Section One - Introduction

The MaxTech XPVS56P/C PCI Plug and Play Data,
Fax, Voice Speakerphone Modem connects your com-
puter to all popular high speed modems available today.
The modem utilizes V.90 (56Kbps) technology to provide
increased download speeds using regular telephone
lines. The modem incorporates Plug and Play for ease of
installation.
This manual describes the hardware installation
procedures for your new modem. Additional information
on AT commands and S-registers is provided so that your
system can be customized for a particular operating
environment.
*Note: V.90 is capable of downloading at 56Kbps. How-
ever, current FCC regulations limit its speeds to 53Kbps.

Section Two - Installation

This section will provide step by step instructions
on how to install your new 56 Kbps Data, Fax, Voice,
Speakerphone modem. Installation of this modem is a two-
step process consisting of: 1) hardware installation and
2) communication software installation.
2.1 Unpacking Your Modem
Be certain that you have all the items listed below.
This package contains:
• A modem
• User's manual
• Software user's manual
2.2 What You Need
You will need:
1. A phillips-head screw driver.
2. A computer running Microsoft Windows 95 or
later.
3. An available PCI slot in your PC.
Proceed to Section 2.3 now if you have every-
thing required.
• A telephone cable
• Software for the modem
1
