INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
VOYAGEUR GRAND WOOD INSERT
Automatic Combustion Control (ACC)
Model(s):
VOYA-GRAND-MBK
VOYA-GRAND-PMH
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfi re and generate
poisonous gases (i.e. carbon monoxide).
Installation and service of this appliance should
be performed by qualifi ed personnel. Hearth &
Home Technologies recommends NFI certifi ed
professionals, or technicians supervised by an
NFI certifi ed professional.
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re - If heater or chimney con-
nector glows, you are overfi ring. Overfi ring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fi replace.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
fl ammable materials.
•
Keep clothing, furniture, draperies and other fl ammable
materials away.
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafi re.com
Pour obtenir une traduction française de ce manuel, s'il vous
plaît contacter votre revendeur ou visitez www.quadrafi re.com
7075-209E
WARNING
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
NOTE
August 3, 2015

Advertisement

Table of Contents
loading

Related Manuals for Quadra-Fire VOYA-GRAND-MBK

Summary of Contents for Quadra-Fire VOYA-GRAND-MBK

  • Page 1 Automatic Combustion Control (ACC) damage, personal injury, or death. Model(s): • Do not store or use gasoline or other fl am- VOYA-GRAND-MBK mable vapors and liquids in the vicinity of VOYA-GRAND-PMH this or any other appliance. • Do not overfi re - If heater or chimney con- nector glows, you are overfi...

  • Page 2: Table Of Contents

    VOYAGEUR GRAND Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury.

  • Page 3: Important Safety Information

    VOYAGEUR GRAND Important Safety Information A. Insert Certifi cation Quadra-Fire is a registered trademark of Hearth & Home Technologies. Model: VOYAGEUR GRAND wood Insert Laboratory: Intertek NOTE: This installation must conform with local codes. In the Report No: 100868597PRT-001 absence of local codes you must comply with the UL1482, (UM) 84-HUD and NPFA211 in the U.S.A.

  • Page 4: Non-Combustible Materials

    VOYAGEUR GRAND E. Non-Combustible Materials Material which will not ignite and burn, composed of any combination of the following: - Steel - Plaster - Brick - Iron - Concrete - Tile - Glass - Slate Materials reported as passing ASTM E 136, Standard Test Method for Behavior of Metals, in a Vertical Tube Furnace of 750°...

  • Page 5: Getting Started

    VOYAGEUR GRAND Install Guide Getting Started A. Design and Installation Considerations B. Draft Draft is the pressure difference needed to vent appliances CAUTION successfully. When a appliance is drafting successfully, all combustion byproducts are exiting the home through the Check building codes prior to installation. chimney.

  • Page 6: Negative Pressure

    VOYAGEUR GRAND C. Negative Pressure D. Tools And Supplies Needed Negative pressure results from the imbalance of air avail- Before beginning the installation be sure the following tools able for the appliance to operate properly. It can be stron- and building supplies are available: gest in lower levels of the house.

  • Page 7: Install Checklist

    Installer: Dealer/ Distributor Phone #: Serial #: Model (circle one): VOYA-GRAND-MBK VOYA-GRAND-PMH WARNING! Risk of Fire or Explosion! Failure to install fi replace according to these instructions can lead to a fi re or explosion. IF NO, WHY? Appliance Install Verifi...

  • Page 8: Dimensions And Clearances

    VOYAGEUR GRAND Dimensions and Clearances A. Appliance Dimensions NOTE: Flue Collar size is 6 inch (152mm) diameter (ID) 32 5/8 (829mm) 23 3/4 (602mm) 17 15/16 456 mm 5 (127mm) Figure 8.1 Front View Figure 8.2 Top View Surround Sizes* (356mm) Standard 43 in.

  • Page 9: Clearances To Combustibles

    VOYAGEUR GRAND B. Clearances to Combustibles, United States and Canada (UL and ULC) TOP TRIM (3/4” max depth) 22 1/2 32 5/8 (572mm) (829mm) (1092 mm) HEARTH EXTENSION (MINIMUM EMBER PROTECTION) USA 38 1/4 CANADA 46 1/4 (1175mm) MANTEL (12” max depth) USA 17 1/2 CANADA 19 1/2 (495mm)
  • Page 10 VOYAGEUR GRAND Material Thermal Conductivity: k value The k value indicates the amount of heat (in BTU’s) that will fl ow in 1 hour through 1 square foot of a uniform material 1 inch thick for each degree (F) of temperature difference from one side of the material to the other.

  • Page 11: Locating Your Stove & Chimney

    VOYAGEUR GRAND C. Locating Your Stove & Chimney • Consider the appliance location in order to avoid fl oor and ceiling attic joists and rafters. Location of the appliance and chimney will affect perfor- mance. As shown in Figure 11.1 the chimney should: •...

  • Page 12: 2-10-3 Rule

    VOYAGEUR GRAND E. 2-10-3 Rule These are safety requirements and are not meant to assure proper fl ue draft. This appliance is made with a 6 inch (152mm) diameter chimney connector as the fl ue collar on the unit. • Changing the diameter of the chimney can affect draft and cause poor performance. •...

  • Page 13: Chimney Systems

    VOYAGEUR GRAND Chimney Systems A. Venting Systems D. Masonry Chimney Chimney Connector: • Must meet minimum standards of NFPA 211. It is also known as fl ue pipe or stove pipe. It must be 6 inches • Must have at least 5/8 inch (16mm) fi reclay lining joined (152mm) minimum diameter stainless steel connector pipe.
  • Page 14 VOYAGEUR GRAND Masonry Chimney (Cont’d) NOTE: In Canada, this fi replace insert must be installed This insert conforms with the UL 1482 and ULC S628 with a continuous chimney liner of a 6 inch (152mm) diam- (Canada) in all respects, and is approved to UL & ULC safety eter extending from the fi...

  • Page 15: Metal Heat Circulating Masonry

    VOYAGEUR GRAND •The original factory-built clearance fi replace chimney E. Metal Heat Circulating Masonry cap must be re-installed after installing the approved This insert conforms with the safety standard UL-1482 and chimney liner meeting type UL 103 HT requirements ULC S628 (Canada) in all respects and is approved to UL & (2100°F) per UL 1777.

  • Page 16: Securing Chimney Components

    VOYAGEUR GRAND Prefabricated Metal Chimney (Cont’d) H. Altering the Fireplace Inches Millimeters The following modifi cations of factory-built fi replaces are permissible: Minimum Width of Cavity Opening - Front 32-7/8 Minimum Width of Cavity Opening - Rear The following parts may be removed: Minimum Height Damper Smoke Shelf or Baffl...

  • Page 17: Zero-Clearance Fireplace

    K. Chimney Height / Rise and Run or fl aws such as burnouts, metal or refectory warping. To be sure that your Quadra-Fire insert burns properly, the chimney draft (static pressure) should be approximately -0.10 Inspection to a minimum of NFPA 211 Level II is recom- inches water column (W.C.) during a high burn and -0.04...

  • Page 18: Appliance Set-Up

    VOYAGEUR GRAND Appliance Set-Up A. Outside Air Kit Installation 3. Repeat step 9 under Option One with one exception. After installing the appliance in the outer can, seal the fi replace A source of air (oxygen) is necessary in order for combustion opening and trim package with insulation to prevent air leak- to take place.

  • Page 19: Securing Stove Pipe/Liner To Flue Collar

    Simpson Durvent Pipe Distributor or from your local as stove mastic Figure 19.1. Quadra-Fire dealer, Part Number DV-6DLR-E15ADSS. 2. Attach gasket to bottom side of fl ue collar with a thin coat Figure 19.2 shows a vertical installation and also how to of silicone.

  • Page 20: Leveling Legs

    VOYAGEUR GRAND E. Securing Appliance to Stove Pipe/Liner D. Leveling Legs 1. Once you have the appliance in place and secured, reach 1. Remove the 2 screws already installed on each leg. up through the fl ue opening and grab the attachment bar 2.

  • Page 21: Surround & Trim Kit Installation

    VOYAGEUR GRAND F. Surround & Trim Kit Installation G. Standard Surround & Cast Trim Kit Standard Size: 42-1/2 in. W x 30 in. H Standard Size: 43 in. W x 31 in. H Large Size: 48 in. W x 34 in. H Large Size: 51 in.

  • Page 22: All Cast Surround Kit

    VOYAGEUR GRAND H. All Cast Surround Kit (4) Felt Vibration Insulation Pads Size: 44 in. W x 33 in. H Included in Surround Kit: (2) side pieces, left and right; (1) l top piece; (1) fastener package. Secure Tools Needed: Powered 4 to 6 inches long Phillips head Surrounds to screw driver;...

  • Page 23: Blower Cord Installation On Left Side

    VOYAGEUR GRAND 4. Remove the 2 screws at the top of the control plate. Push I. Blower Cord Installation on Left Side the bottom of the control plate to the inside of the appli- The blower cord is shipped to be installed on the right side ance and partially remove the control plate assembly.
  • Page 24 VOYAGEUR GRAND Grommet Route Cord Through Retainer Clip 9. Insert the power cord through the left side of the appli- 12. Insert the control plate assembly back into the appliance ance in the hole contains the grommet. Pull the connec- as shown.

  • Page 25: Mobile Home Installation

    VOYAGEUR GRAND Mobile Home Installation An outside air inlet must be provided for combustion and Burn wood only. Other types of fuels may generate must remain clear of leaves, debris, ice and/or snow. It poisonous gases (e.g., carbon monoxide). must be unrestricted while unit is in use to prevent room If unit burns poorly while an exhaust blower is on in home, air starvation which can cause smoke spillage and an (i.e., range hood), increase combustion air.

  • Page 26: Accessory List

    VOYAGEUR GRAND Accessory List VOYAGEUR - Grand Service Parts Beginning Manufacturing Date: Oct 2012 Ending Manufacturing Date: Active #14 Access Assembly 14.1 14.2 14.3 14.6 14.5 14.4 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
  • Page 27 VOYAGEUR GRAND VOYAGEUR - Grand Service Parts Beginning Manufacturing Date: Oct 2012 Ending Manufacturing Date: Active #25 Cast Surround Assemblies 25.3 25.2 25.1 25.4 25.5 IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Stocked Hearth and Home Technologies does not sell directly to consumers.
  • Page 28 VOYAGEUR GRAND VOYAGEUR - Grand Service Parts Beginning Manufacturing Date: Oct 2012 Ending Manufacturing Date: Active #25 Metal Surround Assemblies 26.3 26.2 26.1 26.4 26.5 IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Stocked Hearth and Home Technologies does not sell directly to consumers.
  • Page 29 VOYAGEUR GRAND August 3, 2015 7075-209E...
  • Page 30 VOYAGEUR GRAND 7075-209E August 3, 2015...
  • Page 31 VOYAGEUR GRAND August 3, 2015 7075-209E...

  • Page 32: Contact Information

    Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL...
