Simrad CE34 ChartSounder Manual page 103

CE34/44/54 Waypoint / route menu
If the XTE distance is not the same in all legs, the value will be *.*
instead of the 00.10nm. Navigation mode can be either RHUMB-
LINE or GREAT CIRCLE, or... if not set to the same in all legs in a
route, the mode will be: COMPOSITE.
Direction in route can be set to either FORWARD or REVERSE
direction.
Show route as can be set to either NAVIGATION for navigational
data in the route display (example on the previous page), or POINTS
for a list of routepoints together with the position in lat/long and the
XTE limit of each point.
Place the cursor on the function you wish to change
0-9
Key in new figures, and...
toggle between available values
+/-
- if no more alterations are required, go to [ENT], or you can insert/
remove routepoints from the route by entering a new display:
PLOT
Open for the function: Remove/insert routepoints
+/-
Existing routepoints can be removed, by using the +/- keys to high-
light the routepoint you wish to remove, and press [CLR]
CLR
New routepoints can be added to the route by using the cursor to go
up/down in the WP list to select the position you wish to add to the
route, then...
+/-
By means of the +/- keys highlight the routepoint where you wish the
new position should be placed in the route, and press [PLOT]
PLOT
- the last point in the RtePt panel is empty, and as such will allow
you to enter a new final routepoint.
Confirm modification of route and return to the Edit display
ENT
- or abandon modification by pressing [MENU]
Confirm editing
ENT
Return to route list
MENU
Chapter 7-5
