ASSEMBLY
Assembly requires two persons. Place all parts of the elliptical crosstrainer in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed.
Assembly requires the following tools: the included allen wrench, a phillips screwdriver
an adjustable wrench
As you assemble the elliptical crosstrainer, use the drawings below to identify the small parts used in assembly.
The number in parenthesis below each drawing refers to the key number of the part, from the PART LIST on
page 18. The second number refers to the quantity used in assembly. Note: Some small parts may have been
pre-attached for shipping. If a part is not in the parts bag, check to see if it has been pre-assembled.
M10 Nylon
Locknut (26)Ð7
1. Hold the Rear Stabilizer (65) against the saddle on the
rear of the Frame (1). Make sure that the Stabilizer is
turned so the square holes are facing away from the
Frame. Attach the Stabilizer with two M10 x 105mm
Carriage Bolts (27) and two M10 Nylon Locknuts (26).
2. Turn the Resistance Control (57) counterclockwise to
the minimum setting.
If the Resistance Control (57) is attached to the Upright
(2), remove the M4 x 16mm Screw (35). Pull the bot-
tom of the Resistance Control away from the Upright
and then slide it down to remove it.
, a rubber mallet
M8 Nylon
M8 Split
Locknut (80)Ð2
Washer (58)Ð2
M10 x 85mm Bolt (25)Ð1
M10 x105mm Carriage Bolt (27)Ð2
M8 x 108mm Bolt (79)Ð2
, and pliers
Spacer
M8 Washer (81)Ð6
(44)Ð4
M4 x 16mm
Flange Screw
1
26
1
2
5
.
Nylon Washer
(11)Ð2
M4 x 16mm
Screw (35)Ð9
(43)Ñ6
Axle Screw (30)Ð2
26
65
27
Tab
57
35
2
,
