INSTALLATION INSTRUCTIONS FOR PART 99-7013
99-7013
KIT FEATURES
• DIN Radio Provision with Pocket
• ISO Mount Radio Provision with Pocket
• Double DIN Radio Provision
• Stacked ISO Mount Units Provision
KIT COMPONENTS
A) Radio Housing • B) ISO Brackets • C) ISO Trim Plate • D) Double DIN Brackets
• E) Double DIN Trim Plate • F) Snap In Pocket
A
1-800-221-0932
© COPYRIGHT 2007-2010 METRA ELECTRONICS CORPORATION
APPLICATIONS
Mitsubishi Outlander
2007-2010
Harness & Antenna Connections (sold seperately)
70-7005 - Mitsubishi Harness 07-up
B
C
TOOLS REQUIRED:
Small Flat Blade Screwdriver/ Panel Removal Tool
• Phillips Screwdriver • Socket Set
E
D
www.metraonline.com
F
