rear of the stroller's backrest (fig_a).
The hood can be set in 3 different positions (fig_b) by
simply pulling it forwards or backwards.
The section of netting can be pulled out from the hood
to protect the child from the sun (fig_c) and easily
replaced back inside when it is no longer needed.
7• COVER: in order to use the cover correctly (fig. a),
fasten the buttons in the inner part of the stroller (fig.
1) and lay it beneath the seat covering the footrest,
then fasten the buttons (fig. 2).
RAIN CANOPY: To fit the rain canopy, slip it onto the
stroller (fig_b), button it down on the sides of the
hood (fig_1) and attach the elastic loops, taking in the
chassis in the lower part of the stroller (fig_2).
8• 5-POINT SAFETY HARNESS: to fasten, insert the two
buckles of the waist strap (with attached shoulder
straps, arrow a) into the leg divider strap until they
click into place (arrow b). To unfasten them, press the
button which is situated in the centre of the fastener
(arrow c) and pull the waist strap outwards (arrow d).
9• To tighten the waist strap, pull on both sides in the
direction of the arrow (Fig.a). To loosen it do the
opposite. The waist strap can be tightened as far as the
safety lock (Fig_b).
10• It is possible to set the safety harness at 3 different
heights, depending on how tall the child is. As the
child gets bigger, the harness must be moved to a
higher position.
11• To adjust the height of the safety harnesses, release
the two buckles on the rear of the backrest.
Pull the shoulder straps towards you (arrow a) until the
buckles are released and insert them in the backrest
loops (arrow b). Remove the shoulder straps from the
sack (arrow c) and insert them in the most appropriate
buckle (arrow d), then reattach the two buckles
behind the backrest (arrow e). The buckles are securely
attached when a click is heard (fig f).
12• LEG REST ADJUSTMENT: The leg rest can be set in 2
different positions. To lower the leg rest, pull the two
side levers downwards and at the same time lower the
leg rest. To raise the leg rest, push it upwards until it
clicks into position.
BACKREST ADJUSTMENT: The backrest can be set in 3
positions: To lower the backrest, lift the levers on both
sides at the same time and lower it, locking it in the
position required. To lift the backrest, push it upwards.
13• FOLDING UP: Before folding up the stroller, it is best to
lower the front bar to position 2.
The stroller can be folded up using one hand only: pull
first one lever upwards and then the other, until they
click.
14• Hold the central handlebar and pull it upwards until
the stroller folds up (fig_a). Check the correct closure
of the chassis from the safety hook. When folded, the
chassis will stand upright (fig_b).
15• TRANSPORT: The stroller can be moved with ease (with
the front wheels fixed) using the central handle (fig_a).
It can also be carried using the side handle (fig_b).
16• REMOVABLE COVERS: To remove the cover of the stroller:
Release the two buckles on the rear of the backrest
(fig_a).
Release the two buttons on the seat (fig_b).
Pull the buckle of the crotch strap out from
underneath (fig_c).
Release the buttons from the side of the sack (fig_d).
17• Pull the sack off the footrest (fig_e).
To remove the safety harness, release the screws on
both sides, using a screwdriver and pliers to hold the
nut still (fig_f).
Pull the sack upwards (fig_g).

ATTACHING PRIMO VIAGGIO SL

You must first set the brakes on the stroller.
Lock the car seat onto the stroller without the baby.
The car seat must be fastened facing the mother at
all times.
If necessary, take off the stroller hood since it is
already fitted on the car seat.
Position the backrest of the stroller into the 2nd
central position (section 12).
Position the car seat handlebar into transport
position so that the straps can be easily fastened.
18 Push the button beneath the armrest and extend
•
the front bar, then simultaneously pull it out from
both sides (fig. a).
WARNING: Only extend the front bar when
attaching the Car Seat.
Lean and fit-in the car seat into the seat of the
stroller (fig. b).
19 First lock the strap buttonhole into the button of
•
the stroller (arrow 1), then pass through the strap
behind the handlebar of the car seat (arrow 2).
Lock the strap buttonhole into the button on the
lower part of the stroller frame (arrow 3) and then
tighten the strap until the car seat is completely
fastened into the stroller (arrow 4).
Follow the same procedures on the other side of
the stroller (fig. c).
Car seat locked correctly into the stroller (fig. d).
Releasing the car seat from the stroller:
loosen the belts;
unlock the strap buttonhole from the lower part
of the stroller frame; slip it off from behind the
handlebar of the car seat; then, unlock the strap
buttonhole from the stroller button.

SERIAL NUMBERS

20 The Stroller Si has all the following relevant
•
information behind the backrest: product name,
date of manufacture and serial number.
This information is required for any complaints.

ACCESSORIES

21• MOSQUITO NETTING: can be fastened to the hood (fig_a).
BAG: diaper-changing bag with pad for changing baby's
diaper. Attaches to the stroller (fig_b).
CUP HOLDER: may be attached to the mushroom
button on the frame of the stroller (Fig. c).
22• TRAVEL BAG: practical duffle bag for transporting the
stroller by plane (fig_a).
UMBRELLA: practical umbrella to match (fig_b).
PADDED CUSHION for Peg Perego high chairs and
strollers. Winter side made with cozy matelassé jersey
and summer side made with 100% cotton (fig_c).
