- Page 1 INSTALLATION INSTRUCTIONS USER GUIDE Built-in integrated cooker hood HP90IHCB3 model GB IE...
-
Page 3: Table Of Contents
CONTENTS Introduction Safety and warnings Installation instructions About your cooker hood – Energy efficiency Operating instructions Cleaning and maintenance Parts and accessories Manufacturer’s Warranty Customer Care ImpORTANT! Registration SAVE THESE INSTRUCTIONS Register your product with us so we can The models shown in this user guide may provide you with the best service possible. -
Page 5: Introduction
INTROduCTION Thank you for purchasing a Fisher & Paykel product. Thousands of hours go into the design, engineering, testing and perfecting of each Fisher & Paykel appliance. The care and attention given to creating these beautiful products doesn’t stop once it has found its home with you. This use and care manual will answer most of your questions about the set-up, use and on-going maintenance of your Fisher &... -
Page 6: Safety And Warnings
SafETy aNd waRNINGS waRNING! weight Hazard The cooker hood is heavy. Please ensure adequate care is taken when installing the cooker hood to prevent personal injury. The cooker hood must be installed onto a solid 10.5 kg wall, stud, beam or truss. weight of the product is 10.5 kg. - Page 7 SafETy aNd waRNINGS way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. • The installation of fisher & Paykel cooker hoods must comply with the information in this guide. failure to install the cooker hood in accordance with these installation instructions may result in electrical hazards, injury, and damage to your appliance and...
- Page 8 SafETy aNd waRNINGS • If the supply cord of this equipment is damaged it must only be replaced by the manufacturer, its service agent or similarly qualified person in order to avoid a hazard. • always switch the power off prior to installation, servicing or cleaning the cooker hood.
-
Page 9: Installation Instructions
INSTaLLaTION INSTRuCTIONS Contents of packaging INSTALLATION INSTRUCTIONS USER GUIDE Built-in integrated cooker hood HP90IHCB3 model GB IE Cooker hood Installation instructions 150 mm ducting adapter User guide manual with non return flap 125 mm ducting 9 x 13 mm screw adapter (1) - Page 10 INSTaLLaTION INSTRuCTIONS Product and cabinetry cutout dimensions Ø Power cord location...
- Page 11 INSTaLLaTION INSTRuCTIONS HP90IHCB3 PROduCT dIMENSIONS Overall height of product Overall width of product Overall depth of product Thickness of flange Width of chassis Depth of chassis Height of side of chassis Width of top surface of chassis Length of angled surface of chassis...
- Page 12 INSTaLLaTION INSTRuCTIONS Height of cooker hood MINIMuM CLEaRaNCES Height top of hob to base of product Electric hob min. 600 – max. 750 Gas hob min. 650 – max. 750...
- Page 13 INSTaLLaTION INSTRuCTIONS Venting options Attention should be given to ensure that any applicable regulations concerning the discharge of exhaust air are fulfilled. The cooker hood can be installed to operate with the exhaust air ducted externally from the kitchen, or installed to operate with the exhaust air recirculating within the kitchen. Ducted For ducted installation it is recommended that 150 mm diameter, rigid or semi-rigid ducting is used.
- Page 14 INSTaLLaTION INSTRuCTIONS Installation WARNING! This product is heavy and requires two persons for installation. WARNING! failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. The manufacturer is not liable for any damage caused by not following these instructions. Prepare for installation.
- Page 15 INSTaLLaTION INSTRuCTIONS Remove the filters and face plate of the cooker hood. 360˚ 360˚ 360˚ 360˚ 360˚ 360˚...
- Page 16 depth INSTaLLaTION INSTRuCTIONS Connect duct and plug cooker hood in. Lift the cooker hood and fit through the opening of the cupboard till the spring loaded brackets / clips hold the product in place. Secure cooker hood while tightening the 4 brackets / clips.
-
Page 17: About Your Cooker Hood - Energy Efficiency
COOkER HOOd – ENERGy EffICIENCy Product fiche EN61591 MOdEL HP90IHCB3 Annual Energy Consumption (kWh/annum) 32.2 Time Increase Factor Energy Efficiency Index 52.8 Energy Efficiency Class Fluid Dynamic Efficiency 28.5 Fluid Dynamic Efficiency Class Lighting Efficiency 16.1 Lighting Efficiency Class Grease Filtering Efficiency 91.2... -
Page 18: Operating Instructions
OPERaTING INSTRuCTIONS Touch control panel CONTROL PaNEL fEaTuRES Power on/off Turn the cooker hood on or off. The fan automatically turns on to operate at level 1. Fan speed 1 – 4 Adjust the fan speed levels from 1 – 4 with 1 being the lowest level and 4 being the highest. -
Page 19: Cleaning And Maintenance
CLEaNING aNd MaINTENaNCE ImpORTANT! Never use abrasive or oil based cleaners General maintenance Before performing any cleaning or maintenance on your cooker hood, ensure that the power supply is switched off to the hood. The cooker hood should be cleaned regularly using a mild, liquid detergent to avoid a build up of grease occurring. -
Page 20: Parts And Accessories
PaRTS aNd aCCESSORIES ITEM REfERENCE NuMBER LED bulb x2 792556 Aluminium filter 792429 Recirculation carbon filter 50031 Ducting 150 mm kit (eaves) 50033 Ducting 150 mm kit (wall) 50034... -
Page 21: Manufacturer's Warranty
MaNufaCTuRER’S waRRaNTy You automatically receive a 2 year Manufacturer’s Warranty with the purchase of this Built-in integrated cooker hood covering parts and labour for servicing within the United Kingdom and Ireland. fisher & Paykel undertakes to: Repair or, at its option, replace without cost to the owner either for material or labour any part of the product, the serial number of which appears on the product, which is found to be defective within TWO YEARS of the date of purchase. -
Page 22: Customer Care
CuSTOMER CaRE Before you call for service or assistance... Check the things you can do yourself. Refer to your user guide and check that: Your product is correctly installed. You are familiar with its normal operation. If after checking these points you still need assistance or parts, please refer to your nearest Authorised Service Centre, Customer Care, or contact us through our local website listed on the back cover. - Page 23 CuSTOMER CaRE Complete and keep for safe reference: Model Serial No. Purchase Date Purchaser Dealer Suburb Town Country...
-
Page 24: Www.fisherpaykel.com
www.fisherpaykel.com Copyright © Fisher & Paykel 2015. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your dealer to ensure this booklet correctly describes the product currently available.
