LOAD RETAINING FIXTURES

WARNING
Do not exceed the maximum
permissible load of 60 kilogrammes
(132 pounds) on two load retaining
fixtures and 30 kilogrammes (66 pounds)
on one.
Check the security of the load retaining
fixtures and tighten its fittings as follows:
• before starting
• after driving 50 kilometres (30 miles)
• at 1 000 kilometres (600 miles)
intervals.
Installing the load retaining
fixtures
E75003
Load carrying
Installing the load bracket
way round, it may not hold the box in
place in the event of an accident.
E76378
1. Turn the box over.
2. Position the load bracket.
3. Secure the load bracket with four
screws.
E76379
166
WARNINGS
Install the load bracket with the
longest section towards the rear of
the vehicle. If you install it the wrong
Do not exceed the maximum
permissible load of 20 kilogrammes
(44 pounds).
3
1
3
2
