3.5 Chart setup

The settings are dedicated to the chart in the active window and does
not affect the second chart in dual chart mode.
ADJ
Load chart setup related to active chart
◄
GOTO
Display mode
Orientation
Rotation resolution
Motion
Quick chart info
Cursor 5 min.time-limit
Auto chart select
Extended level range
Show range
MENU
The tabs indicate which groups are available in each display mode
e.g. the above example shows that in FULL display mode you have
access to the groups in black: General, Areas and User data. The
two groups in red i.e. Presentation and Depth are only adjustable
in CUSTOM display mode. See further on in this chapter for more
details.
Select display mode: FULL, CUSTOM, SIMPLE, FISHING, LOW,
+/-
GRID
Go to the next group
PLOT
Step back to the previous group
GOTO
Scroll up/down in the chart settings
General Presentation Dep
Exit
PLOT
FULL
NORTH UP
15°
RELATIVE
OFF
WITH BACKGROUND
Accept
