Introduction
The CS-102 or CS-122 CPU Switch is a controller for one user to access multiple computers. Before the development of the
Master View, the only way to control multiple computer configurations from a single console was through a complex and
costly network system. Now, with a Master View CPU Switch, you can easily access multiple computers in a cost effective
manner. The CS-102 and CS-122 are basically similiar in their functions. The difference is that the latter offers PS/2 mouse
ports.
There are two methods to switch from one computer to the other: with a pushbutton switch, or with Hot Keys. Setup is fast
and easy; plugging cables into their appropriate ports is all that is entailed. There is no software to configure or install, and
there are no incompatibility problems. Since the Master View intercepts keyboard input directly, it works on any hardware
platform and with all operating systems.
A CS-102/CS-122 can control up to two computers. Units can be cascaded to three levels, allowing the user to control even
more computers. A powerful auto-scan feature scans all operational computers one by one and stops upon user requests.
The CS-102/CS-122 CPU Switch is ideal for Server, Control Room, Testing, etc.
Features
CS-102 for PCs / CS-122 for PS/2s.
PS/2 Mouse and MS Mouse Emulation.
Supports SVGA, VGA, and Mutisync Monitors.
Simple Keystrokes or Pushbutton for PC Selection.
Buzzer Sounds for Switching Confirmation.
Three Stage Cascadable.
Power-free Operation.
Auto Scan and Manual Selection.
Caps Lock, Num Lock, Scroll Lock States Automatically Saved and Restored When Switching Among Computers.
Scan Mode Automatically Switches Through Powered On Computers - Scan Rate is DIP Switch Selectable.
Saves Space, Equipment, and Power Costs.
Easy Hot Key Control is Compatible With Normal Keyboard Operation.
CS-102/CS-122 Front and Rear Views
