UBI EasyCoder 401 Linerless – User's Manual
PRINTHEAD CLEANING, cont'd.
5 6
Insert most of the cleaning card under the printhead (1). Pull out the cleaning card (1) and turn the printhead
Turn the printhead lift knob to "Print" position (2). lift knob to "Load" position (2).
7 8
12
11 1
10 2
30 s.
9 3
8
4
7 5
6
Insert the cleaning card under the printhead again (1).
Wait for approx. 30 seconds. Turn the printhead lift knob to "Print" position (2).
9 10
Allow the cleaned parts to dry before
loading the printer with paper.
Pull out the cleaning card. Repeat if necessary.
