- Page 1 Digital Blood Pressure Monitor UA-767PC Instruction Manual UA-767PEX-C WM:PD4000034B...
-
Page 2: Preliminary Remarks
Preliminary Remarks The device conforms to the following requirements: European Directive 93/42 EEC for Medical Products Act; Medical Products Act; European Standards for Electrical Medical Equipment EN 60601-1 (General Safety Provisions), EN 60601-1-2 and EN 55011 (Electromagnetic Compatibility); European Standards pertaining to Non Invasive Blood Pressure Instruments EN 1060-1(General Requirements), EN 1060-3 (Supplementary Requirements for Electromechanical Blood Pressure Measuring Systems). -
Page 3: Parts Identification
Parts Identification... - Page 4 Symbols Symbols Function / Meaning Treatment Turns on or off the device ___________ Set the clock / Does not store the ___________ current data Direction guide to install battery ___________ Direct current ___________ Serial number ___________ Date of manufacture ___________ Type BF: Device, cuff and tubing are designed to provide special ___________...
-
Page 5: Setting The Clock
Setting the Clock The UA-767PC blood pressure monitor is equipped with a date and time function. To set the clock on the monitor, follow these steps: Press the clock button on the front of the monitor. The blinking digits reflect the year. If they are not currently set on the correct year, press the START button to advance to the correct year. -
Page 6: Preparation For Measurements
Preparation for Measurements 1. Installing / Changing the Batteries Remove the battery cover and insert new batteries into the battery compartment as shown, taking care to observe the proper direction for each battery. Use R6P, LR6 or similar type batteries. If the symbol appears on the display panel, this means that the batteries are depleted. - Page 7 Measurements Place the cuff on the arm (preferably the left arm). Set the PRESSURE switch to a value that will be 30 to 40 mmHg above the expected systolic value and press the START button. • When the START button is pressed, all of the display symbols will appear for about one second.
- Page 8 Measurements • Remain still while the device is in operation. • When a measurement is made with insufficient pressure, the device will pump again to a higher pressure. When measurement has completed, the buzzer sounds and the air is automatically released from the cuff. The systolic pressure, diastolic pressure readings, and the pulse rate are displayed.
-
Page 9: Notes For Proper Measurements
Measurements • Accurate measurement cannot be made if the exhaust velocity is outside the range of 2 to 5 mmHg. This can be determined by watching the display each time the "Measurement in Progress" symbol blinks. Note the reading as the "Measurement in Progress" symbol blinks. Notes for Proper Measurements Sit in a comfortable position where you can place the arm to be used for the measurement on a table or other support that will place the center of the... -
Page 10: Storing Data In Memory
Data in Memory Storing Data in Memory This device stores up to 126 sets of measurement data in memory automatically. If an error message appears, the measurement data will not be stored. Whether the data will be stored or not after the measurement can be selected as follows: •... -
Page 11: Transmitting Readings To A Computer
“-“ appears one after another in succession and permission will be given to perform various functions. Measurement data of the UA-767PC can be monitored with “Monitor Pro” Data Analysis Software (UA-767P-13) and Printer terminal (TM-2480 series). For details, refer to the instruction manual. - Page 12 How to Make Proper Measurements How is a Proper Measurement Made? Blood pressure varies depending upon the conditions prevailing at the time of the measurement, consider the following so that the most accurate measurements may be made. In preparation for blood pressure measurement, the subject should urinate and should remain relatively still for 5 to 10 minutes before a measurement.
-
Page 13: What Is Blood Pressure
About Blood Pressure What is Blood Pressure? The blood pressure is at its highest levels in the large arteries near the heart and drops off towards the peripheral areas of the circulatory system. The blood pressure varies with the beating of the heart. When the heart contracts, forcing the blood out, the pressure inside the arteries is said to be systolic. -
Page 14: Who Blood Pressure Classifications
About Blood Pressure WHO Blood Pressure Classifications Standards for assessment of high blood pressure, without regard to age, have been established by the World Health Organization (WHO), as shown in this chart. Variations in Blood Pressure Individual blood pressures vary greatly both on a daily and a seasonal basis. These variations are even more pronounced in the hypertensive patient. -
Page 15: Maintenance
Maintenance Do not open the case of the device because it uses delicate electrical components and an intricate air unit that could be damaged. If you can not locate and fix the problem, request service from your supplier, or from the A&D service group. - Page 16 A&D Co.,LTD. A&D Co.,LTD. 1-243 Asahi, Kitamoto-shi, Saitama 364-8585 JAPAN 1-243 Asahi, Kitamoto-shi, Saitama 364-8585 JAPAN Telephone: [81](48)593-1111 Telephone: [81](48)593-1111 Fax: [81](48)593-1119 Fax: [81](48)593-1119 A&D INSTRUMENTS LTD. A&D INSTRUMENTS LTD. <Authorized Representative Established in the European Community> <Authorized Representative Established in the European Community> Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxon OX14 1DY United Kingdom...
