MaxTech PCI Internal Voice/FAX/Data/Speakerphone Modem User Manual page 10

I5
I6
I7
I8
I10
L_ L0
L1
L2
L3
M _ M0
M 1
M2
M3
N_ N0
N1
O_ O0
O1
O3
P
Q_ Q0
Q1
S n ? n=0-33 Read and display value in register n
S n = x
T
V_ V0
V1
W_ W0
W1
W2
W3
W4
X_ X0
Modem chip hardware configuration
Country code
Board manufacturer firmware version
Modem firmware version
Modem board configuration
Low speaker volume
Low speaker volume
Medium speaker volume
High speaker volume
Internal speaker off
Internal speaker on until carrier
detected
Internal speaker always on
Internal speaker on until carrier detected
and off while dialing
Connect only at DTE rate
Automatic rate negotiation
Return to Data Mode
Return to Data Mode and initiate an
equalizer retrain
Renegotiates rate and then returns to
data mode
Set Pulse dial as default
Modem sends responses
Modem does not send responses
Set register n (n=0-33; x=0-255)
Set Tone Dial as default
Numeric responses
Word responses
Modem reports DTE response
codes
Modem reports DTE response codes
Modem reports DCE response codes
Modem reports DTE speed, modulation
mode, error control, data compression,
DCE transmit and receive speed
Modem reports
compression and DTE data rate
Hayes Smartmodem 300 compatible
responses/blind dialing
8
protocol, data
