8. Set the console assembly on the Left Handrail
(74) and the Right Handrail (75). Be careful
not to pinch any wires. Pull the plastic tie tight
around the Upright Wire (77) and cut off the end
of the tie. Insert the excess Upright Wire into the
Left Handrail.
Attach the console assembly with six #8 x 3/4"
Screws (1) and four 1/4" x 1/2" Screws (4). Start
all ten Screws, and then tighten them.
9. Fully tighten the six 3/8" x 3 1/2" Screws (11)
(three on each side).
8
Console
Assembly
75
4
1
9
11
11
Plastic
Tie
74
1
1
11
77
4
