DO NOT RETURN THIS PRODUCT TO THE STORE, the risk of electric shock. e. When operating a power tool outdoors, use an first contact your local STANLEY Office or nearest authorized service center. extension cord suitable for outdoor use. Use of...
Page 4
The correct power tool will do son, but not authorized by STANLEY, the warranty the job better and safer at the rate for which it was will not be valid.
Page 5
ENGLISH PIECE IS KNOWN AS “THROUGH-SAWING”. Ripping and cross-cutting are through-sawing 1. DO NOT OPERATE THIS MACHINE until it is operations. Cutting with the grain (or down the length assembled and installed according to the instructions. 2. OBTAIN ADVICE FROM another qualified person if of the workpiece) is ripping.
Page 6
ENGLISH Clearly identify the parts shown in Fig. A1 and A2, including the fittings. Group these parts together and ensure that you have the correct quantity of all the pieces shown. 1 x 4 pieces 2 x 2 pieces 3 x 2 pieces 4 x 2 pieces 5 x 2 pieces Bolt...
Page 7
ENGLISH Step 4 Now place and connect the ends of the top and center frame supports to the frame. Take care to ensure that the supports are positioned as shown in Fig. B5. Adjusting the splitter (FIG. D1-D3) The splitter (3) has two positions: storage position (Fig. D1) and working position (Fig.
Page 8
ENGLISH Loosen the two nuts (c). Adjust the two adjusting nuts (d) to Lever make sure the splitter is approximately 1/8” (3 mm) above the blade tips. Tighten the two nuts (c). To adjust the alignment of the splitter The splitter must be precisely IN LINE with the saw blade. 2.
Page 9
ENGLISH (1) by tightening the nut in the handle. (See Fig. J1) 3. If needed, release the locking handle by pulling it up- ward. Mount the rip fence onto the saw so that the side with the indicator is on the scale side of the saw (See Fig. J2). Start by sliding the front of the rip fence onto the front side of the table so that the front locking plate contacts the front side of the table then push down on the back of the rip fence so...
Page 10
ENGLISH The blade elevation handle is used to raise and lower the saw blade. Turn clockwise to lower the blade and counter- clockwise to raise it. (See Fi g. N). Blade tilting wheel The blade tilting wheel (10) is used to tilt the saw blade for bevel cutting.
Page 11
ENGLISH Device used to feed the work-piece through the saw during narrow ripping cuts. The push stick (13) helps to keep the Rip fence (see Fig. Q) operator’s hands well away from the blade. Use the push This rip fence is used for all ripping operations. Never rip stick for ripping widths less than 6”...
Page 12
ENGLISH tion mark on blade matches with that. be sure that the miter gauge and blade bevel stop collar are locked. BASIC TABLE SAW OPERATIONS a. When crosscutting, miter cutting, bevel cutting, compound miter cutting or rabbeting across the end of a narrow work-piece, use the miter gauge.
4. Make a test cut for important cuts. Should you find one day that your STANLEY prod- 5. Always use the correct blade depth setting. The top of uct needs replacement, or if it is of no further use the blade teeth should clear the top of the material to you, do not dispose of it with household waste.
