2 Way Remote Button Functions - Firstech Compustar RF-2W9000FM User Manual

Quick Reference
Remote Maintenance - Battery Replacement
The only regular maintenance this system requires is remote control battery replacement. No programming is required when replacing the battery.
Two Way Remotes:
Turn the remote over and unlock the battery cover by sliding the clear tab up. Slide the battery cover off, revealing the AAA battery.
IMPORTANT: Be sure to observe correct polarity when installing the battery.
One Way Remotes:
First, remove the small Phillips screw located on the back of the remote. Once the screw has been removed, gently pull the remote apart taking care to not
damage the circuit board. Your battery size should be listed on the battery. Replacements can be purchased from your local Firstech dealer or an electronics
store.
By Firstech, LLC 6
FT-2WLCD-S-E_UserGuide.indd 7-8
Quick Reference

2 Way Remote Button Functions

Button Duration LCD readout
Half second Locks doors and/or arms alarm.
Button Lock. Prevents all buttons on remote from accidentally being pressed. Once On /
2.5 seconds HOLD
3.5 seconds PANIC Panic/vehicle locater (flashes vehicle's parking lights and sounds siren and horn).
Half second Unlocks doors and/or disarms alarm.
2.5 seconds START AGAIN Resets the run time or turbo timer
Aux 1. Triggers the auxiliary 1 output (most commonly used for rear defrost
2.5 seconds A - 01
or window roll-down).
2.5 seconds Trunk release. Triggers the trunk release output and opens the vehicle's trunk.
Car Check shows vehicle temperature, battery voltage, and remote battery
Half second
voltage (updates vehicle status on remote pager) / Secure Auxiliary
Activates the remote start. Repeat and remote start will shut off. Will activate
2.5 seconds
Stop and Go Mode if held when vehicle is running with the key.
Turns siren chirps on/off (Note: With the siren chirps off, it will still sound in
Half second
the event the alarm is triggered).
2.5 seconds Option programming menu 1 - Installers Only.
Function Chirp(s)
Once
Twice Off
N/A
Twice
Once
Once
Twice
Once
Once On /
Twice Off
Once Off /
Twice On
Once
7 By Firstech, LLC
2011-6-10 12:05:34
