Page 11
WARNING Per FCC rules, changes or modifications not expressly approved by Precor could void the user's authority to operate the equipment. Industry Canada This device complies with RSS-210:2007 of the Spectrum Management &...
Page 13
WARNING Per FCC rules, changes or modifications not expressly approved by Precor could void the user’s authority to operate the equipment. Industry Canada This Class A digital apparatus complies with Canadian ICES-003.
Page 18
S E T High (高) High (高)、Medium (中)、 Low (低) から設 R E S I S T A N C E の 負荷 定します。 R A N G E ( 範 囲 の 設 定 ) * この機能は、すべての Precor フィットネス装置で利用可能です。 注:プログラミングモードで変更を行うと、新しい設定が 工場設定に置き換わります。...
Page 23
製品機能 表示言語の選択 この装置では、ユーザープロンプト、テキスト、ユーザー エントリーを様々な言語で表示することができます。 装 置が工場から出荷されるときのデフォルトの言語は英語 です。 注: プログラミングプロンプトは、言語選択に影響され ません。 このセクションのプロンプトは英語のままです。 言語を選択するには: S E L E C T L A N G U A G E ( 言 語 の 選 択 ) プロンプ トで、OK を押します。 ナビゲーション矢印キーを使 用して、言語を選択します。 2. もう一度 OK を押して、 表示されている設定を受け入 れ、次の機能に移動します。...
Page 24
製品オーナーズマニュアル ワークアウトセッションの時間制限の設定 ユーザーが装置を使うエクササイズ時間を制限すること ができます。 たとえば、時間制限を 20 分に設定した場 合、ユーザーはセッション時間を 1 分~ 20 分の間でし か入力できません。 注: 自動クールダウン期間は、どの時間ベースのプログ ラムの最後にもついており、 時間制限はそれに応じて調整 してください。 最大ワークアウト時間を設定するには: S E T M A X W O R K O U T T I M E ( 最 大 ワ ー ク ア...
Page 25
製品機能 一時停止時間制限の設定 ユーザーが装置を使うエクササイズ中にどれくらいの時 間一時停止できるか、 1~120 秒 (2 分) の数値を入力して 制限することができます。 たとえば、一時停止時間制限 を 60 秒に設定した場合、 1 分間運動が検出されずキーが 押されないと、ディスプレイは自動的にリセットされて Precor のバナーに戻ります。 重要:一時停止時間制限をセットするには、セルフパワー 装置にオプションの電源アダプタが接続されていなけれ ばなりません。 オプションの電源アダプタが接続されて いない場合に、運動速度が最低条件を下回ると、装置は、 一時停止モードを事実上無視して 秒のシャットダウ ンを開始します。 最大一時停止時間を設定するには: S E T M A X P A U S E T I M E ( 最 大 一 時 停 止 時...
たは H I G H (高) (装置によっては L O 、M E D 、また は H I ) を選択します。 2. 準備ができたら、「OK」 を押して変更を保存し、次 製 の機能に進みます。他のオプションについては、「 品設定の変更 」の表を参照してください。 情報のディスプレイ 情報表示を使用して、装置の使用 (走行距離計および使用 時間)、ソフトウェアバージョンおよびパーツ番号、シリ アル番号、使用ログ、エラーログについての情報を見つけ ることができます。 通常は、Precor カスタマーサポート から指示を受けた場合にのみ、 これらの情報にアクセスし ます。 情報表示内を移動するには、 下のフローチャートを使用し ます。 フローチャートの次にある表は、各ディスプレイ についての詳細を提供します。...
Page 29
製品機能 表 4 すべての製品の情報のディスプレイ 製品 表示 説明 すべて 装置が使用された時間数。 H O U R • M E T E R ( 時 装置は経過した分の数値を記 • 間 メ ー タ 録しますが、表示される値は ー ) 一番近い時間数に四捨五入し て表示されます。 すべて 上位ボードアプリケーションソ U - B O O T S W ( 上...
Page 30
ソフトウェアによって検出され E R R O R L O G ( エ ラ ー ロ たエラーコードが表示されます。 グ ) すべて 走行距離計の値は、 Precor 社製品 O D O M E T E R ( 走 行 距 離 のタイプおよびプログラムで選 計 ) 択した単位、米国標準またはメー トル法と関連します。 トレッドミルは、現在までに...
Page 31
きます。 この機能は通常、サービス担当者のみが利用し ます。 エラーログを表示するには: Precor バナーで、RESET (リセット) を 4 秒間押した ままにします。 2. D I A G S - I N F O R M A T I O N D I S P L A Y ( 診 断 - 情 報 表 示 ) または E R R O R L O G ( エ ラ ー ロ...
Page 32
た め 押 し た ま ま に し ま す ) というメッセージ が表示されなくなるまで、キーを軽く押し続けてくだ さい。 3. Quickstart を解放したときに、エラーログが削除され ている場合は、 N O E R R O R S ( エ ラ ー な し ) とい うメッセージがディスプレイに表示されます。 重要:エラーを一度削除してしまうと、それを検索す ることはできません。 いったん削除したエラーログを 取り戻すことはできませんので、エラーログを消去す る前に、装置で発生した問題は解決するようにしてく ださい。 4. RESET (リセット) を押して Precor バナーに戻ります。...
製品オーナーズマニュアル プログラムキーパッド 図 7: プログラムキーパッド プログラムキーパッドを使用すると、 すべてのエクササイ ズ プログラムにアクセスできます。 プログラムキーパッドを使用するには: メニューのトップレベルのプログラムを表示するには、 キーの中央を押します。 2. OK キーを押して選択を確認します。 表 6 利用可能なプログラム プログラムキー プログラムメニュー M A N U A L ( マ ニ ュ ア ル ) MANUAL (マニュア ル) I N T E R V A L ( イ ン タ ー バ ル ) INTERVAL (インタ...
Preva Business Suite, the accompanying printed materials, any copies of such software, and all data collected via the Preva Business Suite, are exclusively owned by Precor or its suppliers, as the case may be. Precor is widely recognized for its innovative, award-winning designs of exercise equipment.
Note: This product is intended for commercial use. The display apparatus (hereinafter referred to as the console) is intended to be shipped with new Precor exercise equipment (hereinafter referred to as the base unit). It is not packaged for individual sale.
Assembling and Maintaining the UBK 615 Upright Exercise Bike Safety Precautions Always follow basic safety precautions when using this equipment to reduce the chance of injury, fire, or damage. Other sections in this manual provide more details of safety features. Be sure to read these sections and observe all safety notices.
Page 59
Important Safety Instructions Care should be taken when mounting or dismounting the equipment. For Treadmills: Do not use typing or web surfing features while walking at speeds that exceed a slow and relaxed leisurely pace. Always stabilize yourself by holding a stationary handle bar while using typing or web surfing features.
Page 60
Assembling and Maintaining the UBK 615 Upright Exercise Bike SPACING—The below minimum spacing recommendations are based on a combination of the ASTM (U.S.) voluntary standards and EN (European) regulations as of October 1, 2012, for access, passage around, and emergency dismount: Treadmills—a minimum of 0.5 m (19.7 in.) on each...
Page 61
350 pounds (160 kg). Use the equipment only for its intended purpose as described in this manual. Do not use accessory attachments that are not recommended by Precor. Such attachments may cause injuries. Do not operate the equipment where aerosol (spray) ...
Assembling and Maintaining the UBK 615 Upright Exercise Bike Educating Users Take time to educate users about the Important Safety Instructions found in both the User Reference Manual and Product Owner’s Manual. Explain to your club or facility patrons that they should observe the following precautions: Hold onto a stationary handrail or handlebar while ...
Important Safety Instructions Regulatory Notices for the RFID Module When equipped with a control console as described in this document, this equipment may include a radio-frequency identification (RFID) module. The RFID module has been certified to operate at temperatures between -20°C and 85°C (-4°F and 185°F).
Assembling and Maintaining the UBK 615 Upright Exercise Bike Industry Canada This device complies with RSS-210:2007 of the Spectrum Management & Telecommunications Radio Standards Specification. Operation is subject to the following two conditions: (1) this device may not cause harmful...
The regulatory information in this section applies to the exercise equipment and its control console. Safety Approvals for Cardiovascular Equipment Precor equipment has been tested and found to comply with the following applicable safety standards. Cardiovascular Type Equipment: CAN/CSA, IEC, EN 60335-1 (Household and similar ...
Page 66
Assembling and Maintaining the UBK 615 Upright Exercise Bike Radio Frequency Interference (RFI) This Precor exercise equipment conforms to the following national standards defining acceptable limits for radio frequency interference (RFI). Federal Communications Commission, Part 15 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
Important Safety Instructions Electrical Recommendations: All Equipment Excluding Treadmills Note: This is a recommendation only. NEC (National Electric Code) guidelines or local region electric codes must be followed. For equipment fitted with a P80 console or Personal Viewing System (PVS) screen a separate power connection is required.
Assembling and Maintaining the UBK 615 Upright Exercise Bike Obtaining Service Do not attempt to service the equipment except for maintenance tasks. If any items are missing, contact your dealer. For more information regarding customer support numbers or a list of Precor authorized service centers, visit the Precor web site at http://www.precor.com.
Page 69
Table of Contents Important Safety Instructions ............ 3 Safety Precautions ................4 Educating Users ..................8 Hazardous Materials and Proper Disposal ........8 Product Recycling and Disposal ............8 Regulatory Notices for the RFID Module ........9 Regulatory Notices for Cardiovascular Exercise |Equipment ..................
Page 70
Assembling and Maintaining the UBK 615 Upright Exercise Bike Self-Powered Features .............. 41 Informational Displays Prior to Shutdown ........42 Symptoms of a Low Battery ............42 Using the Optional Power Adapter ..........43 The Optional Power Adapter Kit ............ 43 Replacing the Battery ................
Assemble the equipment according to the guidelines in this manual to ensure you do not void the Precor Limited Warranty. Important: Any damage caused during installation is not covered by the Precor Limited Warranty.
Assembling and Maintaining the UBK 615 Upright Exercise Bike Unpacking the Equipment The shipping container for this exercise bike consists of the following items: Wooden pallet Cardboard base Cardboard cover Foam spacers WARNING Do not attempt to move the equipment off of the pallet by yourself.
Assembling the Exercise Bike Hardware Kit (not to scale) Before you begin the assembly, verify that the following hardware items are packed with the equipment. Fasteners Quantity M12 x 80 mm sockethead screw M8 x 25 mm sockethead screw M10 x 40 mm buttonhead screw ¹₄-inch x ³₄-inch buttonhead screw...
Assembling and Maintaining the UBK 615 Upright Exercise Bike Required Tools 6 mm hex wrench 10 mm hex wrench ⁵₃₂-inch hex wrench 13 mm open-end, box, or socket wrench 17 mm open-end wrench #2 Phillips screwdriver ...
Page 75
Assembling the Exercise Bike 2. Secure the rear stabilizer using two M10 x 40 mm buttonhead screws. Tighten the screws completely using a 6 mm hex wrench. Figure 3: Rear stabilizer attachment 3. Place the front stabilizer underneath the bracket at the front of the bike.
Page 76
Assembling and Maintaining the UBK 615 Upright Exercise Bike 4. Secure the front stabilizer using two M10 x 40 mm buttonhead screws. Tighten the screws completely using a 6 mm hex wrench. Figure 5: Front stabilizer attachment...
Assembling the Exercise Bike Attaching the Seat Mount the seat onto the bracket at the top of the seat column. To attach the seat: Place the seat on the bracket so that the three bolts extend through the screw holes. 2.
Assembling and Maintaining the UBK 615 Upright Exercise Bike Installing the Upright Support and Cables DANGER Do not attempt to connect electrical power until all assembly procedures are complete and the console is properly installed. Before you begin this procedure, retrieve the cables for the console that you plan to install on this exercise bike, or for any Cardio Theater®...
Page 79
Assembling the Exercise Bike 7. Lift the upright support and position its lower end over the upright support channel on the body assembly. Slide the support into position so that its screw holes line up with the corresponding holes on the body assembly, as shown in the following figure.
Page 80
Assembling and Maintaining the UBK 615 Upright Exercise Bike 8. Insert the two M12 x 80 mm sockethead screws through the openings on the support and into the screw holes on the body assembly. Tighten the screws completely using a 10 mm hex wrench.
Assembling the Exercise Bike Installing the Bottle Holder The bottle holder attaches directly to the upright support. To install the bottle holder: Position the bottle holder against the upright support so that the screw holes in the bottle holder and the support line up.
Assembling and Maintaining the UBK 615 Upright Exercise Bike Installing the Handlebars After the upright support and the bottle holder are securely in place, install the handlebar assembly and route the heart rate sensor cable through the support. To install the handlebars: Place the handlebars on the arms of the upright support, as shown in the following illustration.
Page 83
Assembling the Exercise Bike 2. Feed the end of the heart rate cable through the nearest arm of the upright support, then up through the support itself and out the opening in the console mount, as shown in the following figure. Figure 11: Cable routing through Display C console mount...
Page 84
Assembling and Maintaining the UBK 615 Upright Exercise Bike 3. Seat the handlebars on the upright support as shown in the following figure, storing extra cable in the upright support as needed. Figure 12: Handlebar installation 4. Place four 8.1 mm flat black washers onto four M8 x 25 mm sockethead screws.
Assembling the Exercise Bike Making Sure the Unit Is Stable Make sure the unit is level before allowing anyone to use it. CAUTION: To eliminate movement, make sure the adjustable feet are in contact with the floor. To level the unit: Gently rock the unit.
Assembling and Maintaining the UBK 615 Upright Exercise Bike Installing the Console Before you begin, make sure that the cables have been fed through the mounting bracket and their ends extend through the round opening at the base of the bracket. The television...
Page 87
Assembling the Exercise Bike 3. Retrieve the serial number label you removed from the body assembly earlier. Remove the backing from the label and apply it inside the console at the upper right, as shown in the following figure. Figure 14: Serial number label location...
Page 88
Assembling and Maintaining the UBK 615 Upright Exercise Bike 4. Route the flat, black base unit data cable to the left of the mounting bracket and about three-quarters of the way up the left side of the console, as shown in the following figure.
Page 89
Assembling the Exercise Bike 7. Lower the rear cover over the mounting bracket so that the upright support extends through the gap in the cover. Figure 16: Rear cover position 8. Position the back cover and attach the four 1-inch panhead machine screws, then tighten the screws completely using a #2 Phillips screwdriver.
Assembling and Maintaining the UBK 615 Upright Exercise Bike Breaking in the Equipment Precor equipment does not require an actual break-in period. However, moving components such as belts, gears, and bearings can settle while the equipment is being stored or shipped.
To keep the equipment functioning properly, perform the minor maintenance tasks in this section at the intervals shown on the maintenance checklist. Failure to maintain the equipment as described in this section could void the Precor Limited Warranty. DANGER To reduce the risk of electrical shock, always...
Assembling and Maintaining the UBK 615 Upright Exercise Bike Alternatively, you can clean the equipment with Athletix fitness equipment cleaning wipes (for more information, visit www.athletixproducts.com) CAUTION: Read and follow the manufacturer’s instructions, particularly dilution instructions, before using any cleaner on Precor fitness equipment.
Maintenance Quarterly Maintenance Precor recommends that you clean and inspect the equipment more thoroughly once every three months. To perform quarterly maintenance: Remove the cover panels. 2. Vacuum out any debris, being careful not to bring the vacuum cleaner nozzle too close to any circuit board (unless your vacuum cleaner is protected against static buildup).
Assembling and Maintaining the UBK 615 Upright Exercise Bike Moving the Equipment The equipment is very heavy. If you plan to move it to a new location, obtain the help of an adult assistant and use proper lifting techniques. If the equipment includes roller wheels on one end, use the wheels to reduce the load on yourself and your assistant.
Chapter Self-Powered Features Important: This chapter of the manual describes Precor fitness equipment that can operate without being connected to AC power. This includes units equipped with P30 or P10 consoles. However, P80 consoles must be connected to AC power through their power supplies to operate.
Assembling and Maintaining the UBK 615 Upright Exercise Bike Informational Displays Prior to Shutdown The equipment saves its battery charge by moving into a shutdown mode. If the user does not maintain the minimum rate of motion, a 30-second shutdown process begins.
CAUTION: The internal cable kit must be installed by authorized service personnel. Do not attempt installation on your own as you could void the Precor Limited Warranty. For more information, refer to Obtaining Service. Important: If this equipment includes a P80 console, the optional...
Assembling and Maintaining the UBK 615 Upright Exercise Bike Replacing the Battery The equipment’s battery is built to last for a long time. However, if you feel that the battery may need replacing, check with an authorized service technician. Refer to Obtaining Service.
CONDITIONS. Limited Warranty. Precor Incorporated warrants all new Precor products to be free from defects in materials and manufacture for the warranty periods set forth below. The warranty periods commence on the invoice date of the original purchase. This warranty applies only against defects discovered within the warranty period and extends only to the original purchaser of the product.
Page 100
Internet connectivity, such as Ethernet cabling, routers, servers and switches. Precor is not responsible for the quality of television, video, audio, or other media supplied to its products. This restriction applies to services, such as those provided by a cable or satellite television provider;...
Page 101
GIVEN ABOVE FOR THOSE SAME PARTS. PRECOR HEREBY DISCLAIMS AND EXCLUDES THOSE WARRANTIES THEREAFTER. Some States do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. PRECOR ALSO HEREBY DISCLAIMS AND EXCLUDES ALL OTHER OBLIGATIONS OR LIABILITIES,...
Page 102
Assembling and Maintaining the UBK 615 Upright Exercise Bike EXCLUSION OF CONSEQUENTIAL AND INCIDENTAL DAMAGES. PRECOR AND/OR ITS SUPPLIERS SHALL HAVE NO OBLIGATION OR LIABILITY, WHETHER ARISING IN CONTRACT (INCLUDING WARRANTY), TORT (INCLUDING ACTIVE, PASSIVE, OR IMPUTED NEGLIGENCE AND STRICT LIABILITY), OR...
Page 104
Precor Incorporated UBK 615 PAG/OM 302209-101 rev A 20031 142nd Avenue NE Warranty #36286-114 P.O. Box 7202 December 2012 Woodinville, WA USA 98072-4002...
