Table 3: Installer Configuration Menu (Part 3 of 5)
Parameter
Description and Default
Appearing
on Display
Sets the Occupied and Unoccupied
2
Cool min
minimum Cooling setpoint values.
Default: 12.0°C/54.0°F
Pband
Proportional Band used by the PI
temperature control loop of the
thermostat controller.
Pband is not converted with C or F
scale and is always shown with a
range of 2 to 8.
Default: 2 (2.0F°/1.1C°)
Anticycl
Anti-Short Cycle timer sets the
minimum on/off times for heating
and cooling stages.
Default: 2.0 min
Note: Set the anti-short cycle timer
to 0.0 min for equipment that
already has its own anti-short cycle
timer.
Heat cph
Sets the maximum number of
Heating cycles per hour.
Default: 4.0
Cool cph
Sets the maximum number of
Cooling cycles per hour.
Default: 4.0
Deadband
Sets the minimum deadband
between the heating and cooling
setpoints.
Default: 1.0C°/2.0F°
Fan cont
Determines how the fan is activated
in response to a call for heating or
cooling.
Default: on
Note: The Fan cont parameter
applies to W1 when the fan is in the
Auto mode only. The Fan cont
parameter does not affect fan
operation on a call for cooling (Y1).
Fan del
Fan delay extends fan operation
after a heating or cooling cycle has
ended.
Default off
Note: The fan delay is only active
when the fan is in the Auto mode.
10
TEC2001-4 and TEC2001-4+PIR Single-Stage Wireless Thermostat Controllers Installation Instructions
Selection Options
Range: 12.0°C/54.0°F to 37.5°C/100.0°F
Value
F Scale Pband/C Scale Pband
2
2.0F°/1.1C°
3
3.0F°/1.7C°
4
4.0F°/2.2C°
5
5.0F°/2.8C°
6
6.0F°/3.3C°
7
7.0F°/3.9C°
8
8.0F°/4.4C°
Note: The use of a larger proportional band is not to use the
thermostat controller as a discharge air controller device. The use of
a larger proportional band can be used to solve issues for flawed
HVAC design with basic sizing and thermostat controller location
errors that cannot be worked around.
Range: 0.0 to 5.0 min adjustable in 1-minute increments
Set the anti-short cycle timer to 0.0 min for equipment that already
has its own anti-short cycle timer.
Range: 3.0 to 8.0 cycles per hour
Range: 3.0 or 4.0 cycles per hour
Range: 1.0C°/2.0F° to 2.0C°/4.0F° adjustable in 0.5C°/1.0F°
increments
(off): Enables the thermostat controller to activate the fan in
response to a call for cooling only.
(on): Enables the thermostat controller to activate the fan in
response to a call for heating or cooling.
When there is a call for auxiliary heating, the fan is activated by the
equipment fan and limit control.
(on): Extends fan operation by 60 seconds after a heating or cooling
cycle has ended.
(off): No extension of fan operation after a heating or cooling cycle
has ended.
The fan delay is only active when the fan is in the Auto mode.
