To override the unoccupied state while in the Main User
Menu:
1. Press the NO key to all prompts until the Cancel
ovrd prompt appears. If the thermostat controller is
in the unoccupied state, this is the first prompt.
2. Press the YES key to enable the temporary
override. The thermostat controller returns to the
Status Display Menu.
When scrolling through the Status Display Menu,
Override now appears for the schedule status
parameter.

Resuming the Programmed Schedule

This menu only appears when the thermostat controller
is in the override mode.
To resume the schedule while in the Main User Menu:
1. Press the NO key to all prompts until the Resume
Schedule prompt appears. If the thermostat
controller is in the override state, this is the first
prompt.
2. Press the YES key to resume the programmed
schedule.
The thermostat controller returns to the Status Display
Menu.

Entering Permanent Temperature Setpoints

The first prompt appearing in the Main User Menu of
the thermostat controller when in the occupied state is
to set the permanent temperature setpoint. Permanent
setpoints are stored in the programmed schedule.
To enter the permanent heating and cooling setpoints
for the Occupied and Unoccupied Modes, follow the
steps in Table 2. When changing the temperatures,
press the keys once to change the temperature in
0.5F°/0.5C° increments; press and hold down the keys
to change the temperature in 5.0F°/5.0C° increments.
Table 2: Entering Permanent Temperature
Setpoints (Part 1 of 2)
Thermostat Description
Display
Press the MENU key while in the
Status Display Menu to enter the
RoomTemp
Main User Menu.
75.0°F
Press the NO key to all prompts until
the temperature setpoint prompt
Temperat
appears on the display (it may be the
set? Y/N
first prompt). Press the YES key to
enter the temperature setting menu.
TEC2604-4 and TEC2604-4+PIR BACnet® MS/TP Networked Multi-Stage Economizer Thermostat
Table 2: Entering Permanent Temperature
Setpoints (Part 2 of 2)
Thermostat Description
Display
Press the YES key to change the
occupied cooling setpoint. Press the
Cooling
NO key to advance to the occupied
set? Y/N
heating setpoint menu.
Press the UP/DOWN arrow keys to
set the temperature. Press the YES
Cooling
key to store the value and advance to
75.0 ° F
the next menu.
Press the YES key to change the
occupied heating setpoint. Press the
Heating
NO key to advance to the unoccupied
set? Y/N
cooling setpoint menu.
Press the UP/DOWN arrow keys to
set the temperature. Press the YES
Heating
key to store the value and advance to
68.0 ° F
the next menu.
Press the YES key to change the
unoccupied cooling setpoint. Press
Unocc CL
the NO key to advance to the
set? Y/N
unoccupied heating setpoint.
Press the UP/DOWN arrow keys to
set the temperature. Press the YES
Unocc CL
key to store the value and advance to
80.0 ° F
the next menu.
Press the YES key to change the
unoccupied heating setpoint. Press
Unocc HT
the NO key to advance to the
set? Y/N
temperature display units.
Press the UP/DOWN arrow keys to
set the temperature. Press the YES
Unocc HT
key to store the value and advance to
62.0 ° F
the next menu.
Press the YES key to set the display
units to °F or °C. Press the NO key to
° F/ ° C
advance to the temperature setpoint
set? Y/N
type menu.
Press the YES key to return to the
Status Display Menu or press the NO
Exit?
key to reenter the temperature
Y/N
setting menu.
