Chapter 5-14

5.9 Navigation examples

5.9.1 Chart/cursor navigation. 5.9.2 Waypoint navigation.
5.9.3 Route navigation.
Relevant for all navigation modes are:
- the highway display with graphical steering - section 5.2.1.
- the ETA & AVN display with Estimated Time of Arrival and
Approximate Velocity Necessary to reach a given point at a specific
time - section 5.5.
- the *Trim & Highway display with information on actual and mean
speed over ground, velocity (VMG) and water speed - section 5.6.
- the *Set & Drift display with indication of how fast the current
is moving in knots, in what direction (true) it is moving and what
direction in relation to the vessel (relative) - see section 5.7.
* These readings rely on data from external log and compass.
With the [PILOT] key you can toggle between all the displays in the
pilot-serie - see section 5.1 Shortcut to the pages in the pilot-serie.

5.9.1 Cursor navigation

Cursor navigation is the easiest and most straightforward way of
navigation - point and go!
Shortcut to chart display
CHART
Press the cursor key to activate the cursor, then move the cursor to
your destination
GOTO
Call up the GOTO menu
Select Cursor navigation mode
1
A course line will now be drawn from actual position (ship's posi-
tion) to destination point (cursor's position).
CE34/44/54 Pilot menu & navigation examples
5.9.4 Track navigation.
