Whirlpool WED99HED Dimension Manual

Front view:
(686 mm)
38 / " Min.
3
4
(984 mm)
39" Max.
(990 mm)
Recommended installation clearances (dryer only):
5"
(127 mm)
(25 mm)
Installation spacing for recessed area or closet installation
All dimensions show recommended and minimum spacing allowed.
Additional spacing should be considered for ease of installation
■
and servicing.
Additional clearances might be required for wall, door, floor,
■
moldings, and drain system.
Additional spacing should be considered on all sides of the dryer
■
to reduce noise transfer.
For closet installation, with a door, minimum ventilation openings
■
in the top and bottom of the door are required. Louvered doors
with equivalent ventilation openings are acceptable.
Companion appliance spacing should also be considered.
■
27"
3"
(76 mm)
18" min.
(457 mm)
3"
(76 mm)
1"
1"
(25 mm)
Electric Heat Pump Dryer
PRODUCT MODEL NUMBERS
WED99HED
Side view:
Back view:
48 in. min.
2
(310 cm )
2
24 in. min.
2
(155 cm )
2
* Approx. measurement.
NOTE: Allow clearance behind dryer for proper
drain hose routing and cooling fan ventilation.
Push dryer back as far as possible and make sure
drain hose is not crushed or kinked.
6 "
1 /
2
(165 mm)
Power cord/
cable
29 / "*
7
8
Water Cooling
(759 mm)
drain fan
13 " 6 / "
/ 1
1
2
2
(165 mm)
(343 mm)
W10678946B
12/2014
