INSTALLATION INSTRUCTIONS FOR PART 99-7509
KIT FEATURES
• Painted to match factory dash
• DIN radio provision with pocket
• ISO radio provision with pocket
• Double DIN radio provision
• Stacked ISO mount units provision
KIT COMPONENTS
• A) Radio Housing • B) ISO Brackets • C) ISO Trim Plate • D) Double DIN Brackets
• C) Double DIN Trim Plate • D) Snap In Pocket
A
WIRING & ANTENNA CONNECTIONS (Sold Separately)
Wiring Harness: •70-7903 - Mazda Harness 01-up
Small Flat Blade Screwdriver • Panel Removal Tool • Phillips Screwdriver
APPLICATIONS
Mazda 5 2006-up
(with manual climate controls)
99-7509
B
E
TOOLS REQUIRED
METRA. THE WORLD'S BEST KITS.™
1-800-221-0932
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
C
F
metraonline.com
D

Advertisement

loading

Related Manuals for Metra Electronics 99-7509

Summary of Contents for Metra Electronics 99-7509

  • Page 1 INSTALLATION INSTRUCTIONS FOR PART 99-7509 Mazda 5 2006-up KIT FEATURES • Painted to match factory dash • DIN radio provision with pocket • ISO radio provision with pocket • Double DIN radio provision • Stacked ISO mount units provision KIT COMPONENTS •...
  • Page 2 All accessories, switches, and especially air bag indicator lights must be plugged in before reconnecting the battery or cycling the ignition. *NOTE: Refer also to the instructions included with the aftermarket radio. 99-7509 NOWLEDGE IS OWER Enhance your installation and fabrication skills by enrolling in the most recognized and respected mobile electronics school in our industry.

  • Page 3: Dash Disassembly

    Dash Disassembly 1. Remove the shifter. (Figure A) 2. Remove (2) Phillips screws exposed below shift lever trim panel. (Figure B) Continued on next page 99-7509 (Figure A) (Figure B)
  • Page 4 Dash Disassembly 3. Unclip and remove the center console side trim panels then remove (1) Phillips screw per side behind panels. (Figure C,D). Continue to next page 99-7509 (Figure C) (Figure D)
  • Page 5 Unplug and remove the panel. Note: The climate controls do not come out with the panel. (Figure F,G) Continue to kit assembly 99-7509 (Figure E) (Figure F) (Figure G)

  • Page 6: Din Radio Provision With Pocket

    Kit Assembly 99-7509 DIN radio provision with pocket 1. Locate the factory wiring harness in the dash. Metra recommends using the proper mating adapter from Metra or AXXESS. Re-connect the negative battery terminal and test the unit for proper operation.

  • Page 7: Iso Mount Radio Provision With Pocket

    Kit Assembly 99-7509 ISO mount radio provision with pocket 1. Locate the factory wiring harness in the dash. Metra recommends using the proper mating adapter from Metra or AXXESS. Re-connect the negative battery terminal and test the unit for proper operation.
  • Page 8 Kit Assembly 99-7509 ISO mount radio provision with pocket 6. Snap the pocket into the radio housing. (Figure D) 7. Reassemble dash in reverse order of disassembly. (Figure D)
  • Page 9 Kit Assembly 99-7509 Double DIN/Stacked ISO units provision 1. Locate the factory wiring harness in the dash. Metra recommends using the proper mating adapter from Metra or AXXESS. Re-connect the negative battery terminal and test the unit for proper operation.
  • Page 10 Notes...
  • Page 11 Notes...
  • Page 12 INSTALLATION INSTRUCTIONS FOR PART 99-7509 METRA. THE WORLD’S BEST KITS.™ metraonline.com 1-800-221-0932 © COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION...
