Polycom
RealPresence
®
Base
Legs (4)
M10 x 50 flanged head cap screw (8)
Glides (4)
Flat washer (4)
Lock washer (4)
Optional: Casters (4)
Flat washer (4)
Lock washer (4)
Vertical Support (2)
M10 x 25 flanged head cap screw (6)
Lower display rail (single or dual)
M10 x 25 flanged head cap screw (4)
Handle (2)
Upper display rail (single or dual)
M10 x 25 flanged head cap screw (4)
Front door
Nylon spacer
10-32 x 1/2" pan head screw (2)
Subwoofer
Speaker (2)
1/4-20 x 5/8" socket head cap screw (2)
Flat washer (2)
Lock washer (2)
Speaker wire (2)
Speaker bracket (2)
1/4-20 x 5/8" socket head cap screw (4)
Flat washer (4)
Lock washer (4)
Mesh grill (2)
10-32 x 1/2" pan head screw (6)
For more information about the components of the RealPresence Group Series Media Center, refer to the documentation at
http://support.polycom.com/PolycomService/support/us/support/video/group_series/group_packaged_solutions.html.
Note that additional setup sheets are available and should be referenced before beginning installation, including:
 Polycom RealPresence Group Series Media Center with 84" Display Setup Sheet Supplement
 Setting Up the Polycom RealPresence Group Series Media Center with 65" Dual Displays
 Polycom RealPresence Group Series Media Center Wall-Secured Setup Sheet Supplement
The Media Center components are heavy. Polycom recommends that two people perform the installation.
© 2015, Polycom, Inc. All rights reserved. POLYCOM® and the names and marks associated with Polycom's products are trademarks and/or service marks of
Polycom, Inc. and are registered and/or common law marks in the United States and various other countries. No portion hereof may be reproduced
or transmitted in any form or by any means, for any purpose other than the recipient's personal use, without the express written permission of Polycom.
Polycom
®
RealPresence
Media Center Setup Sheet
Group Series Media Center with a Single 55", 65", or 84" Display
®
or Dual 55" Displays
www.polycom.com
1725-08510-004A
®
Group Series
Display (single or dual)
Display mount bracket (2 per display)
M8 x 20 button head cap screw (4 per display)
1/4-20 x 3.5" socket head cap screw (2 per display)
M6 x 16 flanged button head screw (2 per display)
EagleEye IV camera
M3 x 6 phillips flat head screw (4)
Camera mount bracket
1/4-20 x 5/8" socket head cap screw (4)
Flat washer (4)
Lock washer (4)
1U shelf
Clip-on rack nut fastener (4)
10-32 x 1/2" pan head screw (4)
RealPresence Group Series 500 codec
M3 x 10 screw (2)
Power strip
Shoulder screw (2)
Power brick
Rear panel
Polycom-supplied tools:
L-Key for M8 screw
L-Key for M6 screw
L-Key for M10 screw
L-Key for 1/4-20 screw
User-supplied tools:
9/16" wrench
11/16" wrench
Phillips screwdriver (medium drive)
Phillips screwdriver (small drive)
1

Advertisement

loading

Summary of Contents for Polycom realpresence group series

  • Page 1 Polycom, Inc. and are registered and/or common law marks in the United States and various other countries. No portion hereof may be reproduced or transmitted in any form or by any means, for any purpose other than the recipient’s personal use, without the express written permission of Polycom.
  • Page 2 Group Series Media Center with a Single 55”, 65”, or 84“ Display or 55” Dual Displays Note: For the RealPresence Group Series wall-secured option, refer to the Polycom RealPresence Group Series Wall-Secured Setup Sheet. Install the supplied floor glides on the legs, using one flat Remove the base from packaging and flip the base over.
  • Page 3 Align the holes in the bracket with the holes in the vertical supports. (d) Attach the door using two 10-32 x 7/16 pan head screws. Polycom® RealPresence® Group Series Media Center Setup Sheet...
  • Page 4 Leaving enough slack to reach the subwoofer, trim or dress the speaker cable as needed. Repeat with the right speaker assembly. Attach the speaker wires to the subwoofer. For cabling details, refer to the documentation that came with the subwoofer. Polycom® RealPresence® Group Series Media Center Setup Sheet...
  • Page 5 Install the power strip to the left vertical support, using the two shoulder screws. Install the power brick. Note: For 84” displays, refer to the Polycom With the assistance of another person, lift the display RealPresence Group Series Media Center with 84“...
  • Page 6 Supplement. For the camera mount instructions in all 84” configurations, refer to step 2 in the Polycom If you have a dual display configuration, center the two RealPresence Group Series with 84“ Display Setup Sheet displays on the Media Center. Insert one M6 x 16 Supplement.
  • Page 7: Power Rating

     For further information concerning the individual components of this equipment, please refer to the respective product literature.  For support or service, please contact your Polycom® distributor or go to Polycom Support at www.polycom.com/support. Polycom® RealPresence® Group Series Media Center Setup Sheet...
  • Page 8 LINE IN POWER/STANDBY 40HMS Speakers BASS TREBLE LINE IN 100-120V ~ T5.0AL 250V~ 220-240V ~ FOR 100-120V USE T5.0AL T2.5AL 250V~ 250V~ 100-120V~ FOR 220-240V USE T2.5AL 250V~ キ ャビネットをあけないでください 220-240V~ 350W 230W Polycom® RealPresence® Group Series Media Center Setup Sheet...
  • Page 9 1/4-20 x 3.5” socket head cap screw (4) M5-10 screw (4) For more information about the components of the RealPresence Group Series Media Center, refer to the documentation at http://support.polycom.com/PolycomService/support/us/support/video/group_series/group_packaged_solutions.html. The Media Center components are heavy. Polycom recommends that two people perform the installation.
  • Page 10 ® Group Series Media Center with Dual 42” AIO Displays Note: For the RealPresence Group Series wall-secured option, refer to the Polycom RealPresence Group Series Wall-Secured Setup Sheet. Install the supplied floor glides on the legs using one flat Remove the base from packaging and flip the base over.
  • Page 11 Remove the rear door. Note that the rear door has ventilation holes at the top and bottom that are not displayed. Polycom® RealPresence® Group Series Media Center Setup Sheet...
  • Page 12 Repeat with the second display. Attach the retainer bracket to the back of the upper display rail using one wing nut on each end of the display rail. Polycom® RealPresence® Group Series Media Center Setup Sheet...
  • Page 13 Plug the cables into the power strip and plug the power strip into a power outlet. Only plug Polycom Media Center components into the power outlet block. Do not power any other electrical equipment from this power outlet. Polycom® RealPresence® Group Series Media Center Setup Sheet...
  • Page 14  For further information concerning the individual components of this equipment, please refer to the respective product literature.  For support or service, please contact your Polycom® distributor or go to Polycom Support at www.polycom.com/support. Polycom® RealPresence® Group Series Media Center Setup Sheet...
  • Page 15 Polycom® RealPresence® Group Series Media Center Setup Sheet...
