Threading chainstitch looper (purple)

• Raise the presser foot to release tension discs.
• Pass the thread from back to front through the thread
guide on the thread stand (1).
• Thread the top cover thread guide by pulling the
thread towards the right until it slips under the guide.
Then pull the thread along the right side of the button
as illustrated (2).
• Lift up the handle and bring the thread under it. While
holding the thread with both hands, pass it between
the tension discs and pull it down to make certain it is
properly placed between the tension discs (3).
• Turn the handwheel toward you until the chainstitch
looper is at the far right.
• Thread the looper area of the machine following the
purple color coded thread guides (4-11).
• Place the thread through threading guide (4).
• Place the thread through the front slot of threading
guide (5).
• Thread the chainstitch thread guide (8) by holding the
thread in front of the thread guide pin and pulling the
thread backward and up, until the thread rests inside
the thread guide loop and under the spring.
• To thread the last thread guide (10), pull about 10 cm
• Thread the looper eye (A) from front to back using the
cutout (B) on threader lever. Firmly hold the thread tail
with left hand and pull the threader lever (C) up into
place and back to snap the thread into thread guide 10.
14 Threading
1
3
2
10
11
9
8
8
10
B
2
5
5
7
A
C
1
4
6
