- Page 1 Sukhoi SU-26m 480 ARF Assembly Manual Specifications Wingspan: 43 in (1090mm) Length: 39 in (990mm) Wing Area: 365 sq in (23.5 sq dm) Weight w/o Battery: 24–26 oz (680–740 g) Weight w/Battery: 30–32 oz (850–910 g)
-
Page 2: Table Of Contents
Pushrod Set Optional Accessories ..........3 EFL2858 Canopy Hatch Brushless Outrunner Setup .......... 3 E-flite perfectly captures the essence of this aerial hot EFL2859 Cowling Required Tools and Adhesives ........3 rod with its Sukhoi SU-26m – a scaled-down version of... -
Page 3: Recommended Radio Equipment
If you own a Spektrum radio, just add a DSM2 ™ Especially keep your hands away from the propeller. receiver and four E-flite S75 Sub-Micro servos. We Tools & Equipment show the installation of the AR6200 receiver in the Felt-tipped pen Hobby knife (#11 blade) manual. -
Page 4: Landing Gear Installation
4. Attach the wheel to the landing gear using a 3mm lock nut. Use a #2 Phillips screwdriver and 5mm nut driver to tighten the nut. E-flite Sukhoi SU-26m 480 ARF Assembly Manual... -
Page 5: Optional Wheel Pants Installation
1. Attach the supplied aluminum motor X-mount to the motor using the screws provided with the motor. Make sure to use threadlock on the screws before tightening them with a #2 Phillips screwdriver. E-flite Sukhoi SU-26m 480 ARF Assembly Manual... - Page 6 It will rotate counterclockwise when viewed from the front of the aircraft. Use the instructions with your speed control to correct a motor that is operating in the wrong direction. E-flite Sukhoi SU-26m 480 ARF Assembly Manual...
-
Page 7: Cowling Installation
5. Install the propeller assembly onto the motor shaft. Tighten the propeller nut using a hex wrench slipped through the hole in the propeller nut. E-flite Sukhoi SU-26m 480 ARF Assembly Manual... -
Page 8: Aileron Hinging
Thin CA to each hinge. Make sure the hinge is fully saturated with CA. Use a paper towel to clean up any excess CA from the wing and aileron. Make sure to apply CA to both sides of the hinge. E-flite Sukhoi SU-26m 480 ARF Assembly Manual... -
Page 9: Aileron Servos And Linkages
We suggest using the long 3D servo arms for the Sukhoi SU-26m 480. Replace all existing arms before installing the servos as shown in Step 8. 1. Attach a 6-inch (150mm) servo extension. Use string or dental floss to secure the servo lead and extension to prevent them from unplugging in flight. - Page 10 5. Use a #1 Phillips to secure the aileron servo servo horn from the aileron servo. into the wing. Use care not to drill through the top using the screws provided with the servo. of the wing by accident. E-flite Sukhoi SU-26m 480 ARF Assembly Manual...
- Page 11 Phillips screwdriver. Make sure the horn aligns with the aileron hinge line when the radio system is on and the aileron servo is centered. 14. Repeat Steps 1 through 13 for the remaining servo and linkage. E-flite Sukhoi SU-26m 480 ARF Assembly Manual...
-
Page 12: Wing Installation
2. Slide the wing panel with tube into position on the fuselage. Make sure to guide the aileron servo extension in the hole in the side of the fuselage. E-flite Sukhoi SU-26m 480 ARF Assembly Manual... - Page 13 4. Double-check the adjustments from Steps 1 through 3. Use a felt-tipped pen to trace the outline of the fuselage onto the top and bottom of the stabilizer. E-flite Sukhoi SU-26m 480 ARF Assembly Manual...
- Page 14 Do not use accelerator—to allow the CA Slide the elevator tight against the stabilizer. to wick in the joint, providing the best bond possible. E-flite Sukhoi SU-26m 480 ARF Assembly Manual...
- Page 15 12. Firmly grasp the stabilizer and gently pull on the elevator to ensure the hinges are secure and cannot be pulled apart. Use caution when gripping the elevator and stabilizer to avoid crushing the structure. E-flite Sukhoi SU-26m 480 ARF Assembly Manual...
-
Page 16: Rudder And Fin
5. Slide three hinges into the slits in the rudder. Place a T-pin in each hinge to prevent it from being pushed into the rudder when attaching it to the fin. E-flite Sukhoi SU-26m 480 ARF Assembly Manual... - Page 17 Make sure the hinge is fully saturated with CA. Use a paper towel to clean up any excess CA from the rudder and fin. Make sure to apply CA to both sides of the hinge. E-flite Sukhoi SU-26m 480 ARF Assembly Manual...
-
Page 18: Rudder And Elevator Servos
Apply 2–3 drops of thin CA at the joint between the horn and backplate to keep it secure. E-flite Sukhoi SU-26m 480 ARF Assembly Manual... - Page 19 (1.5mm) drill bit to enlarge the outer hole of the servo horn. 7. Center the elevator servo. Use a #0 Phillips screwdriver to remove the stock servo horn and install the horn prepared in the previous steps. E-flite Sukhoi SU-26m 480 ARF Assembly Manual...
- Page 20 Slide the pushrod wire through the micro connector on the servo horn. Center the elevator, and secure the position of the wire using the 2mm x 4mm screw and a #0 Phillips screwdriver. E-flite Sukhoi SU-26m 480 ARF Assembly Manual...
-
Page 21: Final Assembly
Place a piece of hook and loop tape on the bottom of the battery and on the fuselage where the battery rests. This will keep the battery from shifting forward or backward during extreme maneuvers. E-flite Sukhoi SU-26m 480 ARF Assembly Manual... -
Page 22: Control Throws
Travel Adjust, Sub Trim and Dual Rates are After the first flights, the CG position can be adjusted not listed and should be adjusted according for your personal preference. to each individual model and preference. E-flite Sukhoi SU-26m 480 ARF Assembly Manual... -
Page 23: Preflight
Range Test Your Radio Flying Your Sukhoi SU-26m 480 Check Your Radio Flying the Sukhoi SU-26m 480 is about as fun as it 1. Before each flying session, be sure to range can get at the park. A very light wing loading and Before going to the field, be sure that your batteries check your radio. -
Page 24: Safety Do's And Don'ts For Pilots
Horizon. Return of any goods by Purchaser must be approved in writing by Horizon before shipment. E-flite Sukhoi SU-26m 480 ARF Assembly Manual... - Page 25 Provided warranty conditions have been met, or concerns regarding this product or warranty. your Product will be repaired or replaced free of charge. Repair or replacement decisions are at the sole discretion of Horizon Hobby. E-flite Sukhoi SU-26m 480 ARF Assembly Manual...
-
Page 26: Ce Compliance Information For The European Union
7. I will not operate model aircraft with metal-blade propellers or with gaseous boosts (other than air), nor will I operate model aircraft with fuels containing tetranitromethane or hydrazine. E-flite Sukhoi SU-26m 480 ARF Assembly Manual... - Page 27 I become a proficient flier, unless I The model aircraft must be equipped with a lighting am assisted by an experienced pilot. system which clearly defines the aircraft’s attitude and direction at all times. E-flite Sukhoi SU-26m 480 ARF Assembly Manual...
- Page 28 © 2009 Horizon Hobby, Inc. 4105 Fieldstone Road Champaign, Illinois 61822 (877) 504-0233 horizonhobby.com E-fliteRC.com Printed 05-09 15578...
