,
5. Tube Spacer, TL Stoves
6. Screw, Soc Set, cup pt, M6 X 10, Black
7. Baffle Plate, Left, Cast Iron - 50 TL
8. Screw, HWH SMA 8 x 1/2 SL Blk Oxide
9. Heat Shield, Flue Collar, 50 TL, MB
10. Rear Shroud, 50 TL, MB
11. Screw, Button Head Socket, M6 X 14, Blk
12. Ash Pan, 50 TL
13. Bolt, M8 x 20, hex Serr. Flange Hd Black
14. Leg, Cast Iron, MB
15. Nut, M8, Serrated Flange, DIN 6923 St 8.8
16. Bolt, Leveling, M8 x 40
17. Heat Shield, Bottom, 50 TL, MB
18. Washer, Flat M6 -.062 DIN 125A Plain
19. Screw, Button Head Socket, M6 X 6, Blk
20. Bracket, Top, Cast Convection Panel, 50 TL
21. Convection Panel, Left, Cast Iron - MB
22. Baffle Handle
23. Bracket, Bottom, Cast Convection Panel,
24. Screw, Button Hd Socket M6 x 10 Blk
25. Screw, Button Head Socket, M6 X 16, Blk
27. Andiron, Cast Iron
28. Firebox Weldment, 50 TL
29. Bolt, Hex Head Serr Flange M6 x 12 Blk
30. Inspection Cover, Cast Iron, MB
31. Gasket, Inspection Cover
32. Primary Air Deflector
33. Screw, Shoulder, M6x10 Thd, 8mmØx10mm Shld, Hex
34. Air Valve Weldment, 50 TL
35. Air Valve Handle Ass'y, Nickel Plated
36. Ashlip, Cast Iron - 50 TL, MB
37. Set Screw, M6 x 16
37.a Nut, M6 - Serrated Flange
38. Washer, Fender .250 x 1.500 dia.
39. Gasket, .360 LD2
40. Ashdoor w/Gasket, Top Load Stoves, MB
41. Ashdoor Handle Assembly, Top Load Stoves
42. Hinge Pin, Ash Door, Nickel Plated
43. Hairpin Cotter, 1/16 x 1 1/8" Stainless Steel
44. Gasket Retainer, Front Door
45. Glass Clip w/Gasket, Bottom, Steel Stoves
47. Retainer, Front Door Latch
48. Door, Front, w/Gasket, Cast Iron , MB
50. Latch Shim
51. Front Door Catch
52. Offset Latch, Front Door, Nickel Plated
53. Front Door Tool, Nickel Plate
53a. Receiver
53b. Wooden Handle
53c. M6 Rod
53d. Nut Housing
Part Number
No.
157345
54.
223828
55.
117881
57.
104609
58.
224129
60.
04-11720
61.
104606
62.
117917
63.
22422692
64.
22421992
65.
118215
66.
224114
67.
117875
68.
157346
70.
117881
71.
118047
72.
22422892
73.
117947
74.
118170
75.
224106
78.
157355
79.
157263
80.
224468
81.
117978
82.
118201
83.
10461292
84.
22338892
85.
117130
86.
157347
87.
224355
88.
224367
89.
117982
90.
223729
91.
157391
92.
157348
93.
118031
94.
117968
95.
118029
96.
100038
97.
157349
98.
157350
99.
224268
100.
118091
101.
224268
102.
157357
103.
224159
104.
157351
105.
224734
106.
224733
107.
157459
157262
224359
128064
126835
224358
139262 Rev_N F 50 TL Rangeley 2/16
Description
Hinge Pin - Grooved, Nickel Plate
Slotted Spring Pin, 5mm Ø x 20mm, Plain Steel
Nut, Lock M6 DIN 980v Stover Zinc
Washer, Hinge M6 - 12mm OD x 6mm ID x 0.5mm Zinc
Gasket, LD 250 Fiberglass Rope
Glass, Ceramic, Door, 50 TL
Glass Clip w/Gasket, Top, Steel Stoves
Gasket, MD, .625 Ø Fiberglass Rope
Exhaust Deflector
Screw, Shoulder, M6 Thd, 8mmØx6mm Shldr, Plain
Eyebrow, Cast Iron, MB
Bolt, Hex Head Serr Flange M6x16 8.8 Blk
Grate Plate, Cast Iron - 50 TL
Brick, Refractory, 4.25" x 9" x 1.25"
Brick, Refractory, 5.5" x 3" x 1.25"
Brick, Refractory, 4" x 3" x 1.25"
Brick, Refractory, 8.5" x 3" x 1.25"
Brick, Refractory, 9" x 1.88" x 1.25"
Brick Retainer, Right
Brick Retainer, Left
Convection Panel, Right, Cast Iron, MB
Gasket, MD, .625 Ø Fiberglass Rope
Bolt, Hex Head M8 x 12 Blk
Side Clip (aka Hang Tab)
Linkage Lever, TL Stoves
Dowel Pin, 3/8" x 2"
Nut, M8, Serrated Flange, DIN 6923 St8.8
SWasher, Fender 8mm Zinc
Set Screw, M8 x 40, Hex Socket, Steel, Black, DIN 916
Hinge Tab, Load Door, TL Stoves
Screw, Button Head Socket, M8 X 8 Blk
Gasket, LD2, .375 Ø Fiberglass Rope, SS Jacket, SPL
Handle, Load Door, TL Stoves, Nickel Plated
Door, Top Load, Cast Iron -50 TL
Gasket, Flue Collar
Nut, M6 Serrated Flange plain
Bolt, Hex Head, Serr Flange M6x20 Blk
Smoke outlet, MB
Gasket, LD2, .500 Ø Fiberglass Rope, SS Jacket, SPL
Bolt, M8 x 25, Hex Serrated Flange Hd, SS
Top Plate, TL Stoves, MB
Baffle Plate, Right, 50 TL
Screw, Flat Head Phillips M6 X 12 M/S Blk
Tube Bushing, Machined
Replacement Air Tube Weldment
Steel Convection Panel, Left, 50 TL, MB
Steel Convection Panel, Right, 50 TL, MB
Load Door Tool, TL Stoves, MB
Hinge Pin Retainer Clip
Only use replacement parts provided
through your authorized Jøtul dealer.
Part Number
225098
118240
118016
117588
200024
224158
157352
223858
224325
118244
157353
99625
104605
129082
224259
224175
221752
220390
224113
224112
10461592
223858
99115
128401
225390
224157
117881
117949
118245
22417692
118241
224276
224729
157398
224350
117968
117117
10332692
223828
118242
157356
104607
117976
157285
157358
22422192
22422092
22426592
118261
