Multitech MULTIMODEM MT5634ZBA-USB User Manual page 51

Carrier Frequencies
ITU-T V.34
Carrier Frequencies
ITU-T V.32bis/V.32
Carrier Frequencies
V.22bis/V.22 or
Bell 212A Standard
(2400 & 1200 bps)
Carrier Frequencies
ITU-T V.23
(1200 bps)
Carrier Frequencies
ITU-T V.21
(0–300 bps)
Carrier Frequencies
Bell 103/113
(0–300 bps)
Fax Carrier
Frequencies
Transmit Level
Frequency Stability
Receiver Sensitivity
AGC Dynamic Range
Connectors
Cables
Appendix B - Technical Specifications
1600, 1646, 1680, 1800, 1829, 1867, 1920,
1959, 2000 Hz
1800 Hz
Transmit originate:
Transmit answer:
Receive originate:
Receive answer:
Transmit originate:
Receive originate:
Transmit answer:
Receive answer:
Transmit originate:
Receive originate:
Transmit answer:
Receive answer:
Transmit originate:
Receive originate:
Transmit answer:
Receive answer:
V.21 Ch2 (half duplex):
1650 Hz mark, 1850 HZ space for transmit originate
1650 HZ mark, 1850 Hz space for transmit answer
V.27ter: 1800 Hz originate/answer
V.29 QAM: 1800 Hz originate/answer
V.17 TCM: 1800 Hz originate/answer
-11 dBm (dial-up)
±0.01%
-43 dBm under worst-case conditions
43 dB
USB connector; two RJ-11 phone jacks
One 7-foot RJ-11 phone cable
One 4-foot USB cable
Note: Any cables connected to the computer should be
shielded to reduce interference.
1200 Hz
2400 Hz
2400 Hz
1200 Hz
390 Hz mark
450 Hz space
1300 Hz mark
2100 Hz space
1300 Hz mark
2100 Hz space
390 Hz mark
450 Hz space
980 Hz mark
1180 Hz space
1650 Hz mark
1850 Hz space
1650 Hz mark
1850 Hz space
980 Hz mark
1180 Hz space
1270 Hz mark
1070 Hz space
2225 Hz mark
2025 Hz space
2225 Hz mark
2025 Hz space
1270 Hz mark
1070 Hz space
51
