Moffat turbofan 300 Technical Specifications

TECHNICAL SPECIFICATIONS
Specification Information
Model No.:
Power:
Connections:
Dimensions:
Weight:
Installation Information
Client to provide the following connections:
Oven requires direct wiring from switchboard
Water connection 1/4" BSP
Drainage connection 1/2" required from drain pipe
Note: Oven supply does not include canopies and flues as required by relevant authorities.
Bends or offsets in the flue restrict gas velocity and must be allowed for when designing
the flue height and diameter which will be dependent on the building and local conditions.
A flue connection is required and is not included in the contract.
Exhaust flue - 200mm in diam (canopy models), 100mm (non canopy models)
Clearance: 50mm clearance is required at back and sides of unit
2695mm clearance required back to front of oven with door open
Minimum 2900mm ceiling height
Floor: A concrete or tile surface is preferred.
The floor area is to be flat to within 3mm over whole floor area.
Access: Oven is supplied partially assembled to be fully erected on site.
Largest piece if unassembled 2140mm H x 1680mm W x 750mm D
In line with policy to continually develop and improve its products, Moffat reserves the right to change specifications and design without notice.
Australia
Moffat Pty Limited
Free Call 1800 023 953
email: vsales@moffat.com.au
www.moffat.com.au
TURBOFAN 300
DEL300CX
3P + N + E, 400 - 415 volt, 50 Hz, 95kW (heating 90kW, motors 5kW)
1/4" BSP water and 1/2" BSP copper drain located at rear of oven
Width: 2515mm
Depth: 2180mm (includes canopy)
Height: 2700mm (includes canopy)
1300kg
(Electric)
1830mm (no canopy)
New Zealand
Moffat Limited
Free Call 0800 663 328
email: sales@moffat.co. nz
www.moffat.co. nz
DEL300CX 0403V1
