- Page 1 User’s Manual Utility Series UPS OP850/1250 ADDITIONAL INSTALLATION TIPS CAN BE FOUND AT: www.cyberpowersystems.com/support.htm...
-
Page 2: Table Of Contents
DEFINITION FOR ILLUMINATED LED INDICATORS……………………………………..…8 LIMITED WARRANTY AND POWER CONTROL GUARANTEE……………………………9 Thank you for purchasing a CyberPower Systems Product. To enjoy all the features and benefits of this Uninterruptible Power System (UPS), please read and follow all installation and operation instructions completely. This UPS is designed to provide guaranteed power protection for connected electronic equipment. -
Page 3: Important Safety Warnings
CAUTION! DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT! CyberPower Systems does not sell products for life support or medical applications. DO NOT use in any circumstance that would affect operation or safety of any life support equipment, with any medical applications, or patient care. -
Page 4: Installing Your Ups System
INSTALLING YOUR UPS SYSTEM UNPACKING Inspect the UPS upon receipt. The box should contain the following: (1) UPS Unit; (1) User’s Manual for UPS; (1) Warranty Registration Card; (1) PowerPanel Software Disk; (1) User’s Manual for PowerPanel (1) Serial Interface Cable (DB-9); (1) Serial-to-USB cable; (1) Telephone Cable HARDWARE INSTALLATION GUIDE 1. - Page 5 OP850/1250 Guaranteed Uninterruptible Power System...
- Page 6 ◆ Power Switch Press the power button to turn the UPS ON or OFF ◆ Power On Indicator This LED is illuminated when the utility condition is normal and the UPS outlets are providing “clean power”, free of surges and spikes. ◆...
-
Page 7: Battery Replacement And Storage
BATTERY REPLACEMENT AND STORAGE Contact your dealer or call the number in this manual for information on battery replacement. The order numbers for the battery are as follows: BA-OP850/1250 for OP850/1250 CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the battery. - Page 8 6. Lean the UPS to one side. 7. Remove the battery from the compartment. 8. Disconnect the battery wires from the battery. 9. Install the replacement battery by connecting the red wire to the positive (+) terminal of the battery and connecting the black wire to the negative (-) terminal of the battery.
-
Page 9: Troubleshooting
Recharge the battery by leaving the perform expected UPS plugged in. runtime. Battery is slightly worn out. Contact CyberPower Systems at tech@cyberpowersystems.com The UPS will not The on/off switch is designed to Turn the UPS off. Wait 10 seconds turn on. -
Page 10: Technical Specifications
TECHNICAL SPECIFICATIONS Model OP850 OP1250 Capacity (VA) 850VA 1250VA Capacity (Watts) 510W 750W Input Input Voltage Range 85Vac – 150Vac Frequency Range 57 – 63 Hz Output On Battery Output Voltage Simulated Sine Wave at 120Vac +/- 5% On Battery Output Frequency... -
Page 11: Definition For Illuminated Led Indicators
OP850/1250 Guaranteed Uninterruptible Power System DEFINITIONS FOR ILLUMINATED LED INDICATORS Condition Power Using Circuit Wiring Battery Boost Buck Breaker Alarm Fault Normal Max. boost 15% of input voltage for output regulation while input voltage is from 12% to 30% under nominal. -
Page 12: Limited Warranty And Power Control Guarantee
LIMITED WARRANTY AND POWER CONTROL GUARANTEE In purchasing a OP850/ OP1250 in the United States or Canada, the original end user receives a Limited Warranty and CyberPower's Power Control Guarantee from Cyber Power Systems (USA), Inc. (for ease of reading, referred to as "CyberPower"). The Limited Warranty and the Power Control Guarantee are intended to be the original end-user's exclusive rights and remedies. - Page 13 3. When you contact CyberPower, identify the Product, the Purchase Date, and request Return Materials Authorization (RMA) information from CyberPower. 4. Pack and ship the Product to CyberPower as instructed in your RMA. Show the RMA code on the shipping label or include it with the Product. You MUST prepay all shipping costs and you are responsible for packaging and shipment.
- Page 14 Product), and; (c) none of the limitations or exclusions on warranty coverage apply (or than...
- Page 15 Disturbance passes through the CyberPower Product and (y.1) exhausts the protection capacity of the CyberPower Product or (y.2) damages the CyberPower Product. This provision sets out the only liability of any character of CyberPower for direct, indirect, special, consequential, and/or incidental damages under our Limited Warranty, applies only to Connected Equipment, and all such Liability is limited to the Agreed Damage Amount.
- Page 16 The Limited Warranty and the Power Control Guarantee are intended to exclusive rights and remedies and replace any other rights, to the extent allowed by law. 1. As to the CyberPower Product, the limited warranty does not cover or apply to: misuse, modification, operation or storage outside environmental limits for the Products,...
- Page 17 High Risk Activities. CyberPower does not authorize use of any of its products in any High Risk Activity. ANY SUCH USE IS IMPROPER AND IS A MISUSE OF A CYBERPOWER PRODUCT.
- Page 18 Tel: (952) 403-9500 Fax: (952) 403-9500 Email: sales@cyberpowersystems.com Web: www.cyberpowersystems.com Entire contents copyright ©2003 CyberPower Systems, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited. PowerPanel™ and PowerPanel Plus™ are trademarks of CyberPower Systems (USA), Inc.
