Draytek Vigor2860 Series Quick Start Manual page 10

(Giga)
Right
LED
Left
GigaLAN
LED
1~6
Right
LED
Switch on Rear Side
Interface
Factory Reset
USB1~2 / USB
VDSL/ADSL
WAN2
GigaLAN (1-6)
PWR
ON/OFF Power Switch.
SIM Card Slot
Blinking The data is transmitting.
On The port is connected with 1000Mbps.
Off The port is connected with 10/100Mbps
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 1000Mbps.
Off The port is connected with 10/100Mbps
Description
Restore the default settings. Usage: Turn on the router
(ACT LED is blinking). Press the hole and keep for more than
5 seconds. When you see the ACT LED begins to blink
rapidly than usual, release the button. Then the router will
restart with the factory default configuration.
Connecter for a USB device (for 3G/4G USB Modem or
printer or thermometer.
Connecter for accessing the Internet.
Connecter for local network devices or modem for
accessing Internet.
Connecters for local network devices.
Connecter for a power adapter.
Connector for a SIM card.
(Available for Vigor2860L)
