COMMAND MODE OPTIONS
The following LCDs are used to configure result code responses.
SYNC/ASYNC OPTIONS
Use the
RESET FACTORY DEFAULTS
Use the
factory defaults. Same as the AT&F&W command string.
CONNECT RATE OPTIONS
Use the
speeds.
Multi-Tech Systems, Inc. MT5600BA-V92 User Guide
ENABLE/DISABLE RESPONSE
Use the and Enter buttons to enable or disable the sending of result codes to
the computer. Same as the Q0 and Q1 commands.
VERBOSE/TERSE RESPONSE
Use the and Enter buttons to select verbose or terse result codes. Same as
the V0 and V1 commands.
ENABLE/DISABLE CMD MODE
Use the and Enter buttons to enable or disable the modem's ability to accept
AT commands.
and Enter buttons to select the method of data transmission.
ASYNC, NORM?
Normal asynchronous transmission using the AT command set.
ASYNC, V.25bis?
Asynchronous transmission using the V.25bis command set.
SYNC, NORM?
Normal synchronous transmission using any command set.
V.25bis HDLC NRZ?
V.25bis synchronous transmission using NRZ encoding.
V.25bis HDLC NRZI?
V.25bis synchronous transmission using NRZI encoding.
V.25bis BISYNC?
V.25bis bisynchronous transmission.
and Enter buttons to reset Profile 0 and the modem's active configuration to the
and Enter buttons to change the modem's serial port and data transmission
SERIAL BAUD RATE
Use the and Enter buttons to select the modem's serial port speed. The valid
range is 1200 to 115200 bps. Same as the $SB commands.
MODEM SPEED
Use the and Enter buttons to select the modulation protocol to use in
originating or answering a connection. This also selects the maximum
transmission speed at which the modem can operate. Same as the +MS=[mod] -
command.
