Polycom RealPresence Group Series Quick Tips

Polycom RealPresence
®
3725-63709-006A | September 2016
Group Series Quick Tips
®
Parts of the Remote Control
Number Description
1 LED IR emitter.
2 Decrease speaker volume.
3 Increase speaker volume.
4 Zoom camera out.
5 Zoom camera in.
6 Select button - Press center button to select
highlighted menu item.
7 Navigate through menu items using the Up, Down,
Left, and Right buttons; pan/tilt the camera.
8 Delete letters or numbers or go back to a previous
screen.
9 Display the Menu screen.
10 Return to the Home screen.
11 Place or answer a call and power on the system.
12 End or reject a call and power off the system.
13 Enter letters or numbers.
14 In camera control mode, move the camera to a
stored preset or press and hold a number to store
a preset.
15 • Generates an asterisk if the cursor is in a text
field.
• Generates a period if the cursor is in a numeric
field.
16 Generates touch (DTMF) tones. Press #, followed
by DTMF keys to send.
17 Mute or unmute a microphone.
Wake the System
To wake the system, lift the remote or press any
button on the remote.
Place a Video Call
Enter a Name or Number
1 Press on the remote control.
2 Enter the IP address, SIP address or H.323
name. To enter text, select
3 Press .
Call a Contact
1 Press on the remote control.
2 Select Contacts. Choose the desired contact
from the list or press the Select button to search.
3 Press .
Call a Recent Contact
1 Press on the remote control.
2 Select Recent. From the list of placed and
received calls, select the desired number.
3 Press .
Call a Speed Dial Contact
1 Press on the remote control.
2 Select Speed Dial.
3 Highlight the desired contact and press the
Select button to place a call.
.
