- Page 1 MultiModemII Data/Fax Modem MT5600BA and MT5600BL Series MT5600BA – V.92 MT5600BA – V.90 MT5600BL – V.90 Quick Start Guide...
- Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes in the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.
-
Page 3: Getting Started
Getting Started This Quick Start Guide will help you install and set up your modem. A User Guide containing detailed configuration information and a separate AT Commands reference guide can be found on the MultiModemII CD shipped with your modem. Safety Warnings •... - Page 4 MultiModemII Quick Start Guide Connect the Modem to Your PC Plug one end of the serial cable into the RS-232 connector on the modem and plug the other end into a serial port connector on your computer, such as COM1 or COM2. Connect the Modem to the Telephone Line (Dialup Connection) Plug one end of the modular phone cable into the modem’s LINE jack, and the other end into a public switched telephone network...
-
Page 5: Power-On Test
Power-On Test Test the modem by turning it on (a power switch is located on the front panel). When you turn it on, the modem performs a diagnostic self-test, indicated by the TM indicator lighting for a few seconds, after which the LCD should light. If this does not happen, check that the power switch is on, the transformer module supply is solidly connected, and the AC outlet is live. - Page 6 MultiModemII Quick Start Guide Step 3: Set Country or Region Code The MT5600BA-V.92 is a global modem. However, countries or regions vary in their requirements for how a modem functions. Therefore, you must configure yours to match the defaults of the country or region in which you are using it.
-
Page 7: Using At Commands To Configure Your Modem
1. View the list of available country/region codes and find your code by executing the command AT +GCI? <CR> Note: A list of country/region codes is also available on the Multi-Tech Web site at: http://www.multitech.com/PRODUCTS/Categories/Modems/ global/configuration.asp#chart 2. Set and save the code by executing the command AT+GCI= nn <CR>... - Page 8 Patents This device is covered by one or more of the following patents: 6,031,867; 6,012,113; 6,009,082; 5,905,794; 5,864,560; 5,815,567; 5,815,503; 5,812,534; 5,809,068; 5,790,532; 5,764,628; 5,764,627; 5,754,589; D394,250; 5,724,356; 5,673,268; 5,673,257; 5,644,594; 5,628,030; 5,619,508; 5,617,423; 5,600,649; 5,592,586; 5,577,041; 5,574,725; 5,559,793; 5,546,448; 5,546,395; 5,535,204; 5,500,859;...
