Digital Camera Specifications
Resolution
HI-1600x1200 / LO-640x480
Photograph measure
HI-40 P / LO-300 P
Image sensor
CMOS sensor
Focus range
15m( 49.21ft )~infinity
Exposure
Auto
White balance
Auto
Memory inside
16MB Flash internal memory
Memory slot
SD card slot for expandability
Battery
AAA alkaline battery x 2
Binocular specifications
Specifications
8 x32 mm
o
5.6 Field of view:
Angular field of view
92.7m(304 ft) at 914m(1000 YDS)
Exit pupil
4.0 mm
Eye Relief
12.5 mm
Multi coating on the first surface.
Coatings
Single layer for other surface, fully coated.
Close focusing distance
3.5 m
Package Contents
USB Cable
x1
x1
Software
User Guide
x1
Binocular Dimensions
156mm x 102mm x 56mm
Binocular Weight
433 g
System Requirements:
1. Window 98/ 98SE/ ME/ 2000/ XP
2. The processor above Pentium 233MHz
3. 128MB SDRAM
4. Video(VGA) card with 2MB of RAM for
minimum 16-bit (High Color) display.
(Built-in 16MB Flash memory)
5. CD-ROM
6. USB port
7. 600MB of free hard
disk space.
8x32
Binocular & Digital Camera
Model #72210
Advertisement
Related Manuals for Celestron VistaPix 72210
Summary of Contents for Celestron VistaPix 72210
- Page 1 Digital Camera Specifications Resolution HI-1600x1200 / LO-640x480 Photograph measure HI-40 P / LO-300 P (Built-in 16MB Flash memory) Image sensor CMOS sensor Focus range 15m( 49.21ft )~infinity Exposure Auto White balance Auto Memory inside 16MB Flash internal memory Memory slot SD card slot for expandability Battery AAA alkaline battery x 2...
- Page 2 Cautions Viewing (Movie) recorded images on PC 1. Use the USB cable to connect the USB port from PC to VistaPix. Cautions After connection the "PC" display on LCD. Never immerse VistaPix into any fluid or liquid. Remove dust or stains with a soft cloth dampened with water or neutral 2.
-
Page 3: Table Of Contents
Steps to download image file 1.To execute Photo Manager. 2.Enter " Removable Disk " to open Select the buttons as indicated. "DCIM" file. Contents 1.Introduction............P.1 2.Notice to user..........P .2 3.Product part identification.........P.3 Memory & Image Download ........P.4 5.Digital camera modes........P.5 3.In "... -
Page 4: Introduction
Steps to install Photo Manager 8. Choose "Custom" or "Typical" 9.Please confirm the file location 1.Introduction form of installation. VistaPix is a binocular integrated with a digital camera that is great for sporting events, concerts and wildlife activities such a s huntin g o r bird-watching. -
Page 5: Notice To User
Steps to install Photo Manager 1. Insert the CD ROM 3.Choose the language and press confirm button 2. Select "Install Thalia Photo Manager" 2.Notice to User WARNING ! Never use a VistaPix to look at the sun ! Looking at or near the sun will cause instant and irreversible damage to your eye. -
Page 6: Product Part Identification
Steps to install VistaPix driver 3. Product part identification 5. Computer will automatically install the driver. 1. Diopter Knob(on underside) 2. Center Focus Knob 6. If you see the "Microsoft digital sign" 3. Objective Lens request appear on screen as you are installing the driver , please press 4. -
Page 7: Memory & Image Download
Steps to install VistaPix driver Memory & Image Download 1.Before you install the driver, please make sure that your VistaPix is not Using SD memory card connected to the computer. The VistaPix has built in flash memory, so when you take images, the images will be saved into the flash memory inside your VistaPix until the memory is full. -
Page 8: Digital Camera Modes
8.Basic maintenance 4. Digital Camera Modes Press the left button (Mode/Power Button) to scroll through the Modes Operating Environment: 41 to104 F(5 to 40 C). 20%-85% relative humidity, Press right button(Shutter/Set Button)to select a mode or to take images. non-condensing. Full display of mode icon. - Page 9 6-1-10. VistaPix has a continuous picture taking (CPT) mode that allows you to [ SD card Format mode ] record a video stream as an AVI file. To use continuous picture taking VistaPix will format SD card.Images will be erased. mode: -Use the Mode/Power Button (4) to select the CPT mode.
-
Page 10: How To Use The Binocular
5. How to use the binocular 6.Using the Camera To adjust the eye-relief for eyeglass wearers: Fold down the rubber eyecups Use this product under good lighting conditions, avoid facing light source and place them against your glasses to get the best viewing result. directly.
